CIS VCC-12CL4R Manual

Camera link i/f 12m pixels cmos color (raw) camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-12CL4R
Rev.905-0110-01
Camera Link I/F
12M Pixels CMOS
Color (RAW) Camera
VCC-12CL4R
Product Specifications
& Operation Manual
CIS Corporation
©2018 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-12CL4R and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-12CL4R

Summary of Contents for CIS VCC-12CL4R

  • Page 1 VCC-12CL4R Rev.905-0110-01 Camera Link I/F 12M Pixels CMOS Color (RAW) Camera VCC-12CL4R Product Specifications & Operation Manual CIS Corporation ©2018 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    User Data SAVE/Read-out Function ......................... 29 11.1. Save User Data ............................29 11.2. Reading Out of User Data ........................29 Factory Settings ............................. 30 Sensor Optical Axis Accuracy .......................... 31 Dimensions ..............................32 Case for Indemnity ............................33 ©2018 CIS Corporation. All rights reserved.
  • Page 3 VCC-12CL4R Rev.905-0110-01 CMOS Pixel Defect ............................33 Product Support ............................33 Ordering Information ............................. 33 Licensing ..............................33 ©2018 CIS Corporation. All rights reserved.

  • Page 4: Handling Precautions

    Voltage Rising Time [ms] [About Heat Dissipation] CIS basically recommends you to use M42 mount or F mount lenses with VCC-12CL4R camera. Lens mount conversion rings are prepared. Using 4pcs of M4 screws at the front and fixing the camera on a metal frame also helps to dissipate heat effectively.

  • Page 5: Product Outline

    The purpose of this control software prepared is for user to check operation and evaluate our products. Please be noted that CIS does not customize the program nor provide source code.

  • Page 6: Specifications

    (100G) for ±X,±Y, and ±Z, 6 directions. (21) Operational Environment Operation guaranteed - 5 ~ +45℃ Humidity 20 ~ 80%RH With no condensation. temperature (22) Storage Environment -25 ~ +60℃ Humidity 20 ~ 80%RH With no condensation. ©2018 CIS Corporation. All rights reserved.

  • Page 7: Input And Output Signals Specifications

    (Condition: Gain 0dB) +5.0V( VCC) 100Ω FVAL Output LVAL Output DVAL Output HD74LV1GT32 ACME(RENESAS) Exposure Output Voh:3.8V(Min) Vol:0.55V( Max) 100Ω Trigger Input HD74LV1GT14 ACME(RENESAS) Vt-:0.5(Min) Vt+:1.9V(Max) IO Interface of 12pins Circular connector at rear ©2018 CIS Corporation. All rights reserved.

  • Page 8: Cmos Spectral Response ※The Lens Characteristics And Illuminant Characteristics Are Excluded

    ※ Please note that Bayer Pattern shall also flip when the output image is set to vertical flip and horizontal flip. (1) 2tap Base Configuration mode : 13.324fps 4096pixel Ｒ Ｇ ・・・ (2) 4tap Medium Configuration mode : 26.674fps 4096pixel Ｒ Ｇ Ｒ Ｇ ・・・ ©2018 CIS Corporation. All rights reserved.
  • Page 9 (3) 8tap Full, 8tap10bit Configuration mode : 53.294fps 4096pixel Ｒ Ｇ Ｒ Ｇ Ｒ Ｇ Ｒ Ｇ ・・・ (4) 10tap8bit Configuration mode : 62.984 fps 4100pixel Ｒ Ｇ Ｒ Ｇ Ｒ Ｇ Ｒ Ｇ Ｒ Ｇ ・・・ 9 10 ©2018 CIS Corporation. All rights reserved.

  • Page 10: Camera Function Settings

    Output Image Horizontal Flip Normal When in operation, the cursor is reset Horizontal flip to (0, 0). Output Image Vertical Flip Normal When in operation, the cursor is reset Vertical flip to (0, 0). ©2018 CIS Corporation. All rights reserved.
  • Page 11 Vertical Partial (Lump Settings) The 1 parameter: Partial number (0~7) parameters The 2 parameter: Start line (0~2996 per 4 lines) The 3 parameter: Effective line numbers (4~3000 per 4 lines) Specify the partial numbers (0~7). parameter acquisition ©2018 CIS Corporation. All rights reserved.

  • Page 12: The List Of Preset Shutter

    1/1000 1/1000 1/2000 1/2000 1/2000 1/2000 1/2500 1/2500 1/2500 1/2500 1/5000 1/5000 1/5000 1/5000 1/10000 1/10000 1/10000 1/10000 1/16000 1/20000 1/20000 1/20000 1/26000 1/26000 1/30000 1/29000 1/38000 1/38000 1/40000 ↑ 1/49000 1/51000 ↑ ↑ ©2018 CIS Corporation. All rights reserved.

  • Page 13: Formula To Calculate Manual Shutter Values

    Please note that a dummy trigger is needed at trigger mode. ※ When camera mode (Tap mode) is changed, please re-set other functions, too. ※ When gain is set to over +36dB, image quality deterioration is inevitable. Please evaluate first. ©2018 CIS Corporation. All rights reserved.

  • Page 14: External Connector Pin Assignment

    VCC-12CL4R Rev.905-0110-01 External Connector Pin Assignment 6.1. 12pins Circular Connector HR10-10R-12PA(73) (HIROSE) or equivalent Pin No. Description Power input (DC+12V) LVAL output FVAL output Exposure output DVAL output TRIGGER input ©2018 CIS Corporation. All rights reserved.

  • Page 15: Camera Link Connector 12226-1100-00Pl (Sumitomo 3M)

    ※ There is a mode that exceed the power consumption standard value (4.0W) of PoCL (×1 cable) power feeding. We recommend to feed the power via both CL1 and CL2 at PoCL, or use 12pins circular connector. ©2018 CIS Corporation. All rights reserved.

  • Page 16: Timing Chart

    Video Out FVAL Out LVAL Out DVAL Out V Blanking : 62H Effective Line : 3000H Appr 1Frame = 3062H 56Ｈ SP Out(Exposure Out) Exposure Time 1H = 24.512us 2Tap Configuration mode : 13.324fps ©2018 CIS Corporation. All rights reserved.

  • Page 17: Horizontal Sync. Timing (4Tap Configuration Mode)

    Video Out FVAL Out LVAL Out DVAL Out V Blanking : 62H Effective Line : 3000H Appr 1Frame = 3062H 56Ｈ SP Out(Exposure Out) Exposure Time 1H = 12.256us 4Tap Configuration mode : 26.647fps ©2018 CIS Corporation. All rights reserved.

  • Page 18: Horizontal Sync. Timing (8Tap Configuration Mode)

    Video Out FVAL Out LVAL Out DVAL Out V Blanking : 62H Effective Line : 3000H Appr 1Frame = 3062H 56Ｈ SP Out(Exposure Out) Exposure Time 1H = 6.128us 8Tap Configuration mode : 53.294fps ©2018 CIS Corporation. All rights reserved.

  • Page 19: Horizontal Sync. Timing (10Tap Configuration Mode)

    Video Out FVAL Out LVAL Out DVAL Out V Blanking : 62H Effective Line : 3000H Appr 1Frame = 3062H 56Ｈ SP Out(Exposure Out) Exposure Time 1H = 5.185us 10Tap Configuration mode : 62.984fps ©2018 CIS Corporation. All rights reserved.

  • Page 20: Fixed Trigger Shutter Mode

    Effective Line Video Out Exposure Out Exposure Time LVAL Out DVAL Out FVAL Out Effective Line : 3000H Exposure Time Delay Trigger input ignore period TRIG IN Exposure Out (SP Out) Exposure time delay ©2018 CIS Corporation. All rights reserved.

  • Page 21: Fast Fixed Trigger Shutter Mode

    Next trigger rise prohibited period : 3082H Exposure Out Exposure Time LVAL Out DVAL Out FVAL Out Effective Line : 3000H Exposure Time Delay Trigger input ignore period TRIG IN Exposure Out (SP Out) Exposure time delay ©2018 CIS Corporation. All rights reserved.

  • Page 22: Pulse Width Trigger Shutter Mode

    Exposure Out Exposure Time LVAL Out DVAL Out FVAL Out Effective Line : 3000H Exposure Time Delay① Exposure Time Delay② Trigger input ignore period TRIG IN ① ② Exposure Out (SP Out) Exposure time delay ©2018 CIS Corporation. All rights reserved.

  • Page 23: Fast Pulse Width Trigger Shutter Mode

    Exposure Out Exposure Time LVAL Out DVAL Out FVAL Out Effective Line : 3000H Exposure Time Delay① Exposure Time Delay② Trigger input ignore period TRIG IN ① ② Exposure Out (SP Out) Exposure time delay ©2018 CIS Corporation. All rights reserved.

  • Page 24: Partial Scan Mode

    Partial effective line 1 + Partial effective lines 2 + ・・・ + Partial effective lines 8 Please note that sum total of partial effective line count from 1 ~ 8 (except V blanking line) has to be less than 3000. V blanking line at partial mode is 62H. ©2018 CIS Corporation. All rights reserved.
  • Page 25 Especially at fixed trigger shutter mode and pulse width trigger shutter mode, input a dummy trigger first, and use the next trigger as an actual video signal. ©2018 CIS Corporation. All rights reserved.

  • Page 26: Serial Communication Function

    [¥r] [¥n] [Linefeed] [sp]=Space(0x20) [Returned value] >[sp] [Prompt + Space] 【Example of Set Command】 To set 30 to the address 21 [Send] SU[sp]21[sp]30[¥r]or[¥n] [Returned value] [¥r] [¥n] [Linefeed] [Returned value] >[sp] [Prompt + Space] ©2018 CIS Corporation. All rights reserved.

  • Page 27: Defective Pixel Correction

    The number of data that can be registered by user is 256. (Note: Up to 32 points per CH.) □ [CH (Channel)] Images are processed by 8 CH interleave in the camera. (0,0) (1,0) (2,0) (3,0) (4,0) (5,0) (6,0) (7,0) (0,1) (1,1) (2,1) (3,1) (4,1) (5,1) (6,1) (7,1) ©2018 CIS Corporation. All rights reserved.
  • Page 28 This is the function to delete the defective pixel data detected and registered by the users with specifying their coordinate. There are two parameters for commands. The First Parameter: X Coordinate The Second Parameter: Y Coordinate ©2018 CIS Corporation. All rights reserved.
  • Page 29 ・X coordinate and Y coordinate shown are the one for the current image. When vertical partial (SU50, 54), horizontal flip (SU 11), or vertical flip (SU 12) is changed, the coordinates to be indicated shall be changed accordingly. ©2018 CIS Corporation. All rights reserved.

  • Page 30: User Data Save/Read-Out Function

    Data are shown with hexadecimal with space partitions. When data count more than the address are specified, error would occur and it would not be read out. 【Send】GU[sp]200[sp]Readout address[sp]Readout count 【Returned value】0xnn[sp]0xnn[sp]0xnn[sp][¥r][¥n] 【Returned value】>[sp] ©2018 CIS Corporation. All rights reserved.

  • Page 31: Factory Settings

    Vertical Flip of the Output Image Normal Defective Pixel Correction Serial Communication Baud Rate 9600baud Black Level Settings Gain Shutter White Balance Through Vertical Partial Mode OFF (3000line) Factory setting for rear switch Power Selection CL side ©2018 CIS Corporation. All rights reserved.

  • Page 32: Sensor Optical Axis Accuracy

    VCC-12CL4R Rev.905-0110-01 13. Sensor Optical Axis Accuracy ©2018 CIS Corporation. All rights reserved.

  • Page 33: Dimensions

    VCC-12CL4R Rev.905-0110-01 14. Dimensions ©2018 CIS Corporation. All rights reserved.

  • Page 34: Case For Indemnity

    If you use the product properly and discover a defect during the warranty period, and if that was caused by designing or manufacturing, CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge.
