Shared Equipment - Hayward OmniLogic HLBASE Installation Manual

Accessory Wired to Relay? Select whether the accessory requires the use of a high voltage relay.
If Yes is selected:
Select Relay - Touching the box will bring you to a table showing all detected relays. Select the relay that is connected to the acces-
sory and touch the Done button. The relay should now be shown in the box and you can advance to the next screen to continue the
accessory configuration.
Does Accessory have a Valve? Select whether the accessory requires a valve to change position when in use.
If Yes is selected:
How Many? Select how many valves are used for the accessory.
Where is the Valve(s) Wired? Selecting the box will bring you to a table showing all detected low voltage relays. Select the relay(s)
that is wired to the accessory valve(s), then advance. The valve(s) should now be shown in the box. Advance to the next screen to
continue accessory configuration.
Freeze Protection Enabled? Freeze protection is used to protect the pool and plumbed equipment against freeze damage during cold tem-
peratures. If freeze protection is enabled AND the air temperature falls below the freeze threshold (refer to pump configuration), the OmniLogic
will turn on the accessory pump to circulate the water.
If Yes is selected:
Freeze Protect Speed? This is the speed of the pump while freeze protection is active. Select the desired pump speed %. NOTE:
this option only appears if the pump is a two speed pump or a variable speed pump.
Would You Like To Configure A Default Startup Speed For the Accessory? If the accessory has a valve and the system uses a VSP filter
pump, the OmniLogic allows you to set a startup pump speed for the accessory, regardless of the pump's schedule. The speed will change at
the next scheduled interval.
NOTE: The following configuration settings are specific to the second Body of Water regarding Shared Equipment and Dual Equipment with shared heaters setup.
As you advance through the second Body of Water's configuration settings, note that most of the questions asked are the same as the first Body of Water with
the exception of the following:
Does Body of Water 2 share its equipment with Body of Water 1?
If Yes is selected:
Your system will be "fully shared" which means your filter pump/heaters/chemistry will be shared between both Bodies of Water. You can now set your
filter pump and heater settings for this body of water.
If No is selected:
You will begin dual equipment setup for you second Body of Water. This means that your filter pump and chemistry will not be shared between both
Bodies of Water, but you will still have the option of configuring shared heaters and spillover. You can now configure a filter pump and heaters for this
body of water.
Are any of Body of Water 2's heaters shared with Body of Water 1?
If Yes is selected:
Which body of water is heated in the event that both are running? Select the Body of Water that you would like to have heating priority if both
Bodies of Water are running. This question only appears if you have a Pool/Pool or Spa/Spa setup. If you have a Pool/Spa setup, then the Spa Body
of Water will automatically have heating priority.
Select Shared Heater Valves - Select Body of Water 1's return valve, Body of Water 2's return valve, and the Heater return valve in your system.
The selections will also affect spillover operation.
Select the heaters you wish to share - Select the heaters that you configured in Body of Water 1 that you would like to be shared with Body of
Water 2 and press advance.
Does this body of water have any additional heaters? Select whether you have any additional heaters in Body of Water 2 that you would like to
configure that are not shared with Body of Water 1.
Do you have Spillover? Select yes to this question if you have Spillover in your system. If yes is selected, choose the valves that will operate Spillover from
the following screen.
