Heater Priority Duration? This question will appear of more than one heater is configured. Set the amount of time that you will allow
the priority heater to heat before allowing the next heater to start. If the priority heater meets the demand within this time frame, the
next heater will not be used. Note that a time interval setting of "0" will eliminate priority and always run both heaters at the same time.
If a time interval setting of "24" is selected, the next priority heater will not turn on until the first priority heater becomes invalid to run.
Minimum Operation Speed? For variable speed pumps, select the lowest pump speed that is allowed while heating. Set a speed
that will ensure that there will be sufficient flow for the heater to operate properly. For two speed pumps, you can select if you want to
allow the filter pump to run at low speed during heater operation.
If Heat Pump or Geothermal is selected:
Name Heater Select the box, then type the desired name for your heater. This name will be used when referring to this particular
heater.
Which Relay is it Wired to? Selecting the box will bring you to a table showing all detected relays. Select the low voltage relay that
is wired to the heater (refer to the Connection Table for this information), then advance. The relay should now be shown in the box.
Advance to the next screen to continue heat pump configuration.
Does Heater Have a Valve? Select whether or not the heater has an associated valve that will turn on when the heater is activated.
If Yes is selected, the following screen will ask where the valve is wired (refer to Connection Table for this information).
Does Heater Support Cooling? If your Heat Pump or Geothermal Heater supports cooling and you would like to use it to chill your
pool/spa water, select Yes to this question. If Yes is selected, the following screen will ask where the cooling relay is located (refer to
Connection Table for this information).
Heater Priority Duration? This question will appear if more than one heater is configured. Set the amount of time that you will allow
the priority heater to heat before allowing the next heater to start. If the priority heater meets the demand within this time frame, the
next heater will not be used. Note that a time interval setting of "0" will eliminate priority and always run both heaters at the same time.
If a time interval setting of "24" is selected, the next priority heater will not turn on until the first priority heater becomes invalid to run.
Minimum Allowed Air Temperature for Heater? (Heat Pump Only) If the air temperature falls below this setting, the heater will
be prevented from running, regardless of conditions. This feature is especially useful for heat pumps which become less efficient as
the outdoor ambient temperature falls.
Minimum Operation Speed? For variable speed pumps, select the lowest pump speed that is allowed while heating. Set a speed
that will ensure that there will be sufficient flow for the heater to operate properly. For two speed pumps, you can select if you want to
allow the filter pump to run at low speed during heater operation.
If Solar is selected:
Name Heater Select the box, then type the desired name for your heater. This name will be used when referring to this particular
heater.
Does the Solar Heater Have a Pump? Select whether the solar heating system has a dedicated recirculation pump. If so, the Om-
niLogic will turn this pump on when the pool temperature is below the heater setting and there is solar heat available.
If Yes is selected:
Which Relay is it Wired to? Selecting the box will bring you to a table showing all detected relays. Select the high voltage
relay that is wired to the heater (refer to the Connection Table in for this information), then advance. The relay should now be
shown in the box. Advance to the next screen to continue solar heater configuration.
Does the Solar Heater Have a Valve? Select whether the solar heating system has a diverter valve to route pool/spa water through
the solar collectors. If so, the OmniLogic will rotate this valve when the pool temperature is below the heater setting and there is solar
heat available.
If Yes is selected:
Where is the valve wired? Selecting the box will bring you to a table showing all detected low voltage relays. Select the
relay that is wired to the solar valve, then advance. The relay should now be shown in the box. Advance to the next screen
to continue solar heater configuration.
Where is the Solar Temperature Sensor Located? Selecting the box will bring you to a table showing all detected sensors. Select
the solar sensor (usually SENS3), then advance. The sensor should now be shown in the box. Advance to the next screen to continue
solar heater configuration.
