If Yes is selected:
What Type? Select the type of pump used. The choices are Single Speed, Two Speed and VSP.
If single speed or two speed pump is selected:
Which Relay is it Wired to? If using a single speed or two speed pump, you'll be asked which relay(s) is wired to the
pump. If a value is already shown in the box(es), advance to the next screen. If no value is shown, selecting the box will bring
you to a table showing all detected relays. Select the proper relay(s) from the table and touch the Done. The relay(s) should
now be shown in the box(es) and you can advance to the next screen to continue the pump configuration.
Would You Like to Enable Priming? Select whether you want the pump to prime when turned on. This will turn the pump
on at high speed for a set duration to establish normal water flow every time the pump is activated after being off for at least
30 seconds. This option only appears if the pump is configured as a 2-Speed pump.
If VSP is selected:
Which Hayward Unique Address? If using a VSP for your water feature pump, you'll be asked what is the Hayward
Unique Address (HUA). If a value is already shown in the box, advance to the next screen. If no value is shown, selecting the
box will bring you to a table showing all detected devices. Select the proper HUA from the table and touch the Done button.
If unsure of the HUA, refer to the pump's manual for instructions on how to determine the pump's HUA. Once selected, the
address should now be shown in the box and you can advance to the next screen to continue the VSP configuration.
Pump Capacity - Set the minimum and maximum RPM of the pump. Refer to your pump manual for more information.
Permitted User Setting - The OmniLogic will automatically calculate these values based on the minimum and maximum
RPM that were previously entered. They can be changed as desired.
Speed Presets - Set the Low Pump Speed %, Medium Pump Speed %, and High Pump Speed %, presets. These presets
will be used when setting schedules for your pump.
Would You Like to Enable Priming? Select whether you want the pump to prime when turned on. This will turn the
pump on at high speed for a set duration to establish normal water flow every time the pump is activated after being off for
at least 30 seconds.
Water Feature Wired to a Relay? Select whether the water feature requires the use of a high voltage relay.
If Yes is selected:
Select Relay - Touching the box will bring you to a table showing all detected relays. Select the relay(s) that is connected to the water
feature and touch the Done button. The relay should now be shown in the box and you can advance to the next screen to continue
water feature configuration.
Does Water Feature have a Valve? Select whether the water feature requires a valve to change position when in use.
If Yes is selected:
How Many? Select how many valves are used for the water feature.
Where is the Valve(s) Wired? Selecting the box will bring you to a table showing all detected low voltage relays. Select the relay(s)
that is wired to the water feature valve(s), then advance. The valve(s) should now be shown in the box. Advance to the next screen to
continue water feature configuration.
Freeze Protection Enabled? Freeze protection is used to protect the pool and plumbed equipment against freeze damage during cold tem-
peratures. If freeze protection is enabled AND the air temperature falls below the freeze threshold (refer to pump configuration), the OmniLogic
will turn on the water feature pump to circulate the water.
If Yes is selected:
Freeze Protect Speed? This is the speed of the pump while freeze protection is active. Select the desired pump speed %. NOTE:
this option only appears if the pump is a two speed pump or a variable speed pump.
Would You Like To Configure A Default Startup Speed For Water Feature? If the water feature has a valve and the system uses a VSP filter
pump, the OmniLogic allows you to set a startup pump speed for the water feature, regardless of the pump's schedule. The speed will change
at the next scheduled interval.
Do You Want to Configure Any Lights? Select yes if you are using any type of pool or spa lights. The options are Universal ColorLogic (UCL), ColorLogic
4.0 (CL4.0), ColorLogic 2.5 (CL2.5), WaterBowl, Pentair Color LED (P-COLOR), Jandy Color LED (Z-Color), Incandescent, and Other. Transformers powering
Universal ColorLogic lights must all be connected to the same high voltage relay for synchronization to function properly. If using OmniDirect mode, you
must use an internal relay, not an HLRELAYBANK.
