Select a Cleaner - Once you select a cleaner, all of the options for that cleaner will appear on the next screen. These options are as follows:
Name - Rename the cleaner to whatever name you desire.
Type - Select the type of cleaner that is configured (Pressure, Suction, Robotic, In Floor).
Pump - Configure the cleaner pump, if used.
Relay - Select the relay that the cleaner is wired to. This option only appears if the cleaner does not have an associated pump con-
figured.
Valve - Configure the cleaner valve, if used.
Freeze Protect - Select whether you want the cleaner to turn on for Freeze Protection. Also set the Freeze Protect air temperature
threshold from this menu.
Valve Cycle - Configure the valve cycling time period for the cleaner. This option is only available if the cleaner has an assigned valve.
Speed - Change the Minimum and Maximum Allowed Speeds of the cleaner as well as the Low, Medium and High speed settings. This
option only appears if the cleaner pump is configured as a Variable Speed Pump.
Priming - Select whether you want the cleaner pump to prime and the desired duration. This option only appears if the cleaner pump
is configured as a 2-Speed or Variable Speed Pump.
Delete a Cleaner - From this screen, if you wish to delete a cleaner that is currently configured, select the trash can on the right of the
name of the cleaner that you wish to delete.
If Water Features is selected:
Add Water Feature - Pressing "Add Water Feature" from this screen will take you through the full configuration for adding a new water
feature. These steps are described in the Configuration Wizard portion of this manual.
Select a Water Feature - Once you select a water feature, all of the options for that water feature will appear on the next screen. These
options are as follows:
Name - Rename the water feature to whatever name you desire.
Type - Change the type of water feature that is configured (Waterfall, Waterslide, etc.).
Pump - Configure the water feature pump, if used.
Relay - Select the relay that the water feature is wired to. This option appears only if the water feature does not have an associated
pump configured.
Valve - Configure the water feature valve, if used.
Speed - Change the Minimum and Maximum Allowed Speeds of the water feature pump as well as the Low, Medium and High speed
settings. This option only appears if the water feature pump is configured as a Variable Speed Pump.
Priming - Select whether you want the water feature pump to prime and the desired duration. This option is only available if the water
feature pump is configured as a 2-Speed or Variable Speed Pump.
Freeze Protect - Select whether you want the water feature to turn on for Freeze Protection. Also set the Freeze Protect air temperature
threshold from this menu.
Default Startup Speed - Select the speed that the filter pump will run at when the water feature is turned on.
Delete a Water Feature - From this screen, if you wish to delete a water feature that is currently configured, select the trash can on the
right of the name of the water feature that you wish to delete.
If Standalone Lights is selected:
Add Standalone Light - Pressing "Add Standalone Light" from this screen will take you through the full configuration for adding new lights.
These steps are described in the Configuration Wizard portion of this manual.
