- Page 1 Installation Guides Section: HISPACE CASUAL SPACE DIVISON Date: Sept 2021 Page No: 1 of 5 Description: DOUBLE SIDED SPINE SCREEN HABH_215 Rev. No: 0 Double-Sided Spine Screen - Framed Fabric (HWBCTF) and Double-Sided Spine Screen - Solid (HWBCTS)
- Page 2 height adjustable bench Installation Guides Section: HISPACE CASUAL SPACE DIVISON Date: Sept 2021 Page No: 2 of 5 Description: DOUBLE SIDED SPLINE SCREEN HABH_215 Rev. No: 0 Part and Product Identification A - Double-Sided Spine Screen - C - Double-Sided Spine Screen Framed Fabric Solid (N01-6008-X) x1...
- Page 3 height adjustable bench Installation Guides Section: HISPACE CASUAL SPACE DIVISON Date: Sept 2021 Page No: 3 of 5 Description: DOUBLE SIDED SPINE SCREEN HABH_215 ATTACH SPINE SCREEN MOUNTING BRACKET KIT NOTE: Do not tight the screws. NOTE: Spacer is used only for Double Sided Spine Screen Framed Fabric.
- Page 4 height adjustable bench Installation Guides Section: HISPACE CASUAL SPACE DIVISON Date: Sept 2021 Page No: 4 of 5 Description: DOUBLE SIDED SPINE SCREEN HABH_215 ATTACH SPINE SCREEN TO FRAME ATTACH SCREEN MOUNTING BRACKET COVER NOTE: Worksurface, Control Box, Mid cable Riser are hidden for illustration purpose STEP 4: Insert Bottom Spacer into Spine Screen with Mounting Bracket and attach to the STEP 5: Make sure screen is aligned properly, and tight screws as shown.
- Page 5 height adjustable bench Installation Guides Section: HISPACE CASUAL SPACE DIVISON Date: Sept 2021 Page No: 5 of 5 Description: DOUBLE SIDED SPINE SCREEN HABH_215 ATTACH SPINE SCREEN TO FRAME ATTACH SCREEN MOUNTING BRACKET COVER STEP 6: Fully tighten the screws after screen is aligned properly. STEP 7: Attach Screen Mounting Bracket Cover on Screen Mounting Bracket as shown.
