Installation Steps
DANGER of Death, Injury or Property Damage if procedure not followed. Dead front removal is required for this installation. Power to the OmniLogic
panel MUST be shut off before the dead front is removed. This means a complete shutdown of power to the entire OmniLogic panel.
Details on each installation step are presented on the following pages:
1. Mounting the equipment (page 4)
OmniLogic main unit
Temperature sensors
Remote display/keypad (optional)
Valve actuators (if applicable)
2. Plumbing (page 6)
General Pool Equipment
TurboCell
Flow Switch
3. Electrical Wiring (page 10)
Main service
Grounding and bonding
Circuit breakers
OmniLogic power
High Voltage pool equipment
Low voltage wiring (temperature sensors, flow switch, etc.)
4. Prepare the pool water (page 20)
General Water Chemistry
Salt
5. System Startup and Firmware Upgrade (page 22)
NOTE: If replacing a Pro Logic Controller using networked ColorLogic Lights, the lights must be put into "Standalone" (default) mode before disconnecting the
Pro Logic. The OmniLogic can only control ColorLogic lights in "Standalone" mode.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
3
