Connector X3: 16 Pin I/O Connector - Logic IO RTCU LX2 pro Technical Manual

RTCU LX2 pro Technical Manual V1.00
Advanced Automotive M2M/IoT Gateway

Connector X3: 16 pin I/O connector

Pin Name
1 DOUT 1
2 DOUT 3
3 DIN 1
4 GND
5 DIN 3
6 DIN 5/IGN
7 AIN 1
8 AIN 2
9 DOUT 2
10 DOUT 4
11 DIN 2
12 GND
13 DIN 4
14 GND
15 AGND
16 AGND
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
AIN2 8
AIN1 7
DIN5 6
DIN3 5 13
GND 4 12
DIN1 3 11
DOUT3 2 10
DOUT1 1
Description
Digital output 1
Digital output 3
Digital input 1
Signal Ground
Digital input 3
Digital input 5 / Ignition input (Shared with X1)
Analog input 1
Analog input 2
Digital output 2
Digital output 4
Digital input 2
Signal Ground
Digital input 4
Signal Ground
Analog Ground
Analog Ground
Page 12 of 39
16 AGND
15 AGND
14 GND
DIN4
GND
DIN2
DOUT4
9 DOUT2
