If Yes is selected:
What Kind of Lights? Touch the box to select the type of lights that will be used. The options are UCL (14V), CL4.0 (115V), CL2.5 (14V), Wa-
terBowl, P-Color, Z-Color, Incandescent, and Other.
Name the Group of Lights - Touch the box and use the keyboard to name the lights.
How Many Relays are Lights Wired to? Select the number of relays used by the lights.
Which Relay is it Wired to? Touching the box(es) will bring you to a table showing all detected relays. Select the relay(s) that are connected to
the lights. If the lights are connected to a Smart Power Transformer, select the zone(s) that the lights are wired to. Once the relay(s) are selected,
touch the Done button.The relay(s) should now be shown in the box(es) and you can advance to the next screen to continue the configuration.
If UCL or WaterBowl was previously selected:
Would you like to test for OmniDirect capability? For UCL lights manufactured after June 2018, you can select Yes and the
OmniLogic will test your lights to confirm. If your lights blink white after the test, you can enable OmniDirect mode. If not, the UCL light
will default to UCL Standalone mode. Note that if you are configuring a WaterBowl light, the Flicker feature will only be available if the
light is set to OmniDirect mode.
How Many Accessories? Select the number of accessories that will be used for this Body of Water only. You'll have an opportunity to configure acces-
sories for the spa and also the backyard at a later point.
If "1"or more is selected:
Select and Configure Accessories At this screen you can add, delete and configure your accessories. Select the desired accessory, then
touch the Advance button. When finished configuring accessories, you'll be returned to this same screen. Touch the Done button and advance
to the next section of configuration. Refer to the following information when configuring accessories:
Type of Accessory? Touch the box and select the type of accessory used. Choices are Laminars, Jets, Blower and Other.
Name of Accessory - Touch the box and use the keyboard to name the accessory.
Does Accessory Have a Pump? Select whether the accessory has a dedicated pump. If so, the OmniLogic will turn this pump on when the
accessory is scheduled to run.
If Yes is selected:
What Type? Select the type of pump used. The choices are Single Speed, Two Speed and VSP.
If single speed or two speed pump is selected:
Which Relay is it Wired to? If using a single speed or two speed pump, you'll be asked which relay(s) is wired to the
pump. If a value is already shown in the box(es), advance to the next screen. If no value is shown, selecting the box will bring
you to a table showing all detected relays. Select the proper relay(s) from the table and touch the Done button. The relay(s)
should now be shown in the box(es) and you can advance to the next screen to continue the pump configuration.
Would You Like to Enable Priming? Select whether you want the pump to prime when turned on. This will turn the pump
on at high speed for 3 minutes to establish normal water flow every time the pump is activated after being off for at least 30
seconds. This option only appears if the pump is configured as a 2-Speed pump.
If VSP is selected:
Which Hayward Unique Address? If using a VSP for your accessory pump, you'll be asked what is the Hayward Unique
Address (HUA). If a value is already shown in the box, advance to the next screen. If no value is shown, selecting the box
will bring you to a table showing all detected devices. Select the proper HUA from the table and touch the Done button. The
address should now be shown in the box and you can advance to the next screen to continue the VSP configuration.
Pump Capacity - Set the minimum and maximum RPM of the pump. Refer to your pump manual for more information.
Permitted User Setting - The OmniLogic will automatically calculate these values based on the minimum and maximum
RPM that were previously entered. They can be changed as desired.
Speed Presets - Set the Low Pump Speed %, Medium Pump Speed %, and High Pump Speed %, presets. These presets
will be used when setting schedules for your pump.
Would You Like to Enable Priming? Select whether you want the pump to prime when turned on. This will turn the
pump on at high speed for a set duration to establish normal water flow every time the pump is activated after being off for
at least 30 seconds.
