Summary of Contents for Milestone pro MP-DA4UHD-H2
- Page 1 User Manual MP-DA4UHD-H2 HDMI V2.0 1x4 Splitter with Down-scaling and AOC Supported All Rights Reserved Version: MP-DA4UHD-H2_2020V1.8...
-
Page 2: Safety Precaution
Statement Thanks for purchasing this product, please read this user manual carefully before using this product. The functions described in this version are updated till July, 2020. In the constant effort to improve our product, we reserve the right to make functions or parameters changes without notice or obligation. -
Page 3: Product Introduction
Product Introduction Thanks for choosing the HDMI V2.0 1x4 Splitter, which can distribute one HDMI input to four outputs. The splitter supports HDMI video resolution up to 4K@60Hz 4:4:4, 1080p 3D, and multichannel audio formats. Besides passing EDID information from the display, there are multiple built-in EDID settings can be selected by the 4-pin DIP switch on the front panel. -
Page 4: Rear Panel
corresponding channel. EDID: 4-pin DIP switch for EDID setting and HDCP mode selection. Please refer to the EDID Management for more details. FW: Micro-USB port for firmware upgrade. Rear Panel INPUT: Type-A female HDMI input port to connect a HDMI source. OUTPUTS: Four type-A female HDMI output ports to connect HDMI displays. - Page 5 Switch 1~3 are used for EDID setting. The DIP switch status and its corresponding setting are shown at the back of the product. Switch Status Video Resolution Audio Format Obtains EDID from the first detected display starting at HDMI output 1>2>3>4.
-
Page 6: Firmware Upgrade
Video Resolution Down-scaling The product supports video resolution down-scaling, the 4K input can be automatically degraded to 1080p output for compatibility with 1080p display, shown in the below chart. Input Output Color Resolution Refresh Downscale 1080p Specs Space 3840x2160 4:4:4 Support 1080p@60Hz 4:4:4 3840x2160... -
Page 7: Technical Specification
Technical Specification Video Input Input (1) HDMI Input Connector (1) Type-A female HDMI HDMI Input Resolution Up to 4K@60Hz 4:4:4 8bit HDMI Standard HDCP Version 2.3, 1.4 compliant Supported Video Output Output (4) HDMI Output Connector (4) Type-A female HDMI HDMI Output Resolution Up to 4K@60Hz 4:4:4 8bit HDMI Output... -
Page 8: System Connection
System Connection The following diagram illustrates the typical input and output connection of the splitter:...
