Summary of Contents for Fieldmann FDK 200802-E
- Page 7 FDK 200...
-
Page 8: Table Of Contents
Table of contents Electrical Circular Saw INSTRUCTION MANUAL Thank you for your purchase of the electrical circular saw. For your personal safety, read and understand the Instruction Manual before using. Keep the Instruction Ma- nual in a safe place for future reference. TABLE OF CONTENTS PICTURE ANNEX .......................... -
Page 9: General Safety Instructions
General safety instructions GENERAL SAFETY INSTRUCTIONS Carefully read, remember and keep these safety instructions WARNING! In the use of electric machines and power tools, it is necessary to respect and follow the following safety instructions for the reasons of protection against electric shock, personal injury and danger of fire. - Page 10 General safety instructions If an extension cord is used, always check whether its technical parameters match the information specified in the type label of the power tool. When operating a power tool outdoors, use an extension cord suitable for outdoor use. If extension drums are used, these must be rolled out to prevent overheating of the cord.
- Page 11 General safety instructions Power Tool Use and Maintenance Always disconnect the power tool from the mains in case of any problem during the work, before cleaning the power tool or its maintenance, during each transportation and after the completion of the work! Never operate a power tool if it is damaged in any way. Immediately stop working if the power tool generates abnormal noise or smell.
- Page 12 General safety instructions Handle the batteries with care. Rough handling could result in leak of chemical substance from the battery. Avoid contact with such substance and if, nonetheless, any contact occurs wash the affected area under running water. If eyes get into contact with the chemical substance seek immediately medical aid.
-
Page 13: Symbols And Pictograms
Symbols and pictograms 3. SYMBOLS AND PICTOGRAMS applicable ELECTRICAL CIRCULAR SAW OPERATING INSTRUCTIONS... -
Page 14: Machine Description And Package Content
Machine description and package content 4. MACHINE DESCRIPTION AND PACKAGE CONTENT Machine Description (see Fig. 1.2) Switch Handle Guiding handle Bevel adjustment knob Parallel guide adjustment knob Parallel guide Circular-saw blade guide Circular-saw base Blade stud 10 - Cutting depth adjustment knob 11 - Safety switch 12 -... -
Page 15: Safety Instructions
Safety instructions 5. SAFETY INSTRUCTIONS Before use, please read these safety instructions and keep them in a safe place. ATTENTION! This symbol indicates risk of injury or damage to the equipment. ATTENTION! Upon failure to follow the instructions specified in this manual, there is a risk of injury. - Page 16 Safety instructions ATTENTION! Do not use grinding discs - The arrow on the circular-saw blade indicating the running direction must indicate the same direction as the arrow on the circular-saw guard. The teeth of the circular-saw blade must match the running direction of the saw (downwards and forward). - Keep the circular-saw blade and the clamping surface of the flange clean.
- Page 17 Safety instructions ATTENTION! During longitudinal cutting, always use the longitudinal guide scale or straight guide rail. ATTENTION! Never use damaged or incorrect washers or clamping bolts. ATTENTION! If the circular-saw blade is pinched or when interrupting a cut for other reason, release the trigger and hold the saw motionless in the material until the blade comes to a complete stop.
- Page 18 Safety instructions ATTENTION! Except for plunge cuts, always use the riving knife. ATTENTION! In order for the riving knife to work, it must fit into the cut-out in the processed piece. ATTENTION! Do not operate the saw if the riving knife is bent. ATTENTION! Make sure that the riving knife is so adjusted that the distance between the riving knife and the blade rim is not greater than 5 mm and the blade rim does not reach out behind the lower edge of the riving knife by more than 5 mm.
-
Page 19: Use And Operation
Use and operation | Adjustment and operation 6. USE AND OPERATION The circular saw is supplied with a circular-saw blade intended for making straight cuts in wooden materials. After replacement of the circular-saw blade, you can also cut plastics, thermoplastics, hard plastics, laminate, polyurethane foam boards, mineral wool insulation boards, cement bricks, cellular concrete and products made of non-ferrous metals. - Page 20 Adjustment and oper ATTENTION! Make sure that the spindle diameter matches the blade hole. Secure the clamping nut using the flange wrench 14 and loosen it using the Allen wrench 13 anticlockwise. Retract the blade guard and remove the blade stud, washer and flange. Remove the old saw blade and insert a new blade.
-
Page 21: Cleaning And Maintenance
Adjustment and operation | Cleaning and maintenance tips Replacement of carbon brushes ATTENTION! In case of carbon brush seasoning, immediately switch off the saw and contact the nearest service centre of FAST ČR, a.s. or your nearest vendor. Use only correct types of carbon brushes. After attaching new carbon brushes, let the saw run on idle for approx. -
Page 22: Technical Data
Technical data ELECTRICAL CIRCULAR SAW OPERATING INSTRUCTIONS... - Page 23 Technical data ELECTRICAL CIRCULAR SAW OPERATING INSTRUCTIONS...
- Page 24 liquidati INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED PACKAGING. Put any used package material to the place determined by the municipality for waste disposal. DISPOSAL OF USED ELECTRIC AND ELECTRONIC EQUIPMENT This symbol on products or accompanying documents means that used electric or electronic products must not be put to ordinary municipal waste.
