Important Information

Thank you very much for using a product from Logic IO Aps. Our products are designed for
professional use; therefore, this manual assumes technical knowledge and practice working with such
products.
This documentation does not entail any guarantee on the part of Logic IO Aps with respect to
technical processes described in the manual or any product characteristics set out in the manual. We
do not accept any liability for any printing errors or other inaccuracies in the manual, unless it can be
proven that we are aware of such errors or inaccuracies, or that we are unaware of these as a result of
gross negligence and Logic IO Aps has failed to eliminate these errors or inaccuracies for this reason.
This product is a complex and sensitive electronic product. Please act carefully and ensure
that only qualified personnel will handle and use the device. In the event of damage to the device
caused by failure to observe the information in this manual and on the device, Logic IO Aps shall not
be required to honor a warranty claim even during the warranty period and shall be exempted from
the statutory accident liability obligation. Any attempts to repair or modify the product also voids all
warranty claims. Only open the device to access the internal SIM card reader. There is no user-
serviceable part inside.
Please contact Logic IO for any technical or commercial inquiries:
Logic IO Aps.
Holmboes Alle 14
8700 Horsens
Denmark
Phone: +45 76250210
Support: support@logicio.com
URL: www.logicio.com
