Camera Introduction

1
2
3
4
5
6
7
8
9
3 English
microSD Card Slot
1
*Loosen the screws
with a screwdriver (not
included) to access the
microSD card slot.
Antenna
2
Mount
3
Metal Aluminum Case
4
Spotlight
5
Lens
6
Built-in Mic
7
Speaker
8
Waterproof Lid
9
Network Port
10
Reset Button
11
* Press for about 10
seconds to restore the
device to factory
settings.
Power Port
12
10 11 12

Connection Diagram

Before initial setup, follow the steps below to connect your camera.
1. Connect the camera to a LAN port on your router with an Ethernet
cable.
2. Power on the camera with a power adapter.
Network Cable
Router
WiFi IP Camera
Power Adapter
Power Cable
