VCC-G22V31APCL
Rev.900-662-33-00
English
VGA B/W Camera
49MHz Pixel Clock PoCL/PoCL-Lite
VCC-G22V31APCL
Product Specification
& Operational Manual
CIS Corporation
©2010 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISIONmini VCC-G22V31APCL and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VISIONmini VCC-G22V31APCL

Summary of Contents for CIS VISIONmini VCC-G22V31APCL

  • Page 1 VCC-G22V31APCL Rev.900-662-33-00 English VGA B/W Camera 49MHz Pixel Clock PoCL/PoCL-Lite VCC-G22V31APCL Product Specification & Operational Manual CIS Corporation ©2010 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    9. Initial Settings ............................. 14 10. CCD Optical Axis Accuracy ........................15 11. Dimensions ............................16 12. Cases for Indemnity (Limited Warranty) ....................17 13. CCD Pixel Defect ..........................18 14. Product Support ..........................18 ©2010 CIS Corporation. All rights reserved.

  • Page 3: Scope Of Application

    The voltage ripple of camera power DC +12V±10% shall be within ±50mV. Improper power supply voltage may cause noises on the video signals. Please avoid noises like chattering when rising power. In case of abnormal operation, contact the distributor from whom you purchased the product. ©2010 CIS Corporation. All rights reserved.

  • Page 4: Product Outline

    Full frame scan mode and three different partial scan modes are available. □ Approx. 120 fps at full frame scan mode. □ Only 29mm cubic in size (excluding projection), light weight 50g, and speed makes it a best match for □ use in embedded systems. ©2010 CIS Corporation. All rights reserved.

  • Page 5: Specification

    OFF (1/120), 1/200, 1/240, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/14000, variable range 1/24000, 1/40000, 1/100000s ・Fixed Trigger Shutter Mode ・Pulse Width Trigger Shutter Mode Trigger shutter mode *Trigger pulse width shall be over 1H and less than 1/2s. ©2010 CIS Corporation. All rights reserved.
  • Page 6 ±Y, and ±Z, 6 directions. (without package) Temperature Operation guaranteed: -5℃～+45℃ Performance guaranteed: 0℃～+40℃ Operation environment RH 20～80% with no condensation Humidity Temperature -25℃ ～ +60℃ Storage environment RH 20～80% with no condensation Humidity ©2010 CIS Corporation. All rights reserved.

  • Page 7: Camera Output Signal Specification

    : 020 ± 00Ch Digital 10bit 5 seconds shall be waited after turning on power to get proper camera operation. 4.3. CCD Spectral Response (Representative value) ※ Lens characteristics and illuminant characteristics are not considered. ©2010 CIS Corporation. All rights reserved.

  • Page 8: Function Settings

    Address 009 MSB and address 010 LSB makes 10bit in total. 524: Shutter Speed = (524.6-Data) x 15.89μs Max Data = 20Ch = 524 Positive Input Trigger Polarity Negative Input No Function Fixed. Do not change. ©2010 CIS Corporation. All rights reserved.
  • Page 9 Re-triggering at H-Synchronous Mode shall be after 2H of CCD read out signal. Re-triggering at CLK-Synchronous Mode shall be after completion of video output. Trigger pulse width shall be within the range of over 1HD to less than 1/2 sec. ©2010 CIS Corporation. All rights reserved.

  • Page 10: External Connector Pin Assignment

    6. External Connector Pin Assignment 26pins camera Link connector 12226-1100-00 PL (SUMITOMO 3M) Pin No. Pin No. DC＋12V Xclk- Xclk+ SerTC+ SerTC- SerTFG- SerTFG+ CC1- CC1+ (Trigger IN-) (Trigger IN+) CC2+ CC2- CC3- CC3+ CC4+ CC4- (GND) DC＋12V ©2010 CIS Corporation. All rights reserved.

  • Page 11: Timing Chart

    525 H Partial Scan Mode 1 18 H 310 H 345 H Partial Scan Mode 2 23 H 222 H 262 H Partial Scan Mode 3 28 H 124 H 13 H 174 H ©2010 CIS Corporation. All rights reserved.

  • Page 12: Trigger Shutter Mode

    Partial Scan Mode 3 28 H 124 H 174 H CLK- Synchronous Mode Details at Pulse Width Trigger Shutter Mode Trigger Input Signals Discharge Signals Read OUT Signals Delay Time 2.3µs Delay Time 12.0µs Exposure Time ©2010 CIS Corporation. All rights reserved.

  • Page 13: Remote Interface Function

    (Reboot the camera, and the data is reset to the initial setting.) To save the data into EEPROM, please refer to Clause 5.4. Function Setting. Note: Once the data was saved into EEPROM, it may not be reset to t he initial settings. ©2010 CIS Corporation. All rights reserved.

  • Page 14: Initial Settings

    0: Normal Shutter Mode (Trigger Shutter Mode Off) Scan Mode 0: Full Frame Scan Mode Manual Gain Control Invalid Manual Shutter Control 009&010 Invalid Trigger Polarity 0: Positive Input Output Data Select 0:8bit Output Data Trigger Reset Mode 0: H-Synchronous Mode ©2010 CIS Corporation. All rights reserved.

  • Page 15: Ccd Optical Axis Accuracy

    ?? ±0.5° The center of effective pixels shall be Within f 0.6 to the center of lens mount. (*) Dimensions from datum plane to the center of lens mount. 910-007-01-01 (Unit :mm) ©2010 CIS Corporation. All rights reserved.

  • Page 16: Dimensions

    (M2 Size) *) C Mount screws comply with ANSI/ASME B1.1, 1-32UN(2B). *) Screw length from C mount lens surface shall be under 6mm. And protruding portion shall be less than 10mm. 999-504-00-00 (Unit: mm) ©2010 CIS Corporation. All rights reserved.

  • Page 17: Cases For Indemnity (Limited Warranty)

    In case damage or losses are caused by repair or modification conducted by the customer or any unauthorized third party (such as an unauthorized service representative). Expenses we bear on this product shall be limited to the individual price of the product. ©2010 CIS Corporation. All rights reserved.

  • Page 18: Ccd Pixel Defect

    We shall be exempted from taking responsibility and held harmless for damage or malfunction of your hardware and software caused by using this control software. The purpose of this control software is for you to check operation and evaluate our products. Please be noted that CIS does not customize the program nor provide source code.
