CIS VCC-SXCXP5M Product Specification & Operational Manual

Coaxpress i/f 1.6m pixels cmos (b/w) camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Rev. 905-0276-Z1
CoaXPress I/F
1.6M pixels CMOS (B/W) Camera
VCC-SXCXP5M
Product Specifications
& Operational Manual
(P relim inary)
CIS Corporation
©2022 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-SXCXP5M and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-SXCXP5M

Summary of Contents for CIS VCC-SXCXP5M

  • Page 1 Rev. 905-0276-Z1 CoaXPress I/F 1.6M pixels CMOS (B/W) Camera VCC-SXCXP5M Product Specifications & Operational Manual (P relim inary) CIS Corporation ©2022 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    User ID ..............................24 4.17 Temperature Indication ..........................24 4.18 Connection Reset ............................ 24 4.19 Gamma Correction ..........................25 4.20 Image Quality Selection Mode ........................25 4.21 Shading Correction ..........................25 Factory Settings ..............................27 ©2022 CIS Corporation. All rights reserved.
  • Page 3 VCC-SXCXP5M Rev.905-0276-Z1 Dimensions ............................... 28 Camera Dimensions ..........................28 Optical Axis Accuracy ..........................29 Case for Indemnity (Limited Warranty) ........................ 30 Product Warranty ............................ 30 CMOS Defective Pixels ..........................30 Product Support ............................30 ©2022 CIS Corporation. All rights reserved.

  • Page 4: Handling Precautions

    □ The camera must not be used under conditions or environments other than those specified in this manual. 1.3. Disclaimers (Exception Clause) CIS should not be liable for any damages or losses if; damages or losses are caused by earthquake, lightning strike, fire, flood, or other acts of God. □...

  • Page 5: Product Outline

    Rev.905-0276-Z1 2. Product Outline VCC-SXCXP5M is B/W camera with CoaXPress interface. Using 1/2.9”, global shutter type 1.6M pixels CMOS image sensor. Complies with CoaXPress Version 1.1.1. Must have function ready for Machine Vision applications such as trigger shutter, ROI, Gain, black level adjustment, defective pixel correction, and PoCXP. Suitable for various FA/Machine vision applications.

  • Page 6: Specifications

    Partial scan User can set vertical/horizontal 1 area. Power requirements PoCXP: 18.5~26V Power consumption (Max) 2.95W(CXP-3), 3.15W(CXP-6) [with free run] Mechanical Specifications Dimensions H:29mm W:29mm D:29mm excluding projection. Weight Approx. 50g Lens mount C mount ©2022 CIS Corporation. All rights reserved.

  • Page 7: Input And Output Specifications

    □ 5.0V CMOS logic level output □ Output voltage Low: 0.55Vdc (Max), High: 3.8Vdc (Min) □ This is to output timing signals generated in the camera. Set the signal to output with LineSource of DigitalIOControl. +5.0V (CAMERA_INTERNAL) SIGNAL_OUT SN74LV1T32DCKR(Equivalent) ©2022 CIS Corporation. All rights reserved.

  • Page 8: External Connector Pin Assignment

    Green lighting Completion of connection between device and host. Green fast blinking [12.5Hz] Transmitting video data. Orange slow blinking [1Hz] Waiting for a trigger input. Red fast blinking [12.5Hz] System error or inappropriate trigger input. ©2022 CIS Corporation. All rights reserved.

  • Page 9: Spectral Response

    The following command enables to readout frame rate of internal sync. mode. AcquisitionControl AcquisitionFrameRate (ReadOnly)  AcquisitionFrameRate: This is to indicate the frame rate with internal sync. mode (free run mode). ※Even with external trigger mode, frame rate with internal sync. mode will be shown. ©2022 CIS Corporation. All rights reserved.

  • Page 10: Frame Rate Of External Trigger Sync. Mode

    Default. (Camera keeps those values.) ConnectionConfig, PixelFormat, and ImageQualityMode are not subject to UserSetLoad so that camera keeps □ values in operation. If you wish to change those values, set values with each command. ©2022 CIS Corporation. All rights reserved.

  • Page 11: Link Speed And Link Count

    ※ When executing Flip operation with ROI at the same time, the origin coordinate (0) will be on the displaying screen regardless of On/Off of flip setting. The coordinates associated with the setting order of ReverseY and ROI are shown in the next page. ©2022 CIS Corporation. All rights reserved.

  • Page 12: Trigger Mode

     TriggerSelector: Trigger selector (Link with TriggerMode) AcquisitionStart: Operates with internal sync. mode (Free run mode) (TriggerMode = Off) FrameStart: Operates with external trigger mode (TriggerMode = On) ※ Do not change TriggerSelector while grabbing (acquiring image). ©2022 CIS Corporation. All rights reserved.

  • Page 13: Internal Sync. Mode (Free Run Mode)

    □ User can select detailed function with following commands. (Make sure to stop inputting triggers while selecting function.) Acquisition Control LineSync TriggerSyncMode ClockSync LinkTrigger0 TriggerSource Line0 Software TriggerSoftware (Execute) RisingEdge FallingEdge TriggerActivation LevelHigh LevelLow ©2022 CIS Corporation. All rights reserved.

  • Page 14: Fixed Trigger Shutter Mode + H Sync Trigger (Linesync)

    □ There is a restriction for trigger input. Please refer to Section 4.6.7. Restrictions on Trigger Pulse Input Timing. □ The diagram in the next page shows the timing chart and the timing parameter with internal sync. mode + H sync trigger (LineSync). ©2022 CIS Corporation. All rights reserved.

  • Page 15: Fixed Trigger Shutter Mode + Clk Sync. Trigger (Clocksync)

    □ There is a restriction for trigger input. Please refer to Section 4.6.7. Restrictions on Trigger Pulse Input Timing. □ The following shows the timing chart and the timing parameter with fixed trigger shutter mode + CLK sync trigger (ClockSync). ©2022 CIS Corporation. All rights reserved.

  • Page 16: Pulse Width Trigger Shutter Mode + H Sync. Trigger (Linesync)

    Section 4.6.7. Restrictions on Trigger Pulse Input Timing. □ The diagram in the next page shows the timing chart and the timing parameter with pulse width trigger shutter mode + H sync. trigger (LineSync) ©2022 CIS Corporation. All rights reserved.

  • Page 17: Pulse Width Trigger Shutter Mode + Clk Sync. Trigger (Clocksync)

    Section 4.6.7. Restrictions on Trigger Pulse Input Timing. □ The diagram in the next page shows the timing chart and the timing parameter with pulse width trigger shutter mode + CLK sync. trigger (ClockSync) ©2022 CIS Corporation. All rights reserved.

  • Page 18: Restrictions On Trigger Pulse Input Timing

    Please refer to the following restrictions for external trigger input timing. Error will occur if these restrictions are not met. (1) With TriggerSyncMode=ClockSync, user cannot input next trigger until completion of readout images. Input triggers after completed readout. ©2022 CIS Corporation. All rights reserved.
  • Page 19 0 or 1 (ReadOnly) IllegalTriggerFlag  IllegalTriggerFlag: If there is a trigger input with restricted timing explained in the above, “IllegalTriggerFlag” becomes “1”. Device Control ErrorFlagReset (Execute)  ErrorFlagReset: This is to reset IllegalTriggerFlag to “0”. ©2022 CIS Corporation. All rights reserved.

  • Page 20: Exposure Time

    User can adjust black level of image sensor proportionally. This is a value converted by 12bit. The value will be equivalent to 1/4 of setting value with 10bit, and equivalent to 1/16 of setting value with 8bit. ©2022 CIS Corporation. All rights reserved.

  • Page 21: Partial Scan (Roi)

    ※Make sure to select EffectiveRegion when acquire images. ※When there is no effective Region, user cannot select EffectiveRegion.  RegionMode: Set valid/invalid of selected Region. With this model VCC-SXCXP5M, RegionMode is always valid (On).  RegionDestination: Select Stream to output. VCC-SXCXP5M is fixed to Stream0.

  • Page 22: Defective Pixel Correction

    Defective pixel correction data at factory and defective pixel correction data registered by user will be both controlled at the same time. Defective data registered by user □ This is to add/delete the designated X and Y coordinate. AnalogControl DefectPixelAdd (Execute) DefectPixelAddOffsetY 0~1087 DefectPixelAddOffsetX 0~1455 DefectPixelDelete (Execute) ©2022 CIS Corporation. All rights reserved.
  • Page 23 ※Make sure to execute UserSetSave to save data into camera non-volatile memory. (Not saved in camera non-volatile memory at the time of registration with DefectDetection command.) ※Make sure to execute this command while grabbing (acquiring images). ※Make sure to execute with full frame (1456×1088). ©2022 CIS Corporation. All rights reserved.
  • Page 24 When vertical flip is ON, camera deletes user registered defective pixel information entirely with DefectPixelDefault. When vertical flip is OFF, camera does not delete user registered defective pixel information. ©2022 CIS Corporation. All rights reserved.

  • Page 25: Test Pattern Indication

    4.12 Test Pattern Indication This is to display test pattern from camera. This is useful to check if your system is operating properly. ImageFormatControl TestPattern GrayHorizontalRamp GrayHorizontalRampMoving ※Displaying test pattern and cursor are mutually exclusive. ©2022 CIS Corporation. All rights reserved.

  • Page 26: Cursor Indication

    ExposureActive FrameActive LineActive TriggerPacketActive  LineSelector: Select line to set/select. Line0: No.5 pin of 6pins circular connecter Line1: No.3 pin of 6pins circular connecter  LineMode: Indicate the I/O direction of the selected line. ©2022 CIS Corporation. All rights reserved.

  • Page 27: User Id

     ConnectionReset: Reset the device and reconnect it automatically. ※ Please note that it takes few seconds to reconnect the device. ※ Until completed reconnecting the device, error might be indicated temporary with DeviceTemperature, IllegalTriggerFlag etc. Reacquire the values after completed reconnection. ©2022 CIS Corporation. All rights reserved.

  • Page 28: Gamma Correction

    Off: Disable shading correction. Table1- 3: Enable shading correction with the selected correction value. Select Table from 1-3 and execute DetectShading to acquire correction data to the specified Table. Before shading correction After shading correction ©2022 CIS Corporation. All rights reserved.
  • Page 29 ・ Execute UserSetSave to save the correction data of Table1~Table3 into non-volatile memory at the same time. ・ Even execute Default with UserSetLoad, camera maintains correction data. ・ User cannot execute shading detection when ShadingCorrectionDataSelector is Off. ©2022 CIS Corporation. All rights reserved.

  • Page 30: Factory Settings

    CoaXPress connection status indication mode LineSelector Line0 Line0 LineSource FrameTrigger Trigger input DeviceUserID User set letter string (16 letters) DeviceUserString User set letter string (256 letters) ※ ConnectionConfig, PixelFormat, and ImageQualityMode are not subject to UserSetLoad. ©2022 CIS Corporation. All rights reserved.

  • Page 31: Dimensions

    VCC-SXCXP5M Rev.905-0276-Z1 Dimensions 6.1 Camera Dimensions 935-0178-00 (Unit: mm) ©2022 CIS Corporation. All rights reserved.

  • Page 32: Optical Axis Accuracy

    VCC-SXCXP5M Rev.905-0276-Z1 6.2 Optical Axis Accuracy ©2022 CIS Corporation. All rights reserved.

  • Page 33: Case For Indemnity (Limited Warranty)

    CIS applies defective pixel correction prior to shipment of the product. However, the number of defective pixels are subject to increase due primarily to the effect of cosmic rays. Due to this nature, CIS should not hold responsible for the natural increase of defective pixels.
