Select an Existing Group of Lights - Once you select a group of existing lights, all of the options for those lights will appear on the next
screen. These options are as follows:
Name - Rename the group of lights to whatever name is desired.
Type - Select the type of lights configured.
Relay - Select the relay(s) that the group of lights is wired to. If using a Smart Power Transformer, select the zone(s) that the lights are
wired to.
Set Mode - Set the mode of the lights configured.
OmniDirect - If UCL was previously selected, this button will appear and allow you to test whether your UCL lights are OmniDirect
compatible (lights built after June 2018). Note that if you are configuring a WaterBowl light, the Flicker feature will only be available if
the light is set to OmniDirect mode.
Delete an Existing Group of Lights - From this screen, if you wish to delete a group of lights that is currently configured, select the group
and then select the trash can button next to it.
If Accessories is selected:
Add Accessory - Pressing "Add Accessory" from this screen will take you through the full configuration for adding a new accessory. These
steps are described in the Configuration Wizard portion of this manual.
Select an Accessory - Once you select an accessory, all of the options for that accessory will appear on the next screen. These options
are as follows:
Name - Rename the accessory to whatever name you desire.
Type - Select the type of accessory configured (Laminar, Dimmer, etc.).
Pump - Configure the accessory pump, if used.
Valve - Configure the accessory valve, if used.
Speed - Change the Minimum and Maximum Allowed Speeds of the accessory pump as well as the Low, Medium and High Speed
settings. This option only appears if the accessory pump is configured as a Variable Speed Pump.
Priming - Select whether you want the accessory pump to prime and the desired duration. This option is only available if the accessory
pump is configured as a 2-Speed or Variable Speed Pump.
Freeze Protect - Select whether you want the accessory to turn on for Freeze Protection. Also set the Freeze Protect air temperature
threshold from this menu.
Relay - Select the relay that the accessory is wired to. This option only appears if the accessory does not have an associated pump
configured.
Default Startup Speed - Select the speed that the filter pump will run at when the water feature is turned on.
Delete an Accessory - From this screen, if you wish to delete an accessory that is currently configured, select the trash can on the right
of the name of the accessory that you wish to delete.
If Other Options is selected:
Name - This is where you will be allowed to rename the Body of Water that you are currently configuring to whatever name you desire.
If Backyard is selected:
Select the Equipment that you would like to configure - The options are Add Standalone Light and Add Accessory. The configuration for these are
described in the Configuration Wizard portion of this manual.
If Standalone Light is selected:
Add Standalone Light - Pressing "Add Standalone Light" from this screen will take you through the full configuration for adding new lights.
These steps are described in the Configuration Wizard portion of this manual.
Select an Existing Group of Lights - Once you select a group of existing lights, all of the options for those lights will appear on the next screen.
These options are as follows:
