Milestone pro MPHT-4T-H2KIT User Manual page 7

THD+N
SNR
Crosstalk Isolation
L-R Level Deviation
Frequency Response
Deviation
Output Load Capability
Stereo Channel Separation
Control
Control Part
Control Connector
General
Bandwidth
HDMI Standard
HDCP Version
Bidirectional PoC
HDMI 2.0 Cable Length
Transmission Standard
Transmission Distance
Operation Temperature
Storage Temperature
Relative Humidity
Power Supply
Power Consumption
Dimension (W*H*D)
Net Weight
Note: Please adopt quality CAT Ethernet cable compliant with CAT6e or higher
standard for reliable transmission.
1x4 HDBaseT Splitter Kit
nominal consumer line level signal
< 0.05% (-80dB), 20Hz – 20KHz bandwidth, 1KHz sine at 0dBFS
level (or max level)
> 85dB, 20Hz-20 kHz bandwidth
> 70dB, 10KHz sine at 0dBFS level (or max level before clipping)
< 0.3dB, 1KHz sine at 0dBFS level (or max level before clipping)
< ± 0.5dB 20Hz - 20KHz
1KΩ and higher (Supports 10x paralleled 10KΩ loads)
>70dB@1KHz
(1) FW, (1) IR In, (1) IR Out, (1) RS232
(1) Micro-USB port, (2) 3.5mm jacks, (1) 3-pin terminal block
18Gbps
2.0
2.2, 1.4 compliant
Supported
4K@60Hz 4:4:4 ≤ 5m, 4K@60Hz 4:2:0 ≤ 10m, 1080p ≤ 15m
HDBaseT
1080p@60Hz ≤ 230 feet (70 meters),
4K@60Hz ≤ 131 feet (40 meters)
-5~ +55℃
-25 ~ +70℃
10%-90%
Input:100V~240V AC; Output:24V DC 1.25A
12W (Max)
140mm x 19.5mm x 84mm
290g
5
