Select a Heater/Chiller - Once you select a heater/chiller, all of the options for that heater/chiller will appear on the next screen. These
options are as follows:
Name - Rename the heater/chiller to whatever name you desire.
HUA - Select the HUA of the Smart Heater. This option only appears if a Smart Heater is configured.
Type - Select the type of heater that is configured (Solar, Heat Pump, Gas, Geothermal, Electric).
Relay - Select the relay that the heater/chiller is wired to. Option not available for Solar heaters.
Valve - Configure the heating/cooling valve, if used.
Min Filter Speed - Select the minimum speed that the Filter Pump will run while the heater/chiller is active.
Min Air Temperature - Select the minimum air temperature that the heater will be allowed to run at. This option is only available if the
heater is configured as a Heat Pump.
Priority Duration - Select the number of hours that this heater/chiller will run before the next priority heater/chiller turns on.
Pump - Configure the boost pump for the heater. This option is only available if the heater is configured as a Solar heater.
Solar Sensor - Configure the solar sensor. This option is only available if the heater is configured as a Solar heater.
Require Priming - Configure whether or not the filter pump will turn on for 3 minutes to prime during solar heating.
Delete a Heater/Chiller - From this screen, if you wish to delete a heater/chiller that is currently configured, select the trash can on the
right of the name of the heater/chiller that you wish to delete.
If Chemistry is selected:
pH - Once you select pH, all of the options for pH dispensing will appear on the next screen. These options are as follows:
Reduction ON - Select whether you want pH reduction to be enabled.
Chemical Type - Select the type of chemical that is being dispensed (acid or CO
pH Dispensers - Configure the pH dispense unit.
pH Timeout - Choose the pH timeout time.
pH Extend - Select whether you want pH extend enabled for this Body of Water.
Chem Sense Module - Once you select Chem Sense Module, you will be able to select the HUA of your Chem Sense Module you are using
from the next screen.
Chlorination - A flow switch must be installed for this function. Once you select Chlorination, all of the options for chlorination will appear
on the next screen. These options are as follows:
Dispenser Type - Select the type of dispenser used (T-CELL model, liquid chlorinator or tablet feeder).
Dispenser Relay or Valve - Depending on your dispenser type, select the output that controls the dispenser.
ORP Timeout - Choose the ORP timeout time and desired ORP setpoint. This option is only available if ORP controls chlorination.
Delete Chem Sense Module/Chlorination - From this screen, if you wish to delete any currently configured chemistry options, select the
trash can on the right of the name of the item that you wish to delete.
NOTE: If either pH dispensing or chlorination are not configured, then this screen will give you the option to "Add CSM" or "Add Chlorination."
If either of those options are selected, then you will be taken through the full configuration for that equipment as appears in the Configuration
Wizard portion of this manual.
If Cleaners is selected:
Add Cleaner - Pressing "Add Cleaner" from this screen will take you through the full configuration for adding a new cleaner. These steps
are described in the Configuration Wizard portion of this manual.
