- Page 1 Dual Vertical Monitor Desk Stand STAND-V002L Series Assembly Manual Individual Product SKUs STAND-V002L STAND-V002LW...
- Page 2 Better Products for a Better Workspace Experience We are dedicated to creating high-end ergonomic solutions for the office with top of the industry support. Explore Endless Workspace Solutions www.vivo-us.com...
- Page 3 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
-
Page 4: Package Contents
Package Contents A (x2) B (x2) C (x1) D (x1) VESA Plate Base Lower Pole E (x1) F (x1) G (x1) H (x2) Upper Pole Pole Cap Pole Connector Cable Clip Included Hardware & Tools S-A (x2) S-B (x3) T-A (x1) T-B (x1) T-C (x1) Thumbscrew... -
Page 5: Assembly Steps
Assembly Steps STEP 1 Insert Pole Cap (F) into Upper Pole (E). STEP 2 Attach Bottom Pole (D) to Base (C) using M6x14mm Screws (S-B) and 4mm Allen Wrench (T-B). - Page 6 STEP 3 Slide one Cable Clip (H) and Arm (B) down Lower Pole (D). Note: Arm may need to be loosened using 6mm Allen Wrench (T-C) before sliding on. Position Arm (B) where desired and secure by tightening the back screw using 6mm Allen Wrench (T-C).
- Page 7 STEP 4 Thread Pole Connector (G) to Lower Pole (D), then thread Upper Pole (E) into Pole Connector. Secure by tightening the two set screws on Pole Connector using 3mm Allen Wrench (T-A). Poles Won’t Thread Into Connector? If Poles (D,E) are difficult to thread into Pole Connector, the two set screws may need to be loosened.
- Page 8 STEP 5 Slide the remaining Cable Clip (H) and Arm (B) onto Upper Pole (E). Note: Arm may need to be loosened using 6mm Allen Wrench (T-C) before sliding on. Position Arm (B) at the desired height and secure by tightening the back screw using 6mm Allen Wrench (T-C).
- Page 9 STEP 6 Secure VESA Plates (A) to the back of monitors using approprate Screws (M-A thru M-D) and M5 Washers (M-E). Spacers (M-F) can be used if needed. Tighten using a Phillips screwdriver. Ensure Lip on VESA Plate is facing up. Slide monitors with VESA Plates (A) onto the arms and secure using Thumbscrews (S-A).
- Page 10 STEP 7 Adjust the monitors’ tilt by loosening the Adjustment Screw using 6mm Allen Wrench (T-C). Re-tighten once at the desired angle. Adjustment Adjustment Screw Screw Route cables and store Allen Wrenches in Cable Clips (H).
- Page 11 Love Your New Setup? Tag Us on Social! @ VIVO-us @ vivo_us @VIVOus VIVO...
- Page 12 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
