Name - Rename the group of lights to whatever name is desired.
Type - Select the type of lights configured.
Relay - Select the relay(s) that the group of lights is wired to. If using a Smart Power Transformer, select the zone(s) that the lights are wired
to.
Set Mode - Set the mode of the lights configured.
OmniDirect - If UCL was previously selected, this button will appear and allow you to test whether your UCL lights are OmniDirect compatible
(lights built after June 2018). Note that if you are configuring a WaterBowl light, the Flicker feature will only be available if the light is set to
OmniDirect mode.
Delete an Existing Group of Lights - From this screen, if you wish to delete a group of lights that is currently configured, select the group and
then select the trash can button next to it.
If Accessories is selected:
Add Accessory - Pressing "Add Accessory" from this screen will take you through the full configuration for adding a new accessory to the
Backyard. These steps are described in the Configuration Wizard portion of this manual.
Select an Accessory - Once you select an accessory, all of the options for that Backyard accessory will appear on the next screen. These
options are as follows:
Name - Rename the accessory to whatever name is desired.
Relay - Select the relay that the accessory is wired to.
Delete an Accessory - From this screen, if you wish to delete an accessory that is currently configured, select the trash can on the right of the
name of the accessory that you wish to delete.
NOTE: The system does not allow you to configure a pump or a valve to accessory equipment in the Backyard.
If Sensors is selected:
Add Sensor - Pressing "Add Sensor" from this screen will take you through the full configuration for adding a new sensor. These steps are described in
the Configuration Wizard portion of this manual.
Select a Sensor - Once you select a sensor, all of the options for that sensor will appear on the next screen. These options are as follows:
Name - Rename the sensor to whatever name is desired.
Location - Select the location that the sensor is wired to.
Delete a sensor - From this screen, if you wish to delete a sensor that is currently configured, select the trash can on the right of the name of the sensor
that you wish to delete.
If Interlocks is selected:
Add Interlock - Pressing "Add Interlock" from this screen will take you through the full configuration for adding a new interlock. These steps are described
in the Configuration Wizard portion of this manual.
Select an Interlock - Selecting an interlock from this screen will allow you to view that interlock's configuration. However, you cannot edit a pre-existing
interlock. In order to change an interlock's configuration, you have to delete the obsolete interlock and create a new one.
Delete an Interlock - From this screen, if you wish to delete an interlock that is currently configured, select the trash can on the right of the name of the
interlock that you wish to delete.
NOTE: If there are currently no interlocks configured on your system, then the button will appear as "Add Interlock" instead of "Interlocks". In this case,
pressing "Add Interlock" will take you through the full configuration for adding a new interlock. These steps are described in the Configuration Wizard por-
tion of this manual. Once an interlock has been created, the button will say "Interlocks".
If System Options is selected:
Modify Network Setup - Press this button to modify or setup a wired or wireless connection.
Would you like to set up a network Connection now? Select the type of connection you would like to setup/modify or select "Not Now". For wireless
connections, you must have a Hayward HLWLAN connected to the OmniLogic.
