CIS VCC-SXCXP3NIR Operation Manual

Coaxpress i/f 1.3m cmos near-infrared camera

Advertisement

Quick Links

VCC-SXCXP3NIR
Rev.905-0133-00
CoaXPress I/F
1.3M CMOS
Camera
Near-Infrared
VCC-SXCXP3NIR
Product Specifications
& Operational Manual
CIS Corporation
©2018 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-SXCXP3NIR and is the answer not in the manual?

Questions and answers

Summary of Contents for CIS VCC-SXCXP3NIR

  • Page 1 VCC-SXCXP3NIR Rev.905-0133-00 CoaXPress I/F 1.3M CMOS Camera Near-Infrared VCC-SXCXP3NIR Product Specifications & Operational Manual CIS Corporation ©2018 CIS Corporation. All rights reserved.
  • Page 2: Table Of Contents

    Sequence Status Output ......................25 10. Factory Settings ..........................27 11. Dimensions ........................... 28 11.1 Optical Axis Accuracy ......................28 11.2 Camera Dimensions ........................ 29 12. Case for Indemnity (Limited Warranty) ..................... 30 13. Product Support ..........................30 ©2018 CIS Corporation. All rights reserved.
  • Page 3: Handling Precautions

    Do not disassemble the camera. The camera once disassembled shall be out of warranty. Product Outline VCC-SXCXP3NIR is a CoaXPress interfaced small NIR camera utilizing a 1/2 type, 1.3M pixels CMOS image sensor. Features 29mm x 29mm x 29mm in size...
  • Page 4: Bundled Items

    VCC-SXCXP3NIR Rev.905-0133-00 Bundled Items Standard Bundled Items Camera module, VCC-SXCXP3NIR Lens cap Packaging □ Individual carton □ Master carton (10 pcs/carton) Note) Q’ty per master carton may vary depends on the shipping q’ty. ©2018 CIS Corporation. All rights reserved.
  • Page 5: Specifications

    (23) Operation Environment Operation -5 ~ + 45℃ Humidity: 20 ~ 80% RH with no condensation. guaranteed (24) Storage Environment Storage -25 ~ + 60℃ Humidity: 20 ~ 80% RH with no condensation. temperature ©2018 CIS Corporation. All rights reserved.
  • Page 6: Camera In/Output Signal Specifications

    Pin No. 3 FVAL, LVAL, and settings UplinkTriger (After decoding) 5V output Image Sensor Spectral Response ※Please refer to NIR in the graph below. ※The lens characteristic and the illum inant characteristics are excluded. ©2018 CIS Corporation. All rights reserved.
  • Page 7: External Connector Pin Assignment

    6pins Circular Connector (SNH-8-6(RPCB) SamWoo Electronics) Pin No. Signals Note SIGNAL_OUT The output of the selected signal TRIGGER_IN Trigger input Conduction with camera casing ※NC means Non-Connection. Please do not connect anything to the terminal. ©2018 CIS Corporation. All rights reserved.
  • Page 8: How To Save And Initialize The Settings

    If you wish to save the setting values, execute UserSetSave. Doing so, the setting values are saved in the camera internal ROM. And, the saved settings are reflected when the camera is turned on next time. ©2018 CIS Corporation. All rights reserved.
  • Page 9: Camera Operational Mode

    Please be noted that time accuracy with this trigger is not so precise as the trigger generated by TriggerSource explained the above. Only TriggerSelectorAndActivation --- FrameStartRisingEdge mode can be used as Acquisition Control mode. ©2018 CIS Corporation. All rights reserved.
  • Page 10: Internal Sync Mode (Free Run Mode)

    FVAL became “L”. In such cases or when proper images cannot be output, stop inputting a trigger, then execute “SensorReset” command to re-start. ※ Should it cannot be solved, please reboot the camera. Device Control (Execute) SensorReset ©2018 CIS Corporation. All rights reserved.
  • Page 11 Video Out Exposure Out Exposure time Image Image Cxp Stream Idle Stream data Idle Stream data Idle Header Header LVAL FVAL Trigger input forbidden period Readout time Exposure delay time (A) Exposure delay time (B) ©2018 CIS Corporation. All rights reserved.
  • Page 12: Camera Function Settings

    ※Gain up function is up to +32 times. However, please be noted that the image quality will be reduced when gain setting is increased. We recommend you to evaluate it first. AnalogControl Gain_x1 Gain_x1_5 Gain_x2 PresetGainX Gain_x3 Gain_x4 Gain_x6 Gain_x8 Gain (Manual) ©2018 CIS Corporation. All rights reserved.
  • Page 13: Exposure Time Settings

    PresetShutter1_Xs Shutter(s) Time Shutter_1_100 1/100 10ms Shutter_1_150 1/150 6.7 ms Shutter_1_300 1/300 3.3 ms Shutter_1_600 1/600 1.7 ms Shutter_1_1200 1/1200 833 us Shutter_1_2500 1/2500 400 us Shutter_1_5000 1/5000 200 us Shutter_1_10000 1/10000 100 us ©2018 CIS Corporation. All rights reserved.
  • Page 14: Roi (Region Of Interest)

    83.8 167.4 198.1 ROIQuickChangePattern3 1024x768 8bit 130.4 260.7 260.7 10bit 109.8 219.6 260.7 ROIQuickChangePattern4 800x600 SVGA 8bit 193.2 386.3 386.3 10bit 173.0 345.9 386.3 ROIQuickChangePattern5 640x480 8bit 268.9 536.7 536.7 10bit 257.1 514.2 536.7 ©2018 CIS Corporation. All rights reserved.
  • Page 15: Sub-Sampling

    ・Execute re-grabbing the viewer to acquire images. ・The frame rates when sub-sampling operation is in operation at free run mode areas follows. Link Configuration Frame rate (fps) 8bit 10bit CXP-1 266.8 254.5 CXP-2 533.7 508.6 CXP-3 533.7 533.7 ©2018 CIS Corporation. All rights reserved.
  • Page 16: Defectivepixelcorrection

    VCC-SXCXP3NIR Rev.905-0133-00 Defective Pixel Correction CIS compensates the noticeable CMOS pixel defects found at the shipping inspection prior to our shipment. Defective pixel correction can be set to OFF. AnalogControl True DefectivePixelCorrection False Shading Correction This is a function to correct the peripheral brightness lowering caused by the lens and others used.
  • Page 17: Black Level Adjustment

    Inactive Active : This is to indicate communication status of CoaXPress. ・ ・ ErrorStatus : Normally the light is OFF. However, the light turns ON when system error occurs. ・ Inactive : LED OFF. ©2018 CIS Corporation. All rights reserved.
  • Page 18: Camera Timing Output

    Execute “UserDefault” to restore to the factory settings. ※ Register area is 16 byte in total. Please input single-byte alphanumeric characters. ※ Register area is 16 byte in total. Please input single-byte alphanumeric characters. ©2018 CIS Corporation. All rights reserved.
  • Page 19: Sequence Control Function

    (IndexLoopCount), entire sequence loop count (SeqencerLoopCount), and the range of index to be used. (ActiveIndexNumber) SequencerControl --- SequencerActivation ⑤ This is to set the start operation of sequence mode. By setting any preferred [SequencerActivation] from Off, the camera will become stand-by status for a trigger. ©2018 CIS Corporation. All rights reserved.
  • Page 20: Trigger Mode Operation And Burst Mode Operation Outline

    ActiveIndexNumber IndexLoopCount 実行するIndexの範囲 Loop count for each Index. Index range to be executed 各Indexを繰り返す回数 SequencerLoopCount ParameterIndexNumber 0: 無限loop, 1~: 有限loop数 各Indexとパラメータセットの紐付け 0: Infinite loop, 1~: Finite loop count Connect each Index with parameter set ©2018 CIS Corporation. All rights reserved.
  • Page 21: Trigger Mode

    Sequence starts with trigger input when TriggerSelectorAndActivation is FrameStartLevelHigh or FrameStartLevelLow. ・ Exposure time for each frame (① and ②) is the pulse width of the trigger. ・ When the image output for the sequence Loop count is completed, sequence operation ends. ©2018 CIS Corporation. All rights reserved.
  • Page 22: Burst Mode

    When the image output for the sequence loop count is completed, sequence operation ends. ・ (3) Resister Start Sequence operation starts simultaneously when the SequencerActivation OFF is set to FrameBurstStartSoftware. ※ To restart burst mode operation, turn off SequencerActivation OFF once. ©2018 CIS Corporation. All rights reserved.
  • Page 23: Index Mode

    ※ Notes for the issuing timing of IndexSelectorModeIndexNumber command To reflect the specified parameter set surely to the next frame, please issue IndexSelectorModeIndexNumber, wait for the response of ACK, and then input a trigger pulse. ©2018 CIS Corporation. All rights reserved.
  • Page 24: Settings For Sequence Control

    Loop count for whole sequence. 0:infinity ActiveIndexNumber The largest Index number to execute. IndexSelectorModeIndexNumber The Index number to use for Index Mode. ParameterIndexNumber Index0-7 Parameter number of Index0-7. IndexLoopCount IndexCount0-7 Repeating count of each Index0-7. ©2018 CIS Corporation. All rights reserved.
  • Page 25: Sequence Status Output

    The position to indicate the status information can be selected out of four positions as below, and the information shall be embedded into five pixels. TopLeft TopRight Effective Image Pix0 Pix1 Pix2 Pix3 Pix4 BottomLeft BottmRight ©2018 CIS Corporation. All rights reserved.
  • Page 26 In case of 10bit video output, 2 bit of LSB side shall be always “00”. pix0 Index Number [3:0] “0000” “00” pix1 Repeating Count [7:0] “00” pix2 “000000” Repeating Count “00” [9:8] pix3 Loop Count [7:0] “00” pix4 “000000” Loop Count [9:8] “00” ©2018 CIS Corporation. All rights reserved.
  • Page 27: Factory Settings

    The same value as the Index number Index0Count~Index7Count All 1 SequencerLoopCount ActiveIndexNumber ActiveIndexModeIndexNumber SequencerExposureTime 1000.0 (Selector 0-7) SequencerGain (Selector 0-7) TransportLayer CxpLinkConfiguration CXP_X1 ※ Factory setting values are the same as the one for UserSetDefault command. ©2018 CIS Corporation. All rights reserved.
  • Page 28: Dimensions

    VCC-SXCXP3NIR Rev.905-0133-00 11. Dimensions 11.1 Optical Axis Accuracy ©2018 CIS Corporation. All rights reserved.
  • Page 29: Camera Dimensions

    VCC-SXCXP3NIR Rev.905-0133-00 11.2 Camera Dimensions ©2018 CIS Corporation. All rights reserved.
  • Page 30: Case For Indemnity (Limited Warranty)

    CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases. In case damages or losses are caused by earthquake, lightning strike, fire, or other acts of God.
