Pro-Form PFTL50919-INT.0 User Manual page 15

16. Set the Left Handrail Cover (70) on the left
Handrail (72). Start two #8 x 3/4" Screws (11)
into the left Handrail and the Left Handrail Cover.
Next, slide the Left Handrail Cover forward
against the console assembly (H) as shown.
Then, tighten both Screws.
Then, attach the Left Handrail Bottom (14) to the
Handrail (72) with two #8 x 3/4" Screws (11).
Attach the Right Handrail Cover (71) and
the Right Handrail Bottom (12) to the right
Handrail (72) as described above.
17. Tighten all eight indicated Screws (2, 3, 4) from
steps 4 and 5.
16
H
70
11
72
11
14
17
2, 3, 4
15
71
72
11
12
11
2, 3, 4
