Powerware Series
®
Eaton 9390/9390IT UPS
20–80 kVA
Installation and Operation Manual
For 9390IT 20-40 kVA and 9390 20-80 kVA UPS models

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9390IT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eaton 9390IT

Summary of Contents for Eaton 9390IT

  • Page 1 Powerware Series ® Eaton 9390/9390IT UPS 20–80 kVA Installation and Operation Manual For 9390IT 20-40 kVA and 9390 20-80 kVA UPS models...
  • Page 3 Powerware Series ® Eaton 9390/9390IT UPS 20–80 kVA Installation and Operation Manual For 9390IT 20-40 kVA and 9390 20-80 kVA UPS models...
  • Page 4 Schneider Electric. National Electrical Code and NEC are registered trademarks of National Fire Protection Association, Inc. All other trademarks are property of their respective companies. ECopyright 2004-2009 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton Corporation.
  • Page 5 Special Symbols The following are examples of symbols used on the UPS or accessories to alert you to important information: RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of electric shock symbol. CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for additional information, such as important operating and maintenance instructions.
  • Page 6 This page intentionally left blank.

  • Page 7: Table Of Contents

    ............. . . 4-10 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 8 ............... . 8-31 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 9 ................11-1 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 10 ............® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 11 List of Figures Figure 1‐1. Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) UPS ..........
  • Page 12 ............... . 12-2 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 13: Introduction

    AC power to protect the customer's load from all nine power failures. The Eaton 9390/9390IT UPS is available as a single module or a multiple module parallel system (see paragraph 1.3).

  • Page 14: Ups Standard Features

    It consists of a self-contained battery compartment permanently attached to the main unit (see Figure 1‐2.) The 9390IT internal battery model is available in a 2 string (80 batteries) and 3 string (120 batteries) configuration. The UPS is shipped with factory‐installed batteries and requires battery tray interconnection by an Eaton Customer Service Engineer prior to site use.

  • Page 15: X-Slot Communication Bay

    Line-up-and-match battery cabinets are wired through the side panels of the units. Optional X-Slot connectivity cards are quickly installed at the front of the unit and are hot-pluggable. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 16: Options And Accessories

    Contact your Eaton sales representative for information about the following options: 1.2.1 Integrated Battery Cabinets NOTE This item cannot be used with the 9390IT internal battery configuration. Battery backup protection can be enhanced by equipping the UPS system with up to four Eaton 9390 battery cabinets containing sealed lead‐acid, maintenance‐free batteries.

  • Page 17: Sync Control

    (inverter online) or if in Normal mode remains in Normal mode for a default time period of one hour. The High Alert mode time period is configurable by an Eaton Customer Service Engineer. High Alert mode allows the user to place the unit online with full protection when outside conditions could cause a power disturbance.

  • Page 18: Basic System Configurations

    The UPS system configuration can be enhanced by adding optional accessories such as a Remote Emergency Power-off (REPO) control, RMP II, or X-Slot communication cards. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 19: Conventions Used In This Manual

    Eaton 9390 Sync Control Installation and Operation Manual Visit www.eaton.com/powerquality or contact your Eaton service representative for information on how to obtain copies of these manuals. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 20: Getting Help

    Please call the Eaton Help Desk at: 1-800-843-9433 1-919-870-3028 United States: 1-800-461-9166 ext 260 Canada: Call your local service representative All other countries: ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 21: Safety Warnings

    In order to change the 9390 UPS batteries from lead acid to Nicad or from NiCad to lead acid, the internal firmware setup of the UPS must be changed by your Eaton Service representative. Failure to do so will cause battery pack damage and loss of battery backup capability.
  • Page 22 Une mise au rebut réglementaire des batteries est obligatoire. Consulter les règlements en vigueur dans votre localité. Ne jamais jeter les batteries au feu. L'exposition aux flammes risque de les faire exploser. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 23: Section I - Installation

    Section I Installation Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 24 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 25: Ups Installation Plan And Unpacking

    Engineer, or the warranty terms specified on page 15-1 become void. This service is offered as part of the sales contract for the UPS. Contact your Eaton service representative in advance (usually a two-week notice is required) to reserve a preferred startup date.

  • Page 26: Preparing For Wiring The Ups System

    The cabinet is shipped bolted to a wooden pallet and protected with outer protective packaging material (see Figure 3‐1 or Figure 3‐2). Shipping Pallet Figure 3‐1. Eaton 9390 UPS (20–80 kVA) as Shipped on Pallet ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 27: Figure 3-2. Eaton 9390It Ups (20-40 Kva) As Shipped On Pallet

    C A U T I O N Do not install a damaged cabinet. Report any damage to the carrier and contact your Eaton service representative immediately. Do not tilt the UPS cabinet more than 10° sideways from vertical or the cabinet may tip over.
  • Page 28 NOTE While waiting for installation, protect the unpacked cabinet from moisture, dust, and other harmful contaminants. Failure to store and protect the UPS properly may void your warranty. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 29: Installing The Ups System

    Unloading the Eaton 9390 UPS Cabinet from the Pallet To install a standard UPS cabinet, perform the procedures in section 4.2.1. To install a 9390IT UPS cabinet, perform the procedures in section 4.2.2. 4.2.1 Unloading the Standard 9390 Cabinet The UPS cabinet is bolted to a wooden pallet supported by wood skids.
  • Page 30 Remove three bolts securing the removable skid and remove the skid (see Figure 4‐2 on page 4-4). Close and latch the door before rolling the cabinet from the pallet. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 31: Figure 4-1. Removing The Front Shipping Bracket On The Eaton 9390 Ups

    Front Anti‐tip/Shipping Bracket Lower Shipping Bracket Bolts (2) (note wide base) Figure 4‐1. Removing the Front Shipping Bracket on the Eaton 9390 UPS ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 32: Figure 4-2. Removing The Rear Shipping Bracket On The Eaton 9390 Ups

    Roll the cabinet to the final installation location. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 33: Unloading The 9390It Cabinet

    NOTE The cabinet is front and top heavy. Do not remove the front shipping skid until all other brackets have been removed to prevent the unit from tipping forward during the other procedures. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 34 Carefully remove the front skid. The cabinet is front heavy. To prevent possible injury, do not stand directly in front of the cabinet when removing the cabinet from the pallet. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 35: Figure 4-3. Removing The Front Shipping Bracket On The Eaton 9390It Ups

    Front Anti‐tip/Shipping Bracket (DO NOT REMOVE) Lower Shipping Bracket Bolts (2) (note wide base) Figure 4‐3. Removing the Front Shipping Bracket on the Eaton 9390IT UPS ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual...

  • Page 36: Figure 4-4. Removing The Rear Shipping Bracket On The Eaton 9390It Ups

    Removable Skid Pallet Lower Shipping Bracket Bolts (2) Rear Shipping Bracket Figure 4‐4. Removing the Rear Shipping Bracket on the Eaton 9390IT UPS ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 37: Battery Cabinet Installation

    4.7. Battery Cabinet Installation NOTE This procedure does not apply to the 9390IT internal battery configuration. To install the battery cabinet, refer to the Eaton 9390 Integrated Battery Cabinet (Models IBC-S and IBC-L) Installation Manual. After the battery cabinet is installed, return to paragraph 4.7 to wire the UPS and battery cabinet.

  • Page 38: Integrated Distribution Cabinet Installation

    After the IAC is installed and wired, return to paragraph 4.7 to complete the UPS cabinet wiring. UPS Sidecar Wiring To wire a UPS Sidecar, refer to the Eaton 9390 UPS Sidecar Installation and Operation Manual. After the UPS Sidecar is wired, return to paragraph 4.7 to complete the UPS cabinet wiring.
  • Page 39 Note wiring connections for dual-feed systems. 15. If wiring an IDC or IAC, proceed to Step 16; otherwise, proceed to Step 19. ® 4-11 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 40 C A U T I O N DO NOT attempt to connect an external battery or DC source to the 9390IT cabinet. It has its own internal batteries and damage to the cabinet may occur.

  • Page 41: Installing Interface Connections

    15. Reinstall the door removed in Step 3 and secure with the retained hardware. 16. Close the door and secure the latch. ® 4-13 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 42: Tb1 Battery Cabinet Connections

    Route the UV trip and Aux wiring harness supplied with the battery cabinet from the battery cabinet to the UPS cabinet. Refer to Appendix A and to the Eaton 9390 Integrated Battery Cabinet (Models IBC-S and IBC-L) Installation Manual for wiring access information.

  • Page 43: X-Slot Connections

    X-Slot terminals, route the wiring through the internal opening in the X-Slot communication bay. For installation and setup of an X-Slot card, please contact Eaton (see page 1-8). To install wiring for connections: If not already installed, install the LAN and telephone drops.

  • Page 44: Installing Accessories And Parallel System Control Wiring

    NOTE The installation checklist MUST be completed prior to starting the UPS system for the first time. 4-16 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 45 - A ground conductor is properly installed. - Air conditioning equipment is installed and operating correctly. - The area around the installed UPS system is clean and dust‐free. (Eaton recommends that the UPS be installed on a level floor suitable for computer or electronic equipment.) - Adequate workspace exists around the UPS and other cabinets.
  • Page 46 - Controller Area Network (CAN) wiring between the UPMs is properly installed. - Pull chain wiring between the UPMs is properly installed. - Adequate workspace exists around the UPMs, parallel tie cabinet, and other cabinets. - Startup and operational checks are performed by an authorized Eaton Customer Service Engineer. 4-18 ®...
  • Page 47 INSTALLING THE UPS SYSTEM Notes _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ ® 4-19 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 48 INSTALLING THE UPS SYSTEM This page intentionally left blank. 4-20 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 49: Installing A Remote Emergency Power-Off Control

    A latching-type Remote Emergency Power-off (REPO) switch can be used in an emergency to shut down the UPS and remove power to the critical load from a location away from where the UPS is installed. Figure 5‐1 shows an Eaton REPO switch.

  • Page 50: Figure 5-2. Repo Wiring

    REPO switch wiring must be according to UL Class I requirements. Secure the UPS by reversing all steps taken to prepare it for a REPO station installation. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 51: Installing Options And Accessories

    UPS. Remove the X-Slot cover panel to gain access to the X‐Slot. See Drawing 164201603-10 starting on page A-46 for location of the X-Slot communication bay. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 52: Installing Parallel System Control Wiring

    11. Install parallel system backup control (pull chain) wiring between UPMs. See Drawing 164201603-10 starting on page A-46 for terminal locations and wiring information. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 53: Installing A Remote Monitor Panel

    Install 120 Vac power wiring from the critical bus to the RMP II. See Drawing 164201603-10 starting on page A-46 for terminal location and wiring information. NOTE Setup of the Powerware Hot Sync CAN Bridge Card must be performed by an authorized Eaton Customer Service Engineer. Contact service to schedule a date.

  • Page 54: Installing A Relay Interface Module

    Install 120 Vac power wiring from the critical bus to the RIM II. See Drawing 164201603-10 starting on page A-46 for terminal location and wiring information. NOTE Setup of the Powerware Hot Sync CAN Bridge Card must be performed by an authorized Eaton Customer Service Engineer. Contact service to schedule a date.
  • Page 55 Contacts are closed when approximately two minutes of battery time is remaining before the critical load is lost. UTILITY FAILURE Pins 6 and 15 Contacts are closed when Utility Failure is detected. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 56: Installing A Supervisory Contact Module

    Install 120 Vac power wiring from the critical bus to the SCM II. See Drawing 164201603-10 starting on page A-46 for terminal location and wiring information. NOTE Setup of the Powerware Hot Sync CAN Bridge Card must be performed by an authorized Eaton Customer Service Engineer. Contact service to schedule a date.

  • Page 57: Figure 6-2. Supervisory Contact Module Ii Tb2

    NOTE Supervisory contacts are rated at 2.0A at 28 Vdc or 120 Vac and 0.15A at 115 Vdc. NOTE Supervisory contacts require an external power supply. Internal 24 Vdc is not capable of supplying contact current. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 58 INSTALLING OPTIONS AND ACCESSORIES ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 59: Section Ii - Operation

    Section II Operation Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 60 6-10 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 61: Understanding Ups Operation

    380, 400, 414, and 480 Vac, three-phase, true online system that provides conditioned and uninterruptible AC power to the UPS system's output. The 9390IT UPS model is only available in 208V and 480V. The UPS supports process control, data processing, telecommunications/PBX, research, and non-patient medical equipment.

  • Page 62: Single Module Reverse Transfer (Rt)

    7.1.1 Single Module RT Modes The Eaton 9390/9390IT UPS supports a critical load in three different modes of operation. The UPS can automatically use all three modes, as required. The standard operation modes are: Normal mode –...

  • Page 63: Normal Mode - Rt

    The battery is always connected to the UPS and ready to support the inverter should the utility input become unavailable. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 64: Bypass Mode - Rt

    Trickle Current Closed Battery Breaker Energized Open De-Energized Battery Figure 7‐3. Path of Current through the UPS in Bypass Mode – RT ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 65 Bypass mode is a normal operating mode, not an alarm condition. However, if the UPS is unable to return to Normal mode following an automatic transfer to Bypass mode, an alarm condition is recorded. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 66: Energy Saver Mode - Rt

    Energy Saver mode is a normal operating mode, and not an alarm condition. While the UPS is in this mode, the NORMAL light on the front display will illuminate. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 67: Battery Mode - Rt

    If the bypass source is available, the UPS transfers to bypass instead of shutting down. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 68: Multiple Module Parallel System

    Decreasing the load generally increases the battery support time. Multiple Module Parallel System Parallel operation extends the normal operation of Eaton 9390 UPS units by offering increased capacity and/or redundant capability. The parallel system continues to maintain power to the critical loads during commercial electrical power brownout, blackout, overvoltage, undervoltage, and out‐of‐tolerance frequency conditions.

  • Page 69: Multiple Module Parallel System Modes

    7.2.1 Multiple Module Parallel System Modes Similar to the single module system, the Eaton 9390 UPS parallel system supports a critical load in three different modes of operation. The standard operation modes are: In Normal mode, the paralleled UPMs supply the critical load with clean, filtered power.

  • Page 70: Normal Mode - Parallel

    Bypass mode. The parallel system automatically returns to Normal mode when the overload condition is cleared and system operation is restored within specified limits. 7-10 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 71: Bypass Mode - Parallel

    If more modules than can support the load must be taken offline, the load must be transferred to maintenance bypass or shut down. ® 7-11 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 72 In the Parallel Capacity (N + 0) arrangement, if one unit trips offline and goes to bypass, the remaining units also go to bypass. 7-12 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 73: Battery Mode - Parallel

    When this event occurs, the system shuts down. If the bypass source is available, the system transfers to bypass instead of shutting down. ® 7-13 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 74: Functional Description

    672 hours (28 days) maximum rest time. If the battery voltage falls below the opportunity charge level of 2.1 volts/cell during the first 240 hours of the rest period, an alarm sounds. 7-14 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 75: Bypass

    A backfeed contactor is also provided. 7.3.5 Batteries The UPS operates from battery strings from 192 cells (384V nominal) to 240 cells (380V/400V/415V/480V nominal). ® 7-15 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 76 UNDERSTANDING UPS OPERATION This page intentionally left blank. 7-16 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 77: Using The Control Panel

    See Chapter 9, “UPS Operating Instructions,” for use of the operational controls. When the UPS powers up, the screen displays the Eaton logo as shown in Figure 8‐1. To advance to the Main Menu and Mimic screen, press any control panel pushbutton once.

  • Page 78: Using The Lcd And Pushbuttons

    Control UPS operation (see paragraph 8.3) After approximately 30 minutes, the display screen darkens. To restore the screen, press any pushbutton once. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 79: Using The Main Menu

    02 / 25 / 2004 INPUT BATT STSW OUTPUT BYPASS EVENTS METERS CONTROLS SETUP LOAD OFF Figure 8‐3. Main Menu and Mimic Screen (Normal Mode) ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 80: Event Screens

    BYPASS AC UNDER VOLTAGE NOTICE: BATTERY VOLTAGE LOW NOTICE: NO SYNC ON NOTICE: BYPASS NOT AVAILABLE NOTICE: CONFIGURATION ERROR HISTORY Figure 8‐4. Active Events Screen ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 81: Figure 8-5. History Screen

    UPS OFF NOTICE: 5 of 29 02 / 26 / 2004 10 : 20 : 03 . 539 EVENTS Figure 8‐5. History Screen ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 82: Unit Meter Screens

    UPS, as well as the kVA, kW, and power factor measurements. OUTPUT - UNIT FREQ LEAD SYSTEM UNIT Figure 8‐6. Unit Output Meter Screen ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 83: Figure 8-7. Unit Input Meter Screen

    BYPASS - UNIT FREQ LEAD SYSTEM UNIT Figure 8‐8. Unit Bypass Meter Screen ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 84: Figure 8-9. Unit Battery Meter Screen

    The Battery screen displays the battery voltage (Vdc), the battery current (Idc), the minutes of battery time remaining, and battery temperature. Battery temperature must be set up by an authorized Eaton Customer Service Engineer. When battery life decreases to less than 20%, Check Battery is displayed.

  • Page 85: Battery Discharge Log

    AVERAGE TIME ON BATTERY ** M ** S TOTAL TIME ON BATTERY ** H ** M Figure 8‐11. Battery Discharge Log Summary Screen ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 86: Figure 8-12. Battery Discharge Log Screen

    ** M ** S LOAD WHEN ON BATTERY ***.** KW END VOLTAGE : ***.** V RESET SUMMARY Figure 8‐12. Battery Discharge Log Screen 8-10 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 87: Kw Demand Log

    TOTAL TIME OVER LIMIT ** MINUTES TOTAL KWH USED OVER LIMIT *** . ** KWH SETUP Figure 8‐13. kW Demand Log Summary Screen ® 8-11 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 88: Figure 8-14. Kw Demand Log Screen

    2 MINUTES KWH USED OVER LIMIT *** . ** NUM TIMES OVER THIS INTERVAL RESET SUMMARY Figure 8‐14. kW Demand Log Screen 8-12 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 89: Figure 8-15. Current Kw Demand Log Setup Screen 1

    CURRENT KW DEMAND LOG SETUP TIME INTERVAL MONITORED 3 MINUTES MAXIMUM LEVEL (KW) *** KW CHANGE Figure 8‐15. Current kW Demand Log Setup Screen 1 ® 8-13 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 90: Figure 8-16. Current Kw Demand Log Setup Screen 2

    CURRENT KW DEMAND LOG SETUP TIME INTERVAL MONITORED MAXIMUM LEVEL (KW) SELECT Figure 8‐16. Current kW Demand Log Setup Screen 2 8-14 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 91: Figure 8-17. Time Interval Monitored Setup Screen

    Time Interval Monitored Setup screen is redisplayed. TIME INTERVAL MONITORED SETUP 0000 ABORT SAVE RETRY Figure 8‐18. Time Interval Monitored Setup Save Screen ® 8-15 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 92: Figure 8-19. Maximum Level (Kw) Setup Screen

    Maximum Level (kW) Setup screen is redisplayed. MAXIMUM LEVEL (KW) SETUP 0000 SAVE RETRY ABORT Figure 8‐20. Maximum Level (kW) Setup Save Screen 8-16 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 93: Figure 8-21. Maximum Current Log Summary Screen

    MAXIMUM % OF FULL LOAD *** . ** % TOTAL TIME OVER LIMIT ** MINUTES SETUP Figure 8‐21. Maximum Current Log Summary Screen ® 8-17 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 94: Figure 8-22. Maximum Current Log Screen (Three-Phase Measurement)

    2 MINUTES NUM TIMES OVER THIS INTERVAL PHASES OVER THIS INTERVAL RESET SUMMARY Figure 8‐23. Maximum Current Log Screen (Individual Phase Measurement) 8-18 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 95: Figure 8-24. Maximum Current Log Setup Screen 1

    MAXIMUM % OF FULL LOAD *** % LEVEL BASED ON 3 PHASE AVERAGE CHANGE Figure 8‐24. Maximum Current Log Setup Screen 1 ® 8-19 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 96: Figure 8-25. Maximum Current Log Setup Screen 2

    MAXIMUM CURRENT LOG SETUP TIME INTERVAL MONITORED MAXIMUM % OF FULL LOAD CALCULATION METHOD SELECT Figure 8‐25. Maximum Current Log Setup Screen 2 8-20 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 97: Figure 8-26. Time Interval Monitored Setup Screen

    Time Interval Monitored Setup screen is redisplayed. TIME INTERVAL MONITORED SETUP 0000 ABORT SAVE RETRY Figure 8‐27. Time Interval Monitored Setup Save Screen ® 8-21 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 98: Figure 8-29. Maximum % Of Full Load Setup Save Screen

    Maximum % of Full Load Setup screen is redisplayed. MAXIMUM % OF FULL LOAD SETUP SAVE RETRY ABORT Figure 8‐29. Maximum % of Full Load Setup Save Screen 8-22 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 99: Figure 8-30. Calculation Method Setup Screen

    MAXIMUM CURRENT LOG SETUP LEVEL BASED ON 3 PHASE AVERAGE LEVEL BASED ON INDIVIDUAL PHASES SELECT Figure 8‐30. Calculation Method Setup Screen ® 8-23 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 100: Figure 8-31. System Meters Screen

    SELECT pushbutton to display the screen. SYSTEM METERS TOTAL SYSTEM UNIT 1 UNIT 2 UNIT 3 ENTER PASSWORD UNIT 4 SELECT Figure 8‐31. System Meters Screen 8-24 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 101: Figure 8-32. Total System Output Meter Screen

    UPSs, and the PF is calculated from the total values for the kVA and kW. OUTPUT TOTAL SYSTEM FREQ LEAD SYSTEM UNIT Figure 8‐32. Total System Output Meter Screen ® 8-25 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 102: Figure 8-33. Output Unit X Meter Screen

    UPS, as well as the kVA, kW, and power factor measurements for the selected UPS. OUTPUT UNIT X FREQ LEAD SYSTEM UNIT Figure 8‐33. Output Unit X Meter Screen 8-26 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 103: Figure 8-34. Input Unit X Meter Screen

    UPS. BYPASS UNIT X FREQ LEAD SYSTEM UNIT Figure 8‐35. Bypass Unit X Meter Screen ® 8-27 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 104: Figure 8-36. Battery Unit X Meter Screen

    The Battery screen displays the battery voltage (Vdc), the battery current (Idc), the minutes of battery time remaining, and battery temperature. Battery temperature must be set up by an authorized Eaton Customer Service Engineer When battery life decreases to less than 20%, Check Battery is displayed.

  • Page 105: Figure 8-38. System Setup Level 0 Screen

    SELECT pushbutton to display the function screen. SYSTEM SETUP LEVEL 0 ENTER PASSWORD CONTRAST ADJUST VERSIONS UNIT TYPE SELECT Figure 8‐38. System Setup Level 0 Screen ® 8-29 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 106: Figure 8-39. Contrast Adjust Screen

    To return to the System Setup screen, press the pushbutton. VERSIONS 57.00 DISPLAY 0.54 MINI CSB 3.00 GATE DRIVE 0.00 BOOTLOADER 0.00 Figure 8‐40. Versions Screen 8-30 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 107: System Setup Level 1 Screens

    DONE pushbutton. The System Setup Level 1 menu screen is displayed. The default password is L1. ENTER PASSWORD DONE Figure 8‐42. Enter Password Screen ® 8-31 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 108: Figure 8-43. System Setup Level 1 Screen

    LOG OUT ENTER PASSWORD CHANGE PASSWORD ENTER PASSWORD CONTRAST ADJUST VERSIONS UNIT TYPE SELECT Figure 8‐43. System Setup Level 1 Screen 8-32 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 109: Figure 8-44. Change Password Screen

    System Setup screen displays. If RETRY is pressed, the Change Password screen is redisplayed. CHANGE PASSWORD OLD: NEW: SAVE RETRY ABORT Figure 8‐45. Change Password Save Screen ® 8-33 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 110: Figure 8-46. Time Format Screen

    Set Date and Time screen. To return to the System Setup screen, press the pushbutton. TIME FORMAT SETUP MM/DD/YYYY DD/MM/YYYY SELECT Figure 8‐46. Time Format Screen 8-34 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 111: Figure 8-47. Set Date And Time Mm/Dd/Yyyy Screen

    SET DATE AND TIME MM/DD/YYYY MONTH DATE YEAR HOUR MINUTE SAVE 2004 Figure 8‐47. Set Date and Time MM/DD/YYYY Screen ® 8-35 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 112: Figure 8-48. Set Date And Time Dd/Mm/Yyyy Screen

    SET DATE AND TIME DD/MM/YYYY DATE MONTH YEAR HOUR MINUTE SAVE 2004 Figure 8‐48. Set Date and Time DD/MM/YYYY Screen 8-36 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 113: Figure 8-49. Com Port Setup Screen

    SELECT pushbutton. To return to the System Setup screen, press the pushbutton. COM PORT SETUP COM 1 COM 2 COM 3 SELECT Figure 8‐49. COM Port Setup Screen ® 8-37 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 114: Figure 8-50. Com Setup Screen

    SAVE or ABORT. Once the action is completed, the COM Port Setup screen appears. COM 1 SETUP BAUD RATE 19200 DATA BITS STOP BITS PARITY NONE ABORT SAVE Figure 8‐50. COM Setup Screen 8-38 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 115: System Controls Screen

    The CHGR pushbutton switch toggles the charger function On and Off. The PM pushbutton switch toggles the power module function On and Off. ® 8-39 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 116: Figure 8-53. System Controls Screen 3

    Energy Saver commands will not be available for units not configured for Energy Saver mode. Selecting the ESM option on a unit not cofigured for ESM will result in the following screen. 8-40 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 117: Load Off Screen

    LOAD OFF and Shutdown screens, see Chapter 9, “UPS Operating Instructions.” HOLD LOAD OFF BUTTON FOR 3 SECONDS TO TURN OFF LOAD CANCEL LOAD OFF Figure 8‐56. Load Off Screen ® 8-41 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 118: Reading The Status Indicators

    The indicator flashes until acknowledged by pressing any control panel pushbutton once. For more information about audible horns, see “System Event Horns” on page 11-1. 8-42 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 119: Ups Operating Instructions

    Starting the UPS in Normal Mode NOTE When starting a 9390IT UPS with internal batteries, remove the battery compartment access panel by loosening the wing nut at the bottom of the panel and lifting the panel off the retaining hook at the top.

  • Page 120: Starting The Ups In Bypass Mode

    On the System Controls screen, the power module (PM) status should indicate SHUTDOWN. Press the pushbutton to display System Controls Screen 2. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 121: Transfer From Normal To Bypass Mode

    The UPS is now operating in Normal mode, and the NORMAL status indicator is illuminated. us indicates power module (PM) stat ONLINE. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 122: Transfer From Normal To Energy Saver Mode

    9.1.6 Transfer from Normal to Energy Saver Mode To transfer the critical load to Energy Saver mode: NOTE The Energy Saver mode commands are displayed only if enabled at the factory or by an Eaton Customer Service Engineer. Press the pushbutton on the main menu bar.

  • Page 123: Transfer From Normal To High Alert Mode

    9.1.8 Transfer from Normal to High Alert Mode To transfer the critical load to High Alert mode: NOTE The High Alert mode commands are displayed only if enabled at the factory or by an Eaton Customer Service Engineer. Press the pushbutton on the main menu bar.

  • Page 124: Transfer From Bypass To Energy Saver Mode

    9.1.10 Transfer from Bypass to Energy Saver Mode To transfer the critical load to Energy Saver mode: NOTE The Energy Saver mode commands are displayed only if enabled at the factory or by an Eaton Customer Service Engineer. Press the pushbutton on the main menu bar.

  • Page 125: Transfer From Bypass To High Alert Mode

    9.1.12 Transfer from Bypass to High Alert Mode To transfer the critical load to High Alert mode: NOTE The High Alert mode commands are displayed only if enabled at the factory or by an Eaton Customer Service Engineer. Press the pushbutton on the main menu bar.

  • Page 126: Transfer From Energy Saver To High Alert Mode

    SAVER. The Bypass status indicates ON. The UPM status indicates ONLINE. If the battery is not charging, the power module is off. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 127: Transfer From Normal To Bypass Mode And Shut Down Ups

    System Controls Screen 2. Press the CHGR ON or CHGR OFF pushbutton on the System Controls menu bar to toggle the charger on or off. ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 128: Using The Ups Load Off Pushbutton

    All power to the critical load is lost when the REPO switch is activated in the following step. You should use this feature only when you want to de‐energize the critical load. 9-10 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 129: Figure 9-1. Repo Operation

    UPS OPERATING INSTRUCTIONS NOTE The following instructions are for the Eaton-supplied REPO switch. If a customer-supplied REPO switch is used, it may not activate in the same manner; refer to the operating instructions provided with the switch. To use the REPO switch: Firmly push the red pushbutton until it locks into place.

  • Page 130: Multiple Module Parallel Operation

    Starting the Parallel System in Normal Mode NOTE When starting a 9390IT UPS with internal batteries, remove the battery compartment access panel by loosening the wing nut at the bottom of the panel and lifting the panel off the retaining hook at the top.

  • Page 131: Starting The Parallel System In Bypass Mode

    UPM power processors remain on. W A R N I N G Power is present inside the UPM cabinets. ® 9-13 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 132: Transfer Parallel System From Bypass To Normal Mode

    If it is necessary to isolate the UPM from the critical bus, open the module output breaker on the tie cabinet or distribution panel. 9-14 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 133: Restarting A Single Upm

    To restart a single UPM: NOTE When starting a 9390IT UPS with internal batteries, remove the battery compartment access panel by loosening the wing nut at the bottom of the panel and lifting the panel off the retaining hook at the top.

  • Page 134: Using The Ups Load Off Pushbutton

    When LOAD OFF is selected and held for three seconds, the input, output, and bypass backfeed contactors open, the battery breaker or disconnect is tripped, and the power module is turned off. 9-16 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 135: Using The Parallel System Remote Emergency Power-Off Switch

    NOTE The following instructions are for the Eaton-supplied REPO switch. If a customer-supplied REPO switch is used, it may not activate in the same manner; refer to the operating instructions provided with the switch.

  • Page 136: Figure 9-2. Repo Operation

    DO NOT insert the key until the fault is resolved. Activated Deactivated Pushbutton locked into place Unlock pushbutton to release Figure 9‐2. REPO Operation 9-18 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 137: Using Features And Options

    UPS horn may not be heard immediately. C A U T I O N Contacts should not be operated in excess of 120 Vac @ 5A maximum. ® 10-1 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 138: Remote Monitor Panel

    The RMP II can be flush‐mounted or surface‐mounted on a desktop, or secured to a wall. Figure 10‐1 shows an RMP II. Figure 10‐1. Remote Monitor Panel II 10-2 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 139 The UPS is preparing to shut down because the UPS is in Battery mode and the DC voltage is approaching its low limit. This indicator is accompanied by a horn. ® 10-3 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 140: Relay Interface Module

    UTILITY Pins 6 and 15 Contacts are closed when Utility Failure is detected. FAILURE 10-4 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 141: Supervisory Contact Module

    TB2‐10 through TB2‐12 ON BATTERY TB2‐13 through TB2‐15 UPS ALARM TB2‐16 through TB2‐18 ON BYPASS TB2‐19 through TB2‐21 SHUTDOWN IMMINENT TB2‐22 through TB2‐24 ® 10-5 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 142 USING FEATURES AND OPTIONS This page intentionally left blank. 10-6 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 143: Responding To System Events

    History log. The messages are divided into four categories: alarms, notices, status, and commands. The following tables contain the events displayed on the Events screen of the control panel. ® 11-1 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 144 * Log codes indicate where the UPS records the event: H = History log, HA = History and Active logs, and A = Active log only. 11-2 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 145 * Log codes indicate where the UPS records the event: H = History log, HA = History and Active logs, and A = Active log only. ® 11-3 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 146 * Log codes indicate where the UPS records the event: H = History log, HA = History and Active logs, and A = Active log only. 11-4 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 147 * Log codes indicate where the UPS records the event: H = History log, HA = History and Active logs, and A = Active log only. ® 11-5 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 148 * Log codes indicate where the UPS records the event: H = History log, HA = History and Active logs, and A = Active log only. 11-6 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 149 * Log codes indicate where the UPS records the event: H = History log, HA = History and Active logs, and A = Active log only. ® 11-7 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 150 * Log codes indicate where the UPS records the event: H = History log, HA = History and Active logs, and A = Active log only. 11-8 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 151: Communication

    LAN and telephone drops for use with X-Slot cards must be provided by facility planners or the customer. For installation and setup of an X-Slot card, please contact Eaton (see page 1-8). Refer to the manual supplied with the X-Slot card for user instructions.

  • Page 152: Powerware Lansafe Power Management Software

    UPS on the phone. The user has exactly the same capabilities as if using a terminal connected directly to an RS-232 port. 12-2 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 153 Numeric paging support allows the UPS to call a paging service and send numeric messages. Housekeeping – The Housekeeping function maintains the link between the UPS and modem. ® 12-3 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 154 COMMUNICATION This page intentionally left blank. 12-4 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 155: Maintaining The Ups System

    If the string requires service, refer to the battery manufacturer's operating manual for instructions on battery maintenance, or contact your Eaton service representative. ® 13-1 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 156: Performing Preventive Maintenance

    UPS system. Contact your Eaton service representative for more information about service offerings. 13-2 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 157: Battery Maintenance

    UPS system operation and teaches you how to perform first level corrective maintenance. For more information about training and other services, contact the Eaton Help Desk (see page 1-8). ® 13-3 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 158 MAINTAINING THE UPS SYSTEM This page intentionally left blank. 13-4 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 159: Product Specifications

    6 kV OC, 3 kA SC per ANSI 62.41 and IEC 801‐4 Battery Voltage 384 Vdc (208V/220V units only) 432 Vdc 480 Vdc ® 14-1 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 160: Ups System Output

    Meets IEC 801‐2 specifications. Withstands up to 25 kV pulse without Immunity damage and with no disturbance or adverse effect to the critical load. 14-2 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 161: Multiple Module Parallel Specifications

    480 Vac nominal, adjustable from 466 Vac to 494 Vac Operating Output Current See Appendix A, Table T through Table W. ® 14-3 Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 162 PRODUCT SPECIFICATIONS This page intentionally left blank. 14-4 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 163: Warranty

    Powerware-built battery cabinets (individually and collectively, the ”Warranted Items”) are free from defects in material and workmanship. If, in the opinion of Eaton, a Warranted Item is defective and the defect is within the terms of this Warranty, Eaton's sole obligation will be to repair or replace such defective item (including by providing service, parts, and labor, as applicable), at the option of Eaton.
  • Page 164 WARRANTY 15-2 ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...

  • Page 165: Appendix A Installation Information

    Optional Remote Emergency Power-off 164201603-14 Optional Remote Monitor Panel II 164201603-15 Optional Remote Relay Interface Module II 164201603-16 Optional Remote Supervisory Contact Module II ® Eaton 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 166 STANDARD 9390/9390IT UPS BATTERY CABINET UPS CABINET DESCRIPTION: Eaton 9390/9390IT UPS SYSTEM DRAWING NO: SHEET: 164201603-1 1 of 1 REVISION: DATE: 091509 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 167 40/40 KVA, 40/30 KVA, AND 40/20 KVA CONFIGURATIONS DESCRIPTION: Eaton 9390IT UPS SYSTEM DRAWING NO: SHEET: 164201603-2 1 of 1 REVISION: DATE: 091509 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 168 The UPS equipment operating environment must meet the weight requirements shown in Table A and the size requirements shown on Drawing 164201603-11. The UPS cabinet is palleted separately from accessory cabinets for shipping. The 9390IT UPS models with interanl battery configuration ship with batteries installed.
  • Page 169 0-40°C (32-104°F) Recommended Operating Range: 20-25°C (68-77°F) Maximum Relative Humidity: 95%, noncondensing The UPS ventilation requirements are shown in Table D. Table D. 9390 and 9390IT Air Conditioning or Ventilation Requirements During Full Load Operation Voltage Heat Rejection Ratings BTU/hr  1000/hr (kg‐cal/hr)
  • Page 170 9390-80/50 380/400/ 380/400/ 9390-80/60 415/480 415/480 9390-80/80 DESCRIPTION: UPS SYSTEM ONELINE CONFIGURATIONS DRAWING NO: SHEET: 164201603-4 1 of 1 REVISION: DATE: 071608 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 171 2. See Note 7 on page A-14 for DESCRIPTION: UPS SYSTEM ONELINE DRAWING neutral bonding instructions. DRAWING NO: SHEET: 164201603-5 1 of 6 REVISION: DATE: 071608 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 172 2. See Note 7 on page A-14 for DESCRIPTION: UPS SYSTEM ONELINE DRAWING neutral bonding instructions. DRAWING NO: SHEET: 2 of 6 164201603-5 REVISION: DATE: 021509 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 173 UPS and the maintenance bypass. DESCRIPTION: UPS SYSTEM ONELINE DRAWING DRAWING NO: SHEET: 164201603-5 3 of 6 REVISION: DATE: 091505 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 174 DRAWING NO: SHEET: 4 of 6 164201603-5 3. See Note 29 on page A-29 for neutral bonding instructions. REVISION: DATE: 091505 A-10 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 175 DRAWING NO: SHEET: 5 of 6 3. See Note 29 on page A-29 for 164201603-5 neutral bonding instructions. REVISION: DATE: 091505 A-11 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 176 DRAWING NO: SHEET: 6 of 6 3. See Note 29 on page A-29 for 164201603-5 neutral bonding instructions. REVISION: DATE: 091505 A-12 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 177 INSTALLATION INFORMATION Table F. Input/Output Ratings & External Wiring Requirements for the Powerware 9390/9390IT-40/20 Units Rating 50/60 Hz Basic Unit Rating at 0.9 lagging pF load Input and Bypass Input VOLTS 208/220 Output VOLTS 208/220 AC Input to UPS Rectifier (0.98 min.
  • Page 178 INSTALLATION INFORMATION Table G. Input/Output Ratings & External Wiring Requirements for the Powerware 9390/9390IT-40/30 Units Rating 50/60 Hz Basic Unit Rating at 0.9 lagging pF load Input and Bypass Input VOLTS 208/220 Output VOLTS 208/220 AC Input to UPS Rectifier (0.98 min.
  • Page 179 C A U T I O N DELTA SOURCES (TN‐S) - The Eaton 9390 UPS system can be operated only from a delta supply source that is fully floating and if the neutral‐forming transformer kit (PN 103005400) is installed in the UPS. The UPS cannot be operated from a mid‐point or end‐point grounded delta supply source.
  • Page 180 4 of 6, 5 of 6, and 6 of 6. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 164201603-6 4 of 23 REVISION: DATE: 071608 A-16 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 181 4 of 6, 5 of 6, and 6 of 6. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 5 of 23 164201603-6 REVISION: DATE: 071608 A-17 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 182 4 of 6, 5 of 6, and 6 of 6. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 6 of 23 164201603-6 REVISION: DATE: 071608 A-18 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 183 Customer ground can be run in any conduit listed in Table O. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 7 of 23 164201603-6 REVISION: DATE: 110106 A-19 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 184 Customer ground can be run in any conduit listed in Table O. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 164201603-6 8 of 23 REVISION: DATE: 071608 A-20 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 185 Customer ground can be run in any conduit listed in Table O. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 164201603-6 9 of 23 REVISION: DATE: 071608 A-21 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 186 Table O. All Eaton 9390 products can accommodate a double size neutral. Conduit sizes were chosen from NEC Table C1, type letters RHH, RHW, RHW‐2, TW, THW, THHW, THW‐2.
  • Page 187 (A, B, C, Neut, Gnd) Battery 1‐1/2 (Positive), (Negative), Gnd DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 11 of 23 164201603-6 REVISION: DATE: 110106 A-23 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 188 (A, B, C, Neut, Gnd) Battery (Positive), (Negative), Gnd DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 164201603-6 12 of 23 REVISION: DATE: 110106 A-24 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 189 (A, B, C, Neut, Gnd) Battery (Positive), (Negative), Gnd DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 164201603-6 13 of 23 REVISION: DATE: 071608 A-25 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 190 (A, B, C, Neut, Gnd) Battery (Positive), (Negative), Gnd DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 164201603-6 14 of 23 REVISION: DATE: 071608 A-26 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 191 The recommended line‐to‐line load unbalance is 50% or less. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 15 of 23 164201603-6 REVISION: DATE: 071608 A-27 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 192 The battery disconnect device should be installed between the battery cabinet and the UPS. The 9390IT UPS model with internal battery configuration has an internal battery breaker for disconnecting the internal battery supply. See Drawing 164201603-12 on A-67.
  • Page 193 UPS. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 17 of 23 164201603-6 REVISION: DATE: 110106 A-29 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 194 C A U T I O N DELTA SOURCES (TN‐S) - The Eaton 9390 UPS system can be operated only from a delta supply source that is fully floating and if the neutral‐forming transformer kit (PN 103005400) is installed in the UPS. The UPS cannot be operated from a mid‐point or end‐point grounded delta supply source.
  • Page 195 Callout letters D , F , and G map to Drawing 164201603-5, sheets 4 of 6, 5 of 6, and 6 of 6. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 19 of 23 164201603-6 REVISION: DATE: 071608 A-31 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 196 Callout letters D , F , and G map to Drawing 164201603-5, sheets 4 of 6, 5 of 6, and 6 of 6. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 20 of 23 164201603-6 REVISION: DATE: 071608 A-32 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 197 Callout letters D , F , and G map to Drawing 164201603-5, sheets 4 of 6, 5 of 6, and 6 of 6. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 21 of 23 164201603-6 REVISION: DATE: 071608 A-33 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 198 Callout letters D , F , and G map to Drawing 164201603-5, sheets 4 of 6, 5 of 6, and 6 of 6. DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 22 of 23 164201603-6 REVISION: DATE: 071608 A-34 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 199 Outputs from UPMs Battery UPM 4 Battery DESCRIPTION: POWER WIRING INSTALLATION NOTES DRAWING NO: SHEET: 164201603-6 23 of 23 REVISION: DATE: 110106 A-35 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 200 OR PUNCH CONDUIT HOLES.) TOP VIEW DESCRIPTION: CONDUIT AND WIRE ENTRY LOCATIONS DRAWING NO: SHEET: 164201603-7 1 of 2 REVISION: DATE: 091505 A-36 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 201 AS REQUIRED, TO ROUTE WIRES BETWEEN CABINETS. DESCRIPTION: CONDUIT AND WIRE ENTRY LOCATIONS DRAWING NO: SHEET: 164201603-7 2 of 2 REVISION: DATE: 091505 A-37 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 202 (REMOVE PANELS TO DRILL OR PUNCH CONDUIT HOLES.) DESCRIPTION: CONDUIT AND WIRE ENTRY LOCATIONS DRAWING NO: SHEET: 164201603-8 1 of 2 REVISION: DATE: 091505 A-38 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 203 RIGHT SIDE VIEW BETWEEN CABINETS. DESCRIPTION: CONDUIT AND WIRE ENTRY LOCATIONS DRAWING NO: SHEET: 164201603-7 2 of 2 REVISION: DATE: 091505 A-39 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 204 DRAWING NO: SHEET: 164201603-9 1 of 6 terminals. REVISION: DATE: 032406 A-40 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 205 MODELS 80/40, 80/50, 80/60, AND 80/80 208V/220V INPUT AND 208V/220V OUTPUT DESCRIPTION: UPS POWER TERMINAL LOCATIONS DRAWING NO: SHEET: 164201603-9 2 of 6 REVISION: DATE: 091505 A-41 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 206 DRAWING NO: SHEET: 164201603-9 3 of 6 or opened to gain access to terminals. REVISION: DATE: 021509 A-42 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 207 208V/220V INPUT AND 208V/220V OUTPUT 380V/400V/415V/480V INPUT AND 380V/400V/415V/480V OUTPUT DESCRIPTION: UPS POWER TERMINAL LOCATIONS DRAWING NO: SHEET: 164201603-9 4 of 6 REVISION: DATE: 071608 A-43 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 208 DRAWING NO: SHEET: 164201603-9 5 of 6 or opened to gain access to terminals. REVISION: DATE: 071608 A-44 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 209 MODELS 80/40, 80/50, 80/60, AND 80/80 380V/400V/415V/480V INPUT AND 380V/400V/415V/480V OUTPUT DESCRIPTION: UPS POWER TERMINAL LOCATIONS DRAWING NO: SHEET: 164201603-9 6 of 6 REVISION: DATE: 071608 A-45 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 210 TO COMMON SIDE OF ISOLATED RELAY CONTACT. DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 164201603-10 1 of 15 REVISION: DATE: 032406 A-46 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 211 NOTES AND TERMINAL LOCATIONS or opened to gain access to DRAWING NO: SHEET: 2 of 15 terminals. 164201603-10 REVISION: DATE: 021509 A-47 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 212 EPO contact is not used. DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 3 of 15 164201603-10 REVISION: DATE: 032406 A-48 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 213 2. The building alarms can be programmed to display the alarm functional name. DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 4 of 15 164201603-10 REVISION: DATE: 091505 A-49 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 214 UPS is in Normal mode. DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 5 of 15 164201603-10 REVISION: DATE: 032406 A-50 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 215 The REPO switch must be a latching‐type switch with a dedicated circuit. DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 6 of 15 164201603-10 REVISION: DATE: 032406 A-51 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 216 DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 7 of 15 164201603-10 REVISION: DATE: 032406 A-52 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 217 24 Vdc at 6A Maximum DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 8 of 15 164201603-10 REVISION: DATE: 091505 A-53 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 218 NOTE All interface wiring is to be DRAWING NO: SHEET: 9 of 15 164201603-10 provided by the customer. REVISION: DATE: 091505 A-54 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 219 PARALLEL SYSTEM CAN WIRING DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 10 of 15 164201603-10 REVISION: DATE: 091505 A-55 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 220 INTERFACE WIRING INSTALLATION CONTROL (PULL CHAIN) WIRING NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 11 of 15 164201603-10 REVISION: DATE: 032406 A-56 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 221 CONTROL (PULL CHAIN) WIRING NOTES AND TERMINAL LOCATIONS WITH CUSTOMER SUPPLIED TIE DRAWING NO: SHEET: 12 of 15 PANEL 164201603-10 REVISION: DATE: 071608 A-57 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 222 CONTROL (PULL CHAIN) WIRING NOTES AND TERMINAL LOCATIONS FOR CUSTOMER–SUPPLIED DRAWING NO: SHEET: 13 of 15 TIE PANEL 164201603-10 REVISION: DATE: 071608 A-58 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 223 SUPERVISORY CONTACT MODULE II TERMINAL LOCATIONS DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 14 of 15 164201603-10 REVISION: DATE: 091505 A-59 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 224 RMP II, RIM II, OR SCM II TWISTED PAIR DESCRIPTION: INTERFACE WIRING INSTALLATION NOTES AND TERMINAL LOCATIONS DRAWING NO: SHEET: 15 of 15 164201603-10 REVISION: DATE: 091505 A-60 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 225 RIGHT SIDE VIEW DESCRIPTION: UPS CABINET DIMENSIONS DRAWING NO: SHEET: 164201603-11 1 of 6 REVISION: DATE: Dimensions are in millimeters [inches] 021509 A-61 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 226 BOTTOM VIEW DESCRIPTION: UPS CABINET DIMENSIONS DRAWING NO: SHEET: 2 of 6 164201603-11 REVISION: DATE: Dimensions are in millimeters [inches] 021509 A-62 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 227 RIGHT SIDE VIEW DESCRIPTION: UPS CABINET DIMENSIONS DRAWING NO: SHEET: 3 of 6 164201603-11 REVISION: DATE: Dimensions are in millimeters [inches] 021509 A-63 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 228 FRONT FRONT DESCRIPTION: UPS CABINET DIMENSIONS DRAWING NO: SHEET: 4 of 6 164201603-11 REVISION: DATE: Dimensions are in millimeters [inches] 021509 A-64 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 229 BOTTOM VIEW with OPTIONAL FLOOR MOUNTING BRACKETS DESCRIPTION: UPS CABINET DIMENSIONS DRAWING NO: SHEET: 5 of 6 164201603-11 REVISION: DATE: 021509 Dimensions are in millimeters [inches] A-65 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 230 BOTTOM VIEW with OPTIONAL SEISMIC MOUNTING BRACKETS DESCRIPTION: UPS CABINET DIMENSIONS DRAWING NO: SHEET: 6 of 6 164201603-11 REVISION: DATE: Dimensions are in millimeters [inches] 021509 A-66 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 231 9390IT UPS BATTERY DETAIL AND INTERNAL BATTERY DISCONNECT LOCATION DRAWING NO: SHEET: 164201603-12 1 of 1 Dimensions are in millimeters [inches] REVISION: DATE: 021509 A-67 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 232 Minimum wire size #22 AWG. DESCRIPTION: OPTIONAL REMOTE EMERGENCY POWER‐OFF DRAWING NO: SHEET: 164201603-13 1 of 1 Dimensions are in millimeters [inches] REVISION: DATE: 071608 A-68 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 233 OPTIONAL REMOTE MONITOR PANEL II (RMP II) DRAWING NO: SHEET: 164201603-14 1 of 1 REVISION: DATE: 091505 Dimensions are in millimeters [inches] A-69 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 234 OPTIONAL RELAY INTERFACE MODULE II (RIM II) DRAWING NO: SHEET: 164201603-15 1 of 2 REVISION: DATE: Dimensions are in millimeters [inches] 091505 A-70 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 235 15–PIN D–SUB CONNECTORS DESCRIPTION: OPTIONAL RELAY INTERFACE MODULE II (RIM II) DRAWING NO: SHEET: 164201603-15 2 of 2 REVISION: DATE: 091505 A-71 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 236 OPTIONAL SUPERVISORY CONTACT MODULE II (SCM II) DRAWING NO: SHEET: 164201603-16 1 of 1 Dimensions are in millimeters [inches] REVISION: DATE: 091505 A-72 Eaton ® 9390 UPS (20–80 kVA) and 9390IT (20-40 kVA) Installation and Operation Manual 164201603 Rev 4 www.eaton.com/powerquality...
  • Page 238 *1642016034* 164201603 4...

This manual is also suitable for:

9390Powerware series

Table of Contents
