If TurboCell model is selected (requires a connected Hayward TurboCell or AquaRite with HLAQRPCB communication board):
Select Salt Monitoring Level - Select Standard Salt or Low Salt. If running the system using a low salt level (1200 PPM-
1800 PPM, 1500 PPM optimal) select Low Salt. If running the system using standard salt level (2700 PPM - 3400 PPM,
3200 PPM optimal), select Standard Salt.
Where is the Cell Located? If an entry is already shown in the box, touch the Advance button. If no entry is shown, select-
ing the box will bring you to a table showing the detected cells. The OmniLogic will detect a directly connected TurboCell
and/or a TurboCell that is connected to an AquaRite (requires HLAQRPCB communication board). The table will display "Main
Panel" under device type for directly connected TurboCells and "AquaRite", if a AquaRite is used.
If Liquid Chlorinator is selected:
Select Relay - Selecting the box will bring you to a table showing all HV relays. Find the relay that is connected to the Liquid
Chlorinator. Select the relay and select Done.
If Tablet Feeder is selected:
Where is the Valve Wired? - Selecting the box will bring you to a table showing all valve outputs. Find the valve that is
connected to the Tablet Feeder. Select the valve and select Done.
If No is selected:
Do You Have a Salt Water Chlorine Generator? (requires a connected Hayward TurboCell or AquaRite with HLAQRPCB communica-
tion board)
If Yes is selected:
Type of Cell? Select the type of Hayward TurboCell that is installed in your system.
Where is the Cell Located? If an entry is already shown in the box, touch the Advance button. If no entry is shown, select-
ing the box will bring you to a table showing the detected cells. The OmniLogic will detect a directly connected TurboCell
and/or a TurboCell that is connected to an AquaRite (requires HLAQRPCB communication board). The table will display "Main
Panel" under device type for directly connected TurboCells and "AquaRite", if a AquaRite is used.
Percentage of Output - The OmniLogic can only generate chlorine while the filter pump is operating. Set the percentage of
run time that you desire chlorine generation. Raise this value to generate more chlorine. Lower this value to generate less.
Is pH Reduction Enabled? Select Yes if you have a dispenser to lower pH connected to the OmniLogic.
If Yes is selected:
Are you Using Acid or CO2? Select one.
How Many Acid/CO
Which relay is it Wired to? Select the box to advance to the High Voltage Table. This table lists all of the high voltage relays that are
installed in the OmniLogic. Select the relay that is wired to the pH dispense unit. Refer to the Connection Table for this information.
pH Setpoint - Selecting the box will allow you to change the setpoint (7.5 default). Touch the Advance button when finished.
pH Dispensing Timeout - Select a timeout interval. If the unit has been dispensing for more than the selected timeout without reach-
ing the desired level, pH dispensing will turn off and an alarm will be displayed. Check the chemical supply and the feeder. If both are
OK, the timeout may need to be increased. The user must clear the alarm to resume pH dispensing.
pH Extend Enabled - If enabled, the OmniLogic will continue to run the filter pump regardless of schedule until the pH level in the
pool has reached the setpoint.
How Many Cleaners? - This question is for THIS BODY OF WATER ONLY. For example: If you have 2 cleaners; one for the pool Body of Water and one for
the spa Body of Water, you would answer "1" to this question.
If "1"or more is selected:
Select and Configure a Cleaner At this screen you can add, delete and configure your cleaner(s). Select the desired cleaner, then touch the
Advance button. When finished configuring cleaner(s), you'll be returned to this same screen. Touch the Done button to advance to the next
section of configuration. Refer to the following information when configuring cleaner(s):
Type of Cleaner? Touch the box and select the type of cleaner used. Choices are Pressure, Suction, Robotic and In-Floor.
Name of Cleaner - Touch the box and use the keyboard to name the cleaner.
Dispensers? Select the number of Acid/CO
2
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
dispensers in your system.
