DEMO MANUAL DC1763A

pArts list

ITEM QTY REFERENCE
General BOM
1 1 CN1
2 11 C5, C7, C8, C9, C15, C16, C18, C28,
C36, C48, C52
3 1 C4
4 1 C6
5 3 C10, C53, C54
6 1 C17
7 2 C29, C37
8 7 C30, C38, C43-C47
9 4 C31, C32, C39, C40
10 1 C49
11 1 C51
12 1 J1
13 6 JP2, JP5, JP8, JP13, JP14, JP15
14 2 J3, J4
15 2 J11, J12
16 2 L4, L5
17 1 L7
18 2 L9, L11
19 2 R1, R63
20 0 R2, R57-R59, R61, R62, R64, R65
21 12 R4, R5, R10, R36, R102-R109
22 2 R8, R92
23 6 R9, R11, R14, R72, R73, R74
24 1 R12
25 4 R26, R29, R39, R46
26 9 R30, R47, R56, R60, R95-R99
27 8 R31, R32, R33, R34, R48-R51
28 2 R35, R52
29 4 R37, R38, R53, R54
30 2 R40, R41
31 2 R42, R43
32 8 R110-R117
33 3 TP1, TP6, TP7
34 3 T5, T9, T11
35 2 T8, T10
36 1 U2
37 1 U3
38 6 XJ2, XJ5, XJ8, XJ13, XJ14, XJ15
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP , ARRAY, 0508 2.2µF 20% 4V X5R
CAP ., X5R, 0.1µF , 10V, 10% 0402
CAP ., X5R, 1µF , 10V, 10% 0402
CAP ., TANT., 100µF , 16V, 10% 6032
CAP ., X7R, 1µF ,10V, 10% 0603
CAP ., X5R, 2.2µF , 10V, 20% 0603
CAP ., X5R, 2.2µF , 6.3V, 20% 0402
CAP ., X7R, 0.01µF , 16V, 10% 0402
CAP ., COG, 8.2pF , 50V, 5% 0402
CAP ., X7R, 0.01µF , 25V, 10% 0402
CAP ., X5R, 4.7µF , 6.3V 20% 0603
BGA CONNECTOR, 40X10
HEADER, 3-PIN 0.079 SINGLE ROW
CON., SMA 50Ω, EDGE-LAUNCH
CON.,SMA JACK, STRAIGHT, THRU-HOLE
INDUCTOR, 56nH 0603
FERRITE BEAD, 0603
FERRITE BEAD, 1206
RES., CHIP , 0Ω 0402
OPT, RES, CHIP , 0402
RES., CHIP , 10k, 1/16W, 5% 0402
RES., CHIP , 100Ω, 1/16W, 1% 0402
RES., CHIP , 1k, 1/16W, 5% 0402
RES., CHIP , 31.6k, 1/16W, 1% 0402
RES., CHIP , 64.9Ω, 1/16W, 1% 0402
RES., CHIP , 100Ω, 1/16W, 5% 0402
RES., CHIP , 10.0Ω, 1/16W, 1% 0402
RES., CHIP , 86.6Ω, 1/16W, 1%, 0402
RES., CHIP , 86.6Ω, 1/16W, 1% 0603
RES., CHIP , 49.9Ω, 1/16W, 1% 0402
RES., CHIP , 5.1Ω,, 1/16W, 1% 0402
RES., CHIP , 33k, 1/16W, 1% 0402
TESTPOINT, TURRET, 0.094, PBF
TRANSFORMER, RF~SMT~1:1BALUN
TRANSFORMER, FLUX-COUPLED BALUN
IC, LT1763CS8-1.8 SO8
I.C. EEPROM 32KBIT 400kHz 8TSSOP
SHUNT, 0.079" CENTER
MANUFACTURER/PART NUMBER
AVX, W2L14D225MAT1A
AVX, 0402ZD104KAT2A
AVX, 0402ZD105KAT2A
AVX, TPSC107K016R0200
AVX, 0603ZC105KAT2A
AVX, 0603ZD225MAT2A
AVX, 04026D225MAT2A
AVX, 0402YC103KAT2A
AVX, 04025A8R2JAT2A
AVX, 04023C103KAT2A
AVX, 06036D475MAT2A
SAMTEC, SEAM-40-02.0-S-10-2-A
SAMTEC, TMM-103-02-L-S
EF JOHNSON, 142-0701-851
AMPHENOL CONNEX, 132134
MURATA, LQP18MN56NG02D
MURATA, BLM18BB470SN1D
MURATA, BLM31PG330SN1L
YAGEO, RC0402FR-070RL
YAGEO, RC0402JR-0710KL
YAGEO, RC0402FR-07100RL
YAGEO, RC0402JR-071KL
YAGEO, RC0402FR-0731K6L
VISHAY, CRCW040264R9FKED
YAGEO, RC0402JR-07100RL
YAGEO, RC0402FR-0710RL
YAGEO, RC0402FR-0786R6L
YAGEO, RC0603FR-0786R6L
YAGEO, RC0402FR-0749R9L
YAGEO, RC0402FR-075R1L
YAGEO, RC0402FR-0733KL
MILL- MAX, 2501-2-00-80-00-00-07-0
MACOM, MABA-007159-000000
MACOM, MABAES0060
LINEAR TECH., LT1763CS8-1.8#PBF
MICROCHIP , 24LC32A-I/ST
SAMTEC, 2SN-BK-G
