VCC-G22U21ACL
Rev.900-612-32-00
English
UXGA B/W Camera
49MHz Pixel Clock Camera Link
VCC-G22U21ACL
Product Specification
& Operational Manual
CIS Corporation
©2009 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISION:mini VCC-G22U21ACL and is the answer not in the manual?

Questions and answers

Summary of Contents for CIS VISION:mini VCC-G22U21ACL

  • Page 1 VCC-G22U21ACL Rev.900-612-32-00 English UXGA B/W Camera 49MHz Pixel Clock Camera Link VCC-G22U21ACL Product Specification & Operational Manual CIS Corporation ©2009 CIS Corporation. All rights reserved.
  • Page 2: Table Of Contents

    9. Initial Settings ............................. 16 10. CCD Optical Axis Accuracy ........................17 11. Dimensions ............................18 12. Cases for Indemnity (Limited Warranty) ....................19 13. CCD Pixel Defect ..........................20 14. Product Support ..........................20 ©2009 CIS Corporation. All rights reserved.
  • Page 3: Scope Of Application

    AC leaks from the connected devices may cause damages or destroy the camera. Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply voltage may cause damages or malfunction of the camera. ©2009 CIS Corporation. All rights reserved.
  • Page 4 The rising time of camera power supply voltage shall be less than +10V, Max 60ms. Please avoid noises like chattering when rising. Voltage Rising Time [ ms ] In case of abnormal operation, contact the distributor from whom you purchased the product. ©2009 CIS Corporation. All rights reserved.
  • Page 5: Product Outline

    Full frame scan mode and three different partial scan modes are available. □ Approx. 20 fps at full frame scan mode. □ Only 29mm cubic in size (excluding projection), light weight 50g, and speed makes it a best match for □ use in embedded systems. ©2009 CIS Corporation. All rights reserved.
  • Page 6: Specification

    OFF (1/20), 1/50, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000, variable range 1/18000, 1/40000s ・Fixed Trigger Shutter Mode ・Pulse Width Trigger Shutter Mode Trigger shutter mode *Trigger pulse width shall be over 1H and less than 1/2s. ©2009 CIS Corporation. All rights reserved.
  • Page 7 Y, and ±Z, 6 directions. (without package) Temperature Operation guaranteed: -5℃~+45℃ Performance guaranteed: 0℃~+40℃ Operation environment RH 20~80% with no condensation Humidity Temperature -25℃ ~ +60℃ Storage environment RH 20~80% with no condensation Humidity ©2009 CIS Corporation. All rights reserved.
  • Page 8: Camera Output Signal Specification

    Digital 10bit : 3FFh output : 08 ± 03h Setup Level Digital 8bit signal : 020 ± 00Ch Digital 10bit 5 seconds shall be waited after turning on power to get proper camera operation. ©2009 CIS Corporation. All rights reserved.
  • Page 9: Ccd Spectral Response (Representative Value)

    VCC-G22U21ACL Rev.900-612-32-00 4.3. CCD Spectral Response (Representative value) ※ Lens characteristics and illuminant characteristics are not considered. ©2009 CIS Corporation. All rights reserved.
  • Page 10: Function Settings

    Address 009 MSB and address 010 LSB makes 10bit in total. 1251: Shutter Speed = (1251.6-Data) x 39.11μs Max Data = 4E3h = 1251 Positive Input Trigger Polarity Negative Input No Function Fixed. Do not change. ©2009 CIS Corporation. All rights reserved.
  • Page 11 Re-triggering at H-Synchronous Mode shall be after 2H of CCD read out signal. Re-triggering at CLK-Synchronous Mode shall be after completion of video output. Trigger pulse width shall be within the range of over 1HD to less than 1/2 sec. ©2009 CIS Corporation. All rights reserved.
  • Page 12: External Connector Pin Assignment

    Do not connect 6.2. 26pins camera Link connector 12226-1100-00 PL (SUMITOMO 3M) Pin No. Pin No. Xclk- Xclk+ SerTC+ SerTC- SerTFG- SerTFG+ CC1- CC1+ (Trigger IN-) (Trigger IN+) CC2+ CC2- CC3- CC3+ CC4+ CC4- (GND) ©2009 CIS Corporation. All rights reserved.
  • Page 13: Timing Chart

    51 H 837 H Partial Scan Mode 3 79 H 464 H 77 H 629 H * Recommended number of output lines (b line) at full frame scan mode is 1200H dividing at the center. ©2009 CIS Corporation. All rights reserved.
  • Page 14: Trigger Shutter Mode

    Partial Scan Mode 2 53 H 724 H 51 H 837 H Partial Scan Mode 3 79 H 464 H 77 H 629 H CLK- Synchronous Mode Details at Pulse Width Trigger Shutter Mode ©2009 CIS Corporation. All rights reserved.
  • Page 15: Remote Interface Function

    (Reboot the camera, and the data is reset to the initial setting.) To save the data into EEPROM, please refer to Clause 5.4. Function Setting. Note: Once the data was saved into EEPROM, it may not be reset to t he initial settings. ©2009 CIS Corporation. All rights reserved.
  • Page 16: Initial Settings

    Manual Shutter Control 009&010 Invalid Trigger Polarity 0: Positive Input Input Trigger Port Select 0: 26 pins Camera Link connector (12226-1100-00 PL) Output Data Select 0:8bit Output Data Trigger Reset Mode 0: H-Synchronous Mode ©2009 CIS Corporation. All rights reserved.
  • Page 17: Ccd Optical Axis Accuracy

    Inclination of effective pixels θ to datum plane shall be The center of effective pixels shall θ≦±0.5° be within Φ0.6 to the center of lens mount. (*) Dimension from datum plane to the center of lens mount. ©2009 CIS Corporation. All rights reserved.
  • Page 18: Dimensions

    Product Name Label Position (M2 Size) ※ C Mount screws comply with ANSI/ASME B1.1, 1-32UN (2B) ※ Screw length from C mount lens surface shall be under 6mm. And, protruding portion shall be less than 10mm. 999-482-00-00 ©2009 CIS Corporation. All rights reserved.
  • Page 19: Cases For Indemnity (Limited Warranty)

    In case damage or losses are caused by repair or modification conducted by the customer or any unauthorized third party (such as an unauthorized service representative). Expenses we bear on this product shall be limited to the individual price of the product. ©2009 CIS Corporation. All rights reserved.
  • Page 20: Ccd Pixel Defect

    We shall be exempted from taking responsibility and held harmless for damage or malfunction of your hardware and software caused by using this control software. The purpose of this control software is for you to check operation and evaluate our products. Please be noted that CIS does not customize the program nor provide source code.
