    Table of contents Table of contents Electrical Circular Saw INSTRUCTION MANUAL Thank you for your purchase of the electrical circular saw. For your personal safety, read and understand the Instruction Manual before using. Keep the Instruction Ma- nual in a safe place for future reference. TABLE OF CONTENTS PICTURE ANNEX ..........................

  • Page 9: General Safety Regulations

    General safety instructions GENERAL SAFETY INSTRUCTIONS Carefully read, remember and keep these safety instructions WARNING! In the use of electric machines and power tools, it is necessary to respect and follow the following safety instructions for the reasons of protection against electric shock, personal injury and danger of fire.
  • Page 10 Children must be supervised to make sure they are not playing with the equipment. FDK 200801-E...
  • Page 11 General safety instructions Power Tool Use and Maintenance Always disconnect the power tool from the mains in case of any problem during the work, before cleaning the power tool or its maintenance, during each transportation and after the completion of the work! Never operate a power tool if it is damaged in any way. Immediately stop working if the power tool generates abnormal noise or smell.

  • Page 12: General Safety Instructions

    (it could cause injury or damage to the user). Always have your power tool repaired in a certified service centre. Use only original or recommended replacement parts. This will ensure that your safety and the safety of your power tool is maintained. FDK 200801-E...

  • Page 13: Symbols And Pictograms

    Symbols and pictograms Symbols and pictograms Symbols 3. SYMBOLS AND PICTOGRAMS 2. SYMBOLS The product complies with the applicable This product has been manufactured standards and regulations. in accordance with the approved standards. Read the Instruction Manual Before using the machine read attentively prior to use.

  • Page 14: Machine Description And Package Content

    Machine description and package content Machine description and package content Machine description and package content 4. MACHINE DESCRIPTION AND 4. MACHINE DESCRIPTION AND PACKAGE CONTENT PACKAGE CONTENT Machine Description (see Fig. 1.2) Machine Description (see Fig. 1.2) Switch Switch Handle Handle Guiding handle Guiding handle...

  • Page 15: Safety Instructions

    Safety instructions Safety instructions 5. SAFETY INSTRUCTIONS Before use, please read these safety instructions and keep them in a safe place. ATTENTION! This symbol indicates risk of injury or damage to the equipment. ATTENTION! Upon failure to follow the instructions specified in this manual, there is a risk of injury.
  • Page 16 ATTENTION! Maintain a firm grip with both hands on the saw and position your arms to resist kickback forces. Position your body to either side of the circular-saw blade but not in line with the circular-saw blade. FDK 200801-E FDK 2001-E...
  • Page 17 Safety instructions Safety instructions ATTENTION! During longitudinal cutting, always use the longitudinal guide scale or straight guide rail. ATTENTION! Never use damaged or incorrect washers or clamping bolts. ATTENTION! If the circular-saw blade is pinched or when interrupting a cut for other reason, release the trigger and hold the saw motionless in the material until the blade comes to a complete stop.
  • Page 18 ATTENTION! Wear gloves when working with circular-saw blades and roughly machined materials - circular-saw blades should be carried in holders, if possible. ATTENTION! Use means of protection against noise, dust and vibrations !!! ATTENTION! Keep these safety instructions. FDK 200801-E FDK 2001-E...

  • Page 19: Use And Operation

    Use and operation | Adjustment and operation Use and operation | Adjustment and operation 6. USE AND OPERATION The circular saw is supplied with a circular-saw blade intended for making straight cuts in wooden materials. After replacement of the circular-saw blade, you can also cut plastics, thermoplastics, hard plastics, laminate, polyurethane foam boards, mineral wool insulation boards, cement bricks, cellular concrete and products made of non-ferrous metals.
  • Page 20 The tool is equipped with double-acting safety switch: the saw can only be started if you hold the handle firmly and press both safety switches. After releasing the handle, the saw is automatically switched off to prevent accidental machine operation. FDK 200801-E FDK 2001-E...

  • Page 21: Cleaning And Maintenance

    Adjustment and operation | Cleaning and maintenance tips Adjustment and operation | Cleaning and maintenance tips Replacement of carbon brushes ATTENTION! In case of carbon brush seasoning, immediately switch off the saw and contact the nearest service centre of FAST ČR, a.s. or your nearest vendor. Use only correct types of carbon brushes.

  • Page 22: Declaration Of Conformity

    Declaration of conformity 10. DECLARATION OF CONFORMITY Product/Name: ELECTRICAL CIRCULAR SAW / FIELDMANN Type/Model: FDK 200 - E ................230V/50Hz/800W/4000rpm/140mm The product complies with the following directives: The Directive of the European Parliament and the Council No. 2014/35/EU dated 20 April 2016...

  • Page 23: Technical Data

    Technical data 11. TECHNICAL DATA ELECTRICAL CIRCULAR SAW: Power supply 230V/50Hz Power input 800W 4000rpm Speed Protection class Blade Diameter 140 mm Cutting capacity 45mm at 90 degree, 28mm at 45 degree Power supply cable length 1.8m Declared noise level 96.43dB(A) Vibration =1.434 ms...
  • Page 24 Technical data Troubleshooting Suspected malfunctions are often due to causes the user can fix themselves. Therefore check the product using this section .In most cases the problem can be solved quickly . WARNING! Only perform the steps described within these instruction s! All further inspection ,maintenance and repair work must be performed by an...

  • Page 25: Liquidation

    This product fulfils all basic requirements of the EU directives that apply to it. Text, design and technical specifications can change without prior notice and we reserve the right for their change. FDK 200801-E FDK 2001-E...
