In accordance with IKA Terms and Condition of sale, the
warranty period is 24 months� For claims under the war-
ranty please contact your local dealer� You may also send
the machine direct to our factory, enclosing the delivery in-
voice and giving reasons for the claim� You will be liable for
freight costs�
Pump performance curve measured with water:
(Measurements done according DIN 12876-2 with water at 20°C; pump in a closed-loop circuit)�
300
200
100
0
-100
-200
-300
0
Fig. 9

Warranty

Pump performance curve

5 10
Q [l/min]
The warranty does not cover worn out parts, nor does it ap-
ply to faults resulting from improper use, insufficient care or
maintenance not carried out in accordance with the instruc-
tions in this operating manual�
15
3200 rpm
2000 rpm
1000 rpm
20
