Teknion hiSpace Installation Manual

Height-adjustable bench
Hide thumbs Also See for hiSpace:

Advertisement

Quick Links

Download this manual
height-adjustable bench - hiSpace
INDEX
By Section
Product
Product Name
Code
INSTALLATION SUPPORT DOCUMENTS
Typical Installation Sequence
FRAMES AND WORKSURFACE
hiSpace Universal Frame
HBBFYS
hiSpace Rectangular Worksurface
HBBWRL
Frame Grommet Cap
HHBFGC
SCREENS AND GABLES
hiSpace - Center Casual Screen - Solid
HHBCCS
hiSpace Center Casual Screen - Fabric
HHBCCF
hiSpace - Desk Edge Screen - Solid
HHBCDS
hiSpace - Desk Edge Screen - Fabric
HHBCDF
hiSpace - Desk Edge Screen - Glass
HHBCDG
ELECTRICS
Power Harness
HHBEPH
Power Box
HHBEPB
Chicago Power Box
HHBEPBCH
Extension Harness
HHBEEH
hiSpace Base Feed
HHBEBF
hiSpace Split Base Feed
HHBEBFS
hiSpace Chicago Base Feed
HHBEBFCH
hiSpace Cable Riser
HHBECR
E-Chain - hiSpace
HHBEEC
hiSpace Under Worksurface Cover
HHBWUC
hiSpace Cable Tray Cover
HHBFCC
hiSpace Ceiling Feed
HHBECF
hiSpace Chicago Ceiling Feed
HHBECFCH
hiSpace Power Pole
HHBEPP
May 2020
*Click on the desired Installation Guide to jump to the Guide
page.
Guide
Last
No.
Updated
Product Name
Sep 2018
May 2020
111
211a
May 2017
211b
May 2017
212a
May 2017
212b
May 2017
212c
May 2017
311a
May 2017
311b
May 2017
311c
May 2017
311d
Aug 2017
312
May 2017
Product
Guide
Last
Code
No.
Updated
Product Name
Product
Guide
Last
Code
No.
Updated
PAGE 1 OF 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the hiSpace and is the answer not in the manual?

Questions and answers

Related Manuals for Teknion hiSpace

Summary of Contents for Teknion hiSpace

  • Page 1 May 2020 hiSpace Universal Frame HBBFYS hiSpace Rectangular Worksurface HBBWRL Frame Grommet Cap HHBFGC SCREENS AND GABLES hiSpace - Center Casual Screen - Solid 211a May 2017 HHBCCS hiSpace Center Casual Screen - Fabric 211b May 2017 HHBCCF hiSpace - Desk Edge Screen - Solid...
  • Page 2 Description: FRAME & WORKSURFACES ASSEMBLY HABH_111 Rev. No: 5 Part and Product Identification hiSpace Universal Frame (HHBFYS), hiSpace Rectangular Worksurface (HHBWRL) & Frame Grommet Cap (HHBFGC) Hispace Frame Reconfiguration Kit, End (HHBFRK1) x1 Hispace Frame Reconfiguration Kit, Mid (HHBFRK2) xQty varies...
  • Page 3 Head Mach Scr Steel Zn A5 - Wood Screw (FS8-5/8PB)x4 (N09-5358) x1 (E01-0110)x8 C - Mid Gable Hispace (N09-5337)xQty varies D - Cable Tray Assembly (N09-5339)x2 Leg Kit (N09-5785) x2 Worksurface Hardware Kit (X05-0314)x1 C3 -1/4-20 UNC X0.5" 2A Cross D7 -1/4-20 UNC X0.5"...
  • Page 4 height-adjustable bench Installation Guides Section: FRAMES & WORKSURFACES Date: May 2020 Page No: 3 of 11 Description: ASSEMBLE END GABLES HABH_111 REMOVE END GABLES INNER COVER INSTALL END GABLES TOP PLATE Mid Vertical Tube NOTE: End Gables are shipped assembled, except for Top Plate.
  • Page 5 height-adjustable bench Installation Guides Section: FRAMES & WORKSURFACES Date: May 2020 Page No: 4 of 11 Description: ASSEMBLE MID GABLES - IF SPECIFIED HABH_111 REMOVE MID GABLE TOP COVERS INSTALL MID GABLE TOP PLATES IMPORTANT: If Mid Gables are not specified, skip steps 3 to 5 NOTE: Mid Gable is shipped assembled,...
  • Page 6 height-adjustable bench Installation Guides Section: FRAMES & WORKSURFACES Date: May 2020 Page No: 5 of 11 Description: ASSEMBLE END & MID GABLES HABH_111 LOOSEN THE SET SCREWS FROM GABLES INSERT & SECURE LEGS INTO GABLES NOTE: Before installing legs, ensure the set screws on the gables are removed Gable to prevent scratches.
  • Page 7 height-adjustable bench Installation Guides Section: FRAMES & WORKSURFACES Date: May 2020 Page No: 6 of 11 Description: FRAME ASSEMBLY HABH_111 DETERMINE GABLES PROPER LOCATION ALIGN LEGS IMPORTANT: Please refer to HAB_311 for installation of Electric Components into Cable NOTE: Use laser mark tool to check alignment Tray &...
  • Page 8 height-adjustable bench Installation Guides Section: FRAMES & WORKSURFACES Date: May 2020 Page No: 7 of 11 Description: FRAME ASSEMBLY HABH_111 INSTALL WORKSURFACE CHANNELS INSTALL WORKSURFACE ANGLES TO LEGS NOTE: End Gable shown for demonstration STEP 9: Place Worksurface Channels on top of Legs. Make sure the holes align and fasten as STEP 10: Attach Worksurface Angles to Legs with screws provided, as shown.
  • Page 9 height-adjustable bench Installation Guides Section: FRAMES & WORKSURFACES 8 of 11 Date: May 2020 Page No: Description: ASSEMBLE END & MID GABLES HABH_111 TIGHTEN GABLES SET SCREW REINSTALL COVERS BACK End Gables Legs & Cable Tray not shown for better visibility NOTE: Remove the covers if needed.
  • Page 10 height-adjustable bench Installation Guides Section: FRAMES & WORKSURFACES 9 of 11 Date: May 2020 Page No: Description: FRAMES & WORKSURFACES HABH_111 INSTALL CONTROL BOX DETAIL Underside View NOTE: Electrical Power Plug should be installed facing the location of the power box. Support Plate - Worksurface Channel...
  • Page 11 Underside View Note: Gables, Cable Tray and Control Box Cable connections not shown STEP 14: Bring Worksurfaces on top of Hispace Frame. Align Worksurface holes with Worksurface Angle holes, Worksurface Channel and Control Box. Fasten worksurfaces in place, as shown.
  • Page 12 height-adjustable bench Installation Guides Section: FRAMES & WORKSURFACES 11 of 11 Date: May 2020 Page No: Description: FRAMES & WORKSURFACES HABH_111 INSTALL SWITCHES INSTALL GROMMETS - IF SPECIFIED Underside View Underside View STEP 15: Align Swithches & Worksurfaces holes. Fasten Switches to Worksurface with screws STEP 16: When specified, insert Bottom part of Rectangular Grommet into Worksurface cut provided.
  • Page 13 May 2017 Page No: 1 of 3 Description: HABH_211a Rev. No: 01 hiSpace - Center Casual Screen - Solid (HHBCCS) Part and Product Identification A - Wood Fixed HT Screen (C0S-9308) x1 B1 - Wood Screen Mounting Bracket (A16-3622) x4 B2 - 1/4-20 UNC x 0.500"...
  • Page 14 height-adjustable bench Section: Date: May 2017 Page No: 2 of 3 Description: HABH_211a INSTALL MOUNTING BRACKETS ATTACH SCREEN STEP 1: Secure Mounting Brackets to Casual Screen with Murakoshi Screws and Joint Nuts. STEP 2: Fasten Mounting Brackets onto Cable Tray loosely.
  • Page 15 height-adjustable bench Section: Date: May 2017 Page No: 3 of 3 Description: HABH_211a ADJUST & SECURE SCREEN STEP 3: Ensure Casual Screen is located at the center of the bench, then tighten Screws to secure it in place.
  • Page 16 May 2017 Page No: 1 of 4 Description: HABH_211b Rev. No: 01 hiSpace Center Casual Screen - FABRIC (HHBCCF) Part and Product Identification A - Center Casual Screen (HHBCCF) x1 Fabric Screen shipped pre-assembled B1 - Support Bracket - Fabric Screen...
  • Page 17 height-adjustable table Section: Date: May 2017 Page No: 2 of 4 Description: HABH_211b MOUNTING BRACKETS ASSEMBLY STEP 1: Secure Support Brackets to Fabric Screen.
  • Page 18 height-adjustable table Section: Date: May 2017 Page No: 3 of 4 Description: HABH_211b FASTEN SCREEN (LOOSELY) Cable Tray STEP 2: Fasten Support Brackets onto Cable Tray with Screws. Make sure to keep Screws loose for adjustment.
  • Page 19 height-adjustable table Section: Date: May 2017 Page No: 4 of 4 Description: HABH_211b ADJUST & SECURE SCREEN Top View Detail View STEP 3: Ensure Fabric Screen is located at the center of the Cable Tray, then tighten Screws to secure it in place.
  • Page 20 May 2017 Page No: 1 of 3 Description: HABH_212a Rev. No: 01 hiSpace - Desk Edge Screen - Solid (HHBCDS) Part and Product Identification A - Desk Edge Wood Screen - Hispace (C05-9305) x1 B1 - Desk Edge Screen Bar-Sub-Assembly...
  • Page 21 height-adjustable bench Section: Date: May 2017 Page No: 2 of 3 Description: HABH_212a SCREEN MOUNTING KIT ASSEMBLY ATTACH SCREEN TO WORKSURFACE STEP 1: Fasten Screen Bar-Subassembly and Mounting Bracket with Solid Screen. STEP 2: Attach Screen Mounting Bracket to the back of the Worksurface. NOTE: If 48"...
  • Page 22 height-adjustable bench Section: Date: May 2017 Page No: 3 of 3 Description: HABH_212a SECURE SCREEN Underside View Pilot Hole Pilot Hole STEP 3: Locate and align the two Worksurface pilot holes shown above , with the two correspondent Mounting Bracket holes. Fasten Mounting Bracket to the underside of the Worksurface.
  • Page 23 1 of 4 Description: HISPACE - DESK EDGE SCREEN - FABRIC HABH_212b Rev. No: 2 hiSpace - Desk Edge Screen - Fabric (HHBCDF) Part and Product Identification A - Fabric Desk Edge Screen Sub-Assy Hispace (N09-5348) x1 B1 - Desk Edge Screen...
  • Page 24 Date: May 2018 Page No: 2 of 4 Description: HISPACE - DESK EDGE SCREEN - FABRIC HABH_212b SCREEN MOUNTING KIT ASSEMBLY INSERT WASHER & TIGHTEN BRACKET STEP 1: Fasten Screen Bar-Subassembly and Mounting Bracket with the Fabric Screen STEP 2: Insert Slotted Washers to Screws between Bracket and Fabric Frame. Then Tighten loosely .
  • Page 25 Section: SCREENS AND GABLES Date: May 2018 Page No: 3 of 4 Description: HISPACE - DESK EDGE SCREEN - FABRIC HABH_212b ATTACH SCREEN TO WORKSURFACE SECURE SCREEN Underside View Pilot Hole Pilot Hole STEP 3: Attach Mounting Bracket to the back of the Worksurface.
  • Page 26 SCREENS & GABLES Date: May 2018 Page No: 4 of 4 Description: HISPACE - DESK EDGE SCREEN - FABRIC HABH_212b ATTACH SHIMS (OPTIONAL) ATTACH SHIMS (OPTIONAL) NOTE: Only applicable if the Screen is leaning NOTE: Only applicable if the Screen is leaning towards the Desk after mounting.
  • Page 27 1 of 3 Description: HISPACE - DESK EDGE SCREEN - GLASS HABH_212c Rev. No: 01 hiSpace - Desk Edge Screen - Glass (HHBCDG) Part and Product Identification A - 6mm Clear Tempered Glass Screen Hispace (H01-2015) x1 6mm Frost Etched...
  • Page 28 Date: May 2017 Page No: 2 of 3 Description: HISPACE - DESK EDGE SCREEN - GLASS HABH_212c SCREEN MOUNTING KIT ASSEMBLY ATTACH SCREEN TO WORKSURFACE STEP 1: Fasten Screen Bar-Subassembly and Mounting Bracket with 6mm Glass Screen. STEP 2: Attach Mounting Bracket to the back of the Worksurface.
  • Page 29 Date: May 2017 Page No: 3 of 3 Description: HISPACE - DESK EDGE SCREEN - GLASS HABH_212c LOCATE PILOT HOLES & SECURE SCREEN Pilot Hole Pilot Hole STEP 3: Locate and align the two Worksurface pilot holes shown above , with the two correspondent Mounting Bracket holes. Fasten Mounting Bracket to the underside of the Worksurface.
  • Page 30 ELECTRICS Date: May 2017 Page No: 1 of 6 Description: HISPACE - POWER HARNESS AND POWER BOX HABH_311a Rev. No: 3 Power Harness (HHBEPH), Extension Harness (HHBEEH), Part and Product Identification Power Box (HHBEPB), Chicago Power Box (HHBEPBCH) NOTE: Harnesses can be A1 - Power Box connected on either side.
  • Page 31 Installation Guides Section: ELECTRICS Date: May 2017 Page No: 2 of 6 Description: HISPACE - POWER HARNESS AND POWER BOX HABH_311a REMOVE PANELS STEP 1: Remove Panels.
  • Page 32 Installation Guides Section: ELECTRICS Date: May 2017 Page No: 3 of 6 Description: HISPACE - POWER HARNESS AND POWER BOX HABH_311a INSTALL POWER BOX AND POWER HARNESS REINSTALL PANELS NOTE: Similar procedure for Chicago Power Box installation. NOTE: Please refer to Installation Guide No.
  • Page 33 Installation Guides Section: ELECTRICS Date: May 2017 Page No: 4 of 6 Description: HISPACE - POWER HARNESS AND POWER BOX HABH_311a POWER BOX TO CEILING FEED NOTE: Please refer to Installation Guide No. HABH_312 for Power Power Pole information. Pole...
  • Page 34 Section: ELECTRICS Date: May 2017 Page No: 5 of 6 Description: HISPACE - POWER HARNESS AND POWER BOX HABH_311a MULTIPLE MID GABLE & EXTENSION HARNESS APPLICATION (Connects NOTE: These will be Power Box to located in the Mid Gable. It another Power Box).
  • Page 35 ELECTRICS Date: May 2017 Page No: 6 of 6 Description: HISPACE - POWER HARNESS AND POWER BOX HABH_311a MULTIPLE MID GABLE & EXTENSION HARNESS APPLICATION NOTE: These will be Female located in the Mid Gable. It is shown for clarification Male purpose only.
  • Page 36 HISPACE - BASE FEED AND BASE FEED COVER HABH_311b Rev. No: 1 hiSpace Base Feed (HHBEBF), hiSpace Split Base Feed (HHBEBFS), Part and Product Identification hiSpace Chicago Base Feed (HHBEBFCH) & hiSpace Cable Riser (HHBECR) NOTE: Base Feed shown as example. A1 - Base Feed (HHBEBF) x1...
  • Page 37 ELECTRICS Date: May 2017 Page No: 2 of 4 Description: HISPACE - BASE FEED AND BASE FEED COVER HABH_311b INSTALL CABLE RISER ADJUST CABLE RISER Underside View STEP 1: Fasten Base Feed Cover to underside of Tray as shown. STEP 2: Loosen Screw to allow the Cover Bracket to adjust in height (1). Adjust Cover so it...
  • Page 38 Installation Guides Section: ELECTRICS Date: May 2017 Page No: 3 of 4 Description: HISPACE - BASE FEED AND BASE FEED COVER HABH_311b INSTALL BASE FEED INSTALL SPLIT BASE FEED NOTE: Similar Installation for Chicago Base Feed. Underside View Underside View STEP 3a: Install Base Feed.
  • Page 39 Date: May 2017 Page No: 4 of 4 Description: HISPACE - BASE FEED AND BASE FEED COVER HABH_311b INSERT CABLE INTO BASE FEED COVER NOTE: To be connected to Power Box. Please refer to Installation Guide No. HABH_311a for information.
  • Page 40 Date: May 2017 Page No: 1 of 3 Description: HABH_311c Rev. No: 1 E-Chain - HiSpace (HHBEEC) Part and Product Identification A - E-Chain Bottom Link - HAB (Ergotek # 740789) (B02-04797) x1 B - E-Chain Top Link (Ergotek #740657)
  • Page 41 height-adjustable bench Section: Date: May 2017 Page No: 2 of 3 Description: HABH_311c INSTALL E-CHAIN (END GABLE LOCATION) Underside View NOTE: Use Cable Tie Wrap to secure cable to Link (B) NOTE: E-Chain to be installed here for Mid Gable. Push cable inside E-Chain Underside View...
  • Page 42 height-adjustable bench Section: Date: May 2017 Page No: 3 of 3 Description: HABH_311c INSTALL E-CHAIN (MID GABLE LOCATION) Cover for Mid Galbe Underside View Underside View STEP 2: Install Links at location shown. Fasten with Screws provided. Snap E-Chain to Links. Insert Cables through E-Chain and secure cables with Cable Tie Wrap as shown on Page 2.
  • Page 43 ELECTRICS Date: Aug 2017 Page No: 1 of 5 Description: HISPACE - UNDER WORKSURFACE COVER AND CABLE TRAY COVER HABH_311d Rev. No: 02 Hispace Under Worksurface Cover (HHBWUC) Part and Product Identification Hispace Cable Tray Cover (HHBFCC) Worksurface Wire Loom- Hispace (YESL) A1 - Tray Cover - Full (A16-3588) x qty.
  • Page 44 Aug 2017 Page No: 2 of 5 Description: HISPACE - UNDER WORKSURFACE COVER AND CABLE TRAY COVER HABH_311d INSTALL TRAY DIVIDER INSTALL HALF TRAY COVER STEP 1: Align the holes of Tray Divider with those on Frame and secure in place with Cross STEP 2: Lower Half Tray Cover on an angle to install.
  • Page 45 Installation Guides Section: ELECTRICS Date: Aug 2017 Page No: 3 of 5 Description: HISPACE - UNDER WORKSURFACE COVER AND CABLE TRAY COVER HABH_311d INSTALL FULL TRAY COVER STEP 3: Lower Full Tray Cover on an angle to install.
  • Page 46 ELECTRICS Date: Aug 2017 Page No: 4 of 5 Description: HISPACE - UNDER WORKSURFACE COVER AND CABLE TRAY COVER HABH_311d INSTALL WIRE LOOMS INSTALL WIRE LOOMS NOTE: Only Worksurface, Power Module and Wire Loom Assembly is shown. NOTE: For Worksurface & Power Module Installation, refer to Installation Guide no.
  • Page 47 Installation Guides Section: ELECTRICS Date: Aug 2017 Page No: 5 of 5 Description: HISPACE - UNDER WORKSURFACE COVER AND CABLE TRAY COVER HABH_311d HANG WIRING COVER FASTEN COVER Underside View Underside View NOTE: Worksurface and Wire Loom Assembly is not shown.
  • Page 48 1 of 9 Description: HISPACE - CEILING FEED AND POWER POLE HABH_312 Rev. No: 2 hiSpace Ceiling Feed (HHBECF), hiSpace Chicago Ceiling Feed (HHBECFCH), Part and Product Identification hiSpace Power Pole (HHBEPP) I - Power Pole Cover A - Ceiling Feed...
  • Page 49 Section: ELECTRICS Date: May 2017 Page No: 2 of 9 Description: HISPACE - CEILING FEED AND POWER POLE HABH_312 INSTALL BRACKET INSTALL COVER NOTE: Make sure Legs are fully extended when installing cover. STEP 1: Install Bracket to Mid Gable Top Mounting Plate.
  • Page 50 Date: May 2017 Page No: 3 of 9 Description: HISPACE - CEILING FEED AND POWER POLE HABH_312 ATTACH LOWER EXTRUSION SECURE BOTTOM EXTRUSION STEP 3: Align and attach Lower Power Pole to Connecting Bracket as shown. STEP 4: Fasten Bracket to Lower Power Pole.
  • Page 51 Section: ELECTRICS Date: May 2017 Page No: 4 of 9 Description: HISPACE - CEILING FEED AND POWER POLE HABH_312 CEILING CUT OUT 3-1/2" 3-1/2" Power Pole length = distance + 3" STEP 5: Mark Power Pole position on the ceiling using Plum Bob Line. Cut 3-1/2" x 3-1/2" opening. Measure distance from top of the Lower Power pole Extrusion to the Ceiling. Add...
  • Page 52 Date: May 2017 Page No: 5 of 9 Description: HISPACE - CEILING FEED AND POWER POLE HABH_312 UPPER EXTRUSION ASSEMBLY INSTALL HALF TRAY COVER STEP 6: Insert Upper power Pole Extrusion inside ceiling cut-out (uncut edge down). Drop STEP 7: Drop Ceiling Feed cable down through ceiling cut-out down along the Power Pole.
  • Page 53 Date: May 2017 Page No: 6 of 9 Description: HISPACE - CEILING FEED AND POWER POLE HABH_312 ATTACH LOWER COVER ATTACH UPPER COVER STEP 8: Tuck cable and attach Power Pole Covers by engaging them into Lower Extrusion. STEP 9: Insert Upper Covers inside ceiling cut-out then engage into Upper Power Pole...
  • Page 54 ELECTRICS Date: May 2017 Page No: 7 of 9 Description: HISPACE - CEILING FEED AND POWER POLE HABH_312 ATTACH CEILING PLATES INSTALL HALF TRAY COVER WARNING : Do not connect to power source until installation is complete. All wire connections must be performed by a licensed electrician in accordance with applicable codes and regulations.
  • Page 55 Installation Guides Section: ELECTRICS Date: May 2017 Page No: 8 of 9 Description: HISPACE - CEILING FEED AND POWER POLE HABH_312 PLATES INSTALLATION NOTE: Temporarily remove plates, in order to push T-nuts into pre-drilled holes. Bring them back and fasten everything, as shown.
  • Page 56 Installation Guides Section: ELECTRICS Date: May 2017 Page No: 9 of 9 Description: HISPACE - CEILING FEED AND POWER POLE HABH_312 PLUG TO POWER BOX NOTE: To be connected to Power Box. Please refer to Installation Guide No. HABH_311a for information.
