What's Included

Before attempting to install the OmniLogic system, check that the following components have been included in the package:

•

OmniLogic Electronics Unit

•

(3) Temperature sensors with 15 ft. (5m) cable, hose clamp

What's NOT Included

Some of the additional items that you may need to complete an installation include:

Circuit breakers - None are included with control—see page 11 and inside door label for suitable breakers

Wire

4-conductor cable for connection to optional wired terminal(s)

Wire/conduit for 100A service from main panel to OmniLogic

Wire/conduit for filter pump and other high voltage loads

Wire for remote heater control and other low voltage devices

Wire for bonding

Miscellaneous

Optional utility electrical outlet and weatherproof cover (for mounting on lower right side of OmniLogic)

Mounting hardware (screws, bolts, etc.) for mounting OmniLogic and remote terminals

Valve Actuators (to automate valve functions)

Accessory Products - Order Separately

HLEXPAND

Expansion Panel

HLH485RELAY

Smart Relay

HLRELAYBANK

Additional relay pack adds 4 high voltage relays

HLRELAY

Single high voltage relay kit

HLIOEXPAND

Input/Output Expander Board adds 4 additional sensor/external inputs, 4 heater/low voltage outputs, and 4 actuator outputs

HLWLAN

Wireless home network connectivity - eliminates the need to hard wire the OmniLogic to the home's router/access point

HLWALLMOUNT

Wired Wall Mount Remote Terminal

HLWIRELESS

Portable Wireless Remote Terminal

HLSPASIDE

Wired Spa Remote

HL-CHEM

ORP & pH Sensing Kit for monitoring and controlling pool chemistry

AQL-CHEM2

TCELLS340

Chlorinator Cell - generates chlorine for pools up to 40k gallons

TCELLS325

Chlorinator Cell - generates chlorine for pools up to 25k gallons

TCELLS318

Chlorinator Cell - generates chlorine for pools up to 18k gallons

TCELLS315

Chlorinator Cell - generates chlorine for pools up to 15k gallons

P-KIT

Chlorination plumbing kit containing flow switch and cell unions

HL-CHEM4-ACID

Liquid acid feeder

HL-CHEM4-CHLOR

Liquid chlorine feeder

CL200

Chlorine tablet feeder

GVA-24

Valve Actuator

V&A-xx

Valve & Actuator (xx=1P (1.5" pos. seal), -2P (2" pos. seal)

NOTE: Before installing this product as part of a saline water purification system in a pool or spa using natural stone for coping or for immediately adjacent

patios/decking, a qualified stone installation specialist should be consulted regarding the appropriate type, installation, sealant (if any) and maintenance of stone

used around a saline pool with an electronic chlorine generator in your particular location and circumstances.

NOTE: The use of dry acid (sodium bisulfate) to adjust pool pH is discouraged especially in arid regions where pool water is subject to excessive evaporation and

is not commonly diluted with fresh water. Dry acid can cause a buildup of by-products that can damage your chlorinator cell.

The functions and features described in this manual assume that the OmniLogic is using the latest firmware version available from Hayward. The OmniLogic

HLBASE is a multifunction pool automation control that is expandable to meet all your needs and fully manage your pool/spa system. The OmniLogic can control

pumps, valves, lighting, heaters, pool chemistry and more. It offers the next generation of technology to manage pool/spa equipment and the backyard experi-

ence. Using a touchscreen interface and network connectivity, the OmniLogic gives the user complete control over both automation and chlorination of their pool

and spa.Although the OmniLogic is easy to use, it is important to completely read through this manual before attempting to install, configure or operate the unit.
