Pistol Handle Push Start- Shut Off
Test result according to
Vibration
MODEL
EN ISO 28927-2
No Load: 0.5 m/s 2
CBP48
No Load: 0.9 m/s 2
CBP50
No Load: 0.3 m/s 2
CBP55
No Load: 0.3 m/s 2
CBP60
No Load: 0.4 m/s 2
CBP65
No Load: 0.4 m/s 2
CBP68
Uncertainty K= 1.5 m/s²
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
.
PNEUMATIC TOOLS
Composite Screwdriver
EN ISO 11148-6:2012
Noise : EN ISO 15744
Sound pressure level
No Load: 77 dB(A)
No Load: 75.1 dB(A) No Load: 86.1 dB(A)
No Load: 73 dB(A)
No Load: 73.9 dB(A) No Load: 84.9 dB(A)
No Load: 76.4 dB(A) No Load: 87.4 dB(A)
No Load: 77 dB(A)
Uncertainty K= 3dB
Sound power level
1-
No Load: 88 dB(A)
2-
No Load: 84 dB(A)
No Load: 88 dB(A)
CBP48(50)(55)(60)(65)(68)-S-2301H-MIF
Safety Instructions
Warning
Read this manual and
understand all safety
instructions before operation
the tool.
Wear an approved
ear-protector and gloves while
operating tool.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sumake CBP48
Summary of Contents for Sumake CBP48
- Page 1 No Load: 76.4 dB(A) No Load: 87.4 dB(A) No Load: 0.4 m/s 2 CBP68 No Load: 77 dB(A) No Load: 88 dB(A) Uncertainty K= 1.5 m/s² Uncertainty K= 3dB CBP48(50)(55)(60)(65)(68)-S-2301H-MIF SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91...
-
Page 2: Ec Declaration Of Conformity
DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment：PISTOL TYPE PISTOL HANDLE AIR SHUT OFF COMPOSITE SCREWDRIVER Model/ Serial No.：CBP48(50)(55)(60)(65)(68) to which this declaration applies, complies with these normative documents: Machinery Directive: 2006/42/EC ... -
Page 3: Air Supply
CBP38 1800 0.28 3-25 M2.2-M4.7 M1.7-M3.8 ±3 CBP41 1000 0.28 5-35 M2.8-M5.2 M2.2-M4.2 ±3 CBP47 0.28 10-50 M3.6-M6.0 M2.8-M4.7 ±3 CBP48 1700 0.55 7-50 M2.9-M6.0 M2.6-M4.9 ±3 CBP50 1400 0.55 10-60 M3.6-M6.2 M2.8-M5.1 ±3 CBP55 1000 0.55 12-75 M3.8-M6.6 M3.0-M5.6 ±3... - Page 5 CBP48 PISTOL HANDLE AIR SHUT OFF COMPOSITE SCREWDRIVER CBP48-P-1110A1-MI...
- Page 6 CBP48 PISTOL HANDLE AIR SHUT OFF COMPOSITE SCREWDRIVER PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty 5L2100 Pistol Housing (Green) 3S5221 End Clutch 2C2002 Blank Cap 7S2102 Ball 7Q2008 O Ring 3S5231 Ball Race 7S2106-1 Screw 6N2006 C Ring...
- Page 7 SCREWDRIVER Original instructions SUMAKE Industrial Co. Ltd.
- Page 8 Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 9 2. While using an assembly power tool for threaded fasteners, the operator should adopt a comfortable posture whilst maintaining secure footing and avoiding awkward or off-balanced postures. The operator should change posture during extended tasks, which can help avoid discomfort and fatigue. 3.
- Page 10 General preparation and connection: When using brand-new air hose or air pipe. Blow and clean the inside of air hose or pipe before installation. Keep inside of air hose or air pipe clean to prevent airdrop problem caused by the lots of drain and dust accumulated and possibly make the inside diameter smaller in the long use.
