Sumake ACPN39 Quick Start Manual

Push or push and trigger to start cushion air screwdriver

Advertisement

Quick Links

SUMAKE
Push Or Push And Trigger To Start Cushion
Specification:
Free
Torque range
(Hard Joint)
Speed
MODEL
r/min
Nm
ACPN39
1600
5.0
ACPN45
750
7.0
Recommend Air Pressure: 6.0 kg/cm²
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
.
PNEUMATIC TOOLS
Air Screwdriver (Alu.)
Min. air hose
bore
Kgf-cm
mm
50
5.0
70
5.0
Uncertainty K= 1.5 m/s²
Noise and Vibration:
Vibration
EN ISO 28927-2
Sound pressure level
No Load: 0.9 m/s²
No Load: 73.6 dB(A)
No Load: 0.9 m/s²
No Load: 73.6 dB(A)
Noise
EN ISO 15744
Sound power level
No Load: 84.6 dB(A)
No Load: 84.6 dB(A)
Uncertainty K= 3dB
ACPN39(45)-S-2111F-MIF
Remark
Please always
wear ear
protector at
environment
noise level >
80 dB(A) due
to risk of
impaired
hearing!

Advertisement

loading
Need help?

Need help?

Do you have a question about the ACPN39 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sumake ACPN39

  • Page 1 No Load: 0.9 m/s² No Load: 73.6 dB(A) No Load: 84.6 dB(A) to risk of impaired hearing! Recommend Air Pressure: 6.0 kg/cm² Uncertainty K= 1.5 m/s² Uncertainty K= 3dB ACPN39(45)-S-2111F-MIF SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91...
  • Page 2: Ec Declaration Of Conformity

    DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment:TRIGGER START CUSHION AIR SCREWDRIVER (ALU.) Model/ Serial No.:ACPN39(45) to which this declaration applies, complies with these normative documents: Machinery Directive: 2006/42/EC ...
  • Page 3 OPERATION MANUAL AIR SUPPLY 1. Air tools are adversely affected by moisture. Since air from compressor contains much moisture and dust, it is desirable to provide a filter and lubricator in the pipeline to remove such undesirable elements. Also take the drain out from air tank every day. 2.
  • Page 4 ACPN45 TRIGGER START CUSHION AIR SCREWDRIVER (ALU.) ACPN45-P-2210F-MI...
  • Page 5: Parts List

    ACPN45 TRIGGER START CUSHION AIR SCREWDRIVER (ALU.) PARTS LIST Parts No. Description Q'ty Parts No. Description Q'ty 5L2035 Pistol Housing (Sky Blue) 7S2010 Ball Bearing 7Q2008 O Ring 5A5353 Clutch Housing 2C2003-A Blank Cap 3S5060 Anvil 7Q2007 O Ring 6N2081 C Ring 7Q6112 Valve O-Ring...
  • Page 6 SCREWDRIVER Original instructions SUMAKE Industrial Co. Ltd.
  • Page 7 Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
  • Page 8 2. While using an assembly power tool for threaded fasteners, the operator should adopt a comfortable posture whilst maintaining secure footing and avoiding awkward or off-balanced postures. The operator should change posture during extended tasks, which can help avoid discomfort and fatigue. 3.
  • Page 9 General preparation and connection: When using brand-new air hose or air pipe. Blow and clean the inside of air hose or pipe before installation. Keep inside of air hose or air pipe clean to prevent airdrop problem caused by the lots of drain and dust accumulated and possibly make the inside diameter smaller in the long use.
