USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFTL50919.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form PFTL50919.0

Summary of Contents for Pro-Form PFTL50919.0

  • Page 1 Model No. PFTL50919.0 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal REGISTER YOUR PRODUCT To register your product and activate your warranty today, go to my.proform.com. CUSTOMER CARE For service at any time, go to support.proform.com.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 19. Always stand on the foot rails when starting able to safely lift 45 lbs. (20 kg) to move the or stopping the walking belt. Always hold the treadmill. handrails while using the treadmill. 26. When folding or moving the treadmill, make 20.
  • Page 5 STANDARD SERVICE PLANS...

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM ® reading this manual, please see the front cover of this SPORT 7.0 treadmill. The SPORT 7.0 treadmill pro- manual. To help us assist you, note the product model vides an impressive selection of features designed number and serial number before contacting us.

  • Page 7: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 8: Assembly

    ASSEMBLY 1. To use the assembly steps in this manual, first see the helpful tips below. • Assembly requires two persons. • To identify small parts, see page 7. • Place all parts in a cleared area and remove the •...
  • Page 9 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (80) to the front of the Base (88). Next, identify the Right Upright (79). Have a second person hold the Right Upright near the Base (88).
  • Page 10 4. Set the Right Upright (79) on the Base (88) as shown. Make sure not to pinch the Upright Wire (80). Then, slide the Right Upright so that the 3/8" x 2 3/8" Screw (2) in the Base is inserted into the slot (E) in the Right Upright. Do not tighten the Screw yet.
  • Page 11 6. Remove and save the four indicated 5/16" x 3/4" Screws (13). 7. Attach a Handrail (72) to the Right Upright (79) with two 5/16" x 2" Screws (5) and two 5/16" Star Washers (7); start both Screws, and then tighten them. Do not pinch the Upright Wire (80).
  • Page 12 8. Attach the other Handrail (72) to the Left Upright (78) with two 5/16" x 2" Screws (5) and two 5/16" Star Washers (7); start both Screws, and then tighten them. Then, remove and discard the two indicated screws (F). 9.
  • Page 13 10. Set the Upright Tray (90) on the Upright Crossbar (77). Attach the Upright Tray with four #8 x 3/4" Screws (11); start all four Screws, and then tighten them. Do not overtighten the Screws. 11. Set the Console Base (74) face down on a soft surface to avoid scratching the Console Base.
  • Page 14 12. IMPORTANT: To avoid damaging the Pulse Crossbar (75), do not use power tools and do not overtighten the #10 x 3/4" Screws (9). Orient the Pulse Crossbar (75) as shown. Attach the Pulse Crossbar to the Handrails (72) with four #10 x 3/4"...
  • Page 15 14. Set the console assembly (H) on the Handrails (72). Do not pinch any wires. Insert the excess Upright Wire (80) into the con- sole assembly (H). Next, tighten the two ties (J) around the Upright Wire, and cut off the ends of the ties.
  • Page 16 16. Set the Left Handrail Cover (70) on the left Handrail (72). Start two #8 x 3/4" Screws (11) into the left Handrail and the Left Handrail Cover. Next, slide the Left Handrail Cover forward against the console assembly (H) as shown. Then, tighten both Screws.
  • Page 17 18. Tighten all eight indicated Screws (2, 3, 4) from steps 4 and 5. 2, 3, 4 2, 3, 4 19. IMPORTANT: You must activate your Console (31) to begin using its exclusive features. First, plug in the power cord (see page 18) and turn on the power (see page 20).

  • Page 18: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD more amps. To avoid overloading the circuit, do not plug other electrical devices, except for low- Use a Surge Suppressor power devices such as cell phone chargers, into the surge suppressor or into an outlet on the same Your treadmill, like other electronic equipment, can be circuit.
  • Page 19 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s sound system while you IMPORTANT: To activate your console and begin exercise. using its exclusive features, see assembly step 19 on page 17.
  • Page 20 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 21 4. Change the incline of the treadmill as desired. Vertical Distance (VRT FT or VRT M)—The distance you have walked or run in vertical feet or To change the incline of the treadmill, press the vertical meters. Incline increase and decrease buttons or one of the numbered Incline buttons.
  • Page 22 6. Measure your heart rate if desired. HOW TO USE AN ONBOARD WORKOUT You can measure your heart rate using either the 1. Insert the key into the console. handgrip heart rate monitor or a compatible heart rate monitor. For information about purchasing See HOW TO TURN ON THE POWER on page 20.
  • Page 23 To stop the workout at any time, press the Stop HOW TO CONNECT YOUR TABLET TO THE button. To restart the workout, press the Start but- CONSOLE ton. The walking belt will begin to move at 1 mph. When the next segment of the workout begins, the The console supports BLUETOOTH connections treadmill will automatically adjust to the speed and to tablets via the iFit–Smart Cardio Equipment app...
  • Page 24 4. Record and track your workout information. THE SETTINGS MODE Follow the instructions in the iFit–Smart Cardio 1. Select the settings mode. Equipment app to record and track your workout information. To select the settings mode, press the Settings button. The first settings screen will appear in the 5.
  • Page 25 Display Test—This screen is intended to be used Demo Mode—The currently selected demo mode by service technicians to identify whether the option will appear in the display. The console display is working correctly. features a demo mode, designed to be used if the treadmill is displayed in a store.

  • Page 26: Fcc Information

    THE OPTIONAL CHEST HEART RATE MONITOR THE OPTIONAL TABLET HOLDER Whether your The optional goal is to tablet holder (N) burn fat or to will hold your strengthen your tablet securely cardiovascular in place and system, the key enable you to achieving the to use your best results is...

  • Page 27: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at to zero before you fold the treadmill. Then, remove the left.

  • Page 28: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE b. After the power cord has been plugged in, make sure that the key is inserted into the console. Regular maintenance is important for optimal per- formance and to reduce wear. Inspect and properly c. Check the power switch located on the treadmill tighten all parts each time the treadmill is used.
  • Page 29 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is not centered between the foot rails a. Use only a surge suppressor that meets all of the specifi cations described on page 18. IMPORTANT: If the walking belt rubs against the foot rails, the walking belt may become b.

  • Page 30: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 31: Part List

    PART LIST Model No. PFTL50919.0 R0121A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Ground Screw Controller Plate 3/8" x 2 3/8" Screw Plastic Tie 3/8" x 1 1/4" Screw Latch Plate 3/8" x 1 1/2" Screw Storage Latch 5/16"...

  • Page 32: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL50919.0 R0121A...
  • Page 33 EXPLODED DRAWING B Model No. PFTL50919.0 R0121A...
  • Page 34 EXPLODED DRAWING C Model No. PFTL50919.0 R0121A 24 36...
  • Page 35 EXPLODED DRAWING D Model No. PFTL50919.0 R0121A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
