Freeze Protection Enabled? Freeze protection is used to protect the pool and plumbed equipment against freeze damage during
cold temperatures. If freeze protection is enabled AND the air temperature falls below the freeze threshold, the OmniLogic will turn
on the filter pump to circulate the water. If two Bodies of Water are configured, the valves will also alternate between the pool and spa
every 30 minutes and the filter pump will turn off while the valves are turning. The chlorinator will not operate if freeze protection is
the only reason the pump is running.
If Yes is selected:
Freeze Protect Temperature? Select the temperature to be used for freeze protection. Temperature is adjustable from
33ºF-42ºF (1ºC-6ºC). 38ºF (3ºC) is default. This threshold will be used for all outputs that have freeze protection enabled.
Freeze Protect Speed? This is the speed of the pump while freeze protection is active. Select the desired pump speed
%.
How many Heaters? This question is for THIS BODY OF WATER ONLY. For example: If you have 2 heaters, one for the pool Body of Water and one for the
spa Body of Water, you would answer "1" to this question. Note that you can have a maximum of 5 heaters/chillers per Body of Water.
If "1"or more is selected:
Heater Cooldown Enabled? This feature ensures that the heater cools down before water circulation is stopped. When enabled, the Omni-
Logic will continue to run the filter pump for 5 minutes after the heater turns off.
Heater Extend Enabled? If "Enabled", the filter extend logic keeps the filter pump running beyond the normal turn-off time until the pool (or
spa) is heated up to the desired temperature setting. Heater extend will NOT cause the filter pump to turn on, it will only delay the turn off time
when the heater is operating.
Settable Water Temperature Range? This is the maximum and minimum allowed settings for heating and/or cooling.
Select and Configure a Heater At this screen, you can add, delete and configure your heater(s). Select the desired heater, then touch the
Advance button. When finished configuring heater(s), you'll be returned to this same screen. Touch the Done button and advance to the next
section of configuration. Refer to the following information when configuring heater(s):
Do you want to configure a Smart Heater? This option only appears if you have a heater with OmniLogic remote control capability connected
to your OmniLogic and powered on. Select "Yes" if you would like to configure this heater now or "No" if you would like to configure a different
heater.
If Yes is selected:
Which Hayward Unique Address? Select the HUA of the Smart Heater that you would like to configure.
Name Heater Select the box, then type the desired name for your heater. This name will be used when referring to this particular
heater.
Does Heater Have a Valve? Select whether or not the heater has an associated valve that will turn on when the heater is activated.
If Yes is selected, the following screen will ask where the valve is wired (refer to Connection Table for this information).
Minimum Allowed Air Temperature for Heater? If the air temperature falls below this setting, the heater will be prevented from
running, regardless of conditions. This feature is especially useful for heat pumps which become less efficient as the outdoor ambient
temperature falls.
Minimum Operation Speed? For variable speed pumps, select the lowest pump speed that is allowed while heating. Set a speed
that will ensure that there will be sufficient flow for the heater to operate properly. For two speed pumps, you can select if you want to
allow the filter pump to run at low speed during heater operation.
What Type? Heater choices are Solar, Heat Pump, Gas, Geothermal, and Electric. Make your selection and advance.
If Gas or Electric Heater is selected:
Name Heater Select the box, then type the desired name for your heater. This name will be used when referring to this particular
heater.
Which Relay is it Wired to? Selecting the box will bring you to a table showing all detected relays. Select the low voltage relay that
is wired to the heater (refer to the Connection Table for this information), then advance. The relay should now be shown in the box.
Advance to the next screen to continue gas heater configuration.
Does Heater Have a Valve? Select whether or not the heater has an associated valve that will turn on when the heater is activated.
If Yes is selected, the following screen will ask where the valve is wired (refer to Connection Table for this information).
