Camera Introduction

1
2
3
4
5
6
7
8
9
3 English
Antenna
1
Mount
2
Metal Aluminum Case
3
Spotlight
4
IR LEDs
5
High Definition Lens
6
Daylight Sensor
7
Built-in Mic
8
Speaker
9
Network Port
10
Reset Button
11
* Press for about 10
seconds to restore the
device to factory
settings.
Power Port
12
10 11 12

Connection Diagram

NVR
1.Connect the included power adapter to the NVR and a power outlet.
2.Connect the NVR to your router with an Ethernet cable (if you hope
to use it remotely).
Next, connect the mouse to the USB port of the NVR.
HDMI
3.Connect the NVR to the monitor with a VGA or HDMI cable.
NOTE: There is no VGA cable and monitor included in the package.
Router
VGA
