Hardware Overview

IS-NAS Server Front Controls and Indicators

2
Your NAS system consists of the following hardware elements:
• A System Management Unit (SMU), either internal or external, depending on system
configuration
• SGI InfiniteStorage NAS 50/100 server(s), referred to as IS-NAS server(s)
• Storage subsystem, which includes the storage array controllers and/or drive trays populated
with disk drives
• Fibre Channel (FC) switch, depending on system configuration
• Private management network
• Public data network
The IS-NAS server is a highly scalable and modular NAS server with multi-gigabit throughput
from network to disk.
Figure 1-1 shows the LEDs on the front of an IS-NAS server.
the various states of the LEDs.
Figure 1-1 IS-NAS Server Front Controls and Indicators
Table 1-1 and Table 1-2 describe
