- Page 1 User Manual MP-UCUH-KVM HDMI 2.0 CONVERTER All Rights Reserved Version: MP-UCUH-KVM_2022V1.2...
- Page 2 HDMI 2.0 CONVERTER Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 HDMI 2.0 CONVERTER SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material ⚫ for possible future shipment.
-
Page 4: Table Of Contents
HDMI 2.0 CONVERTER Table of Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Packing List ....................... 2 1.3 Customer Service ....................2 2. Specification ....................... 3 3. Panel Description ......................4 3.1 Front Panel ......................4 3.2 Rear Panel ......................4 4. -
Page 5: Product Introduction
HDMI 2.0 CONVERTER 1. Product Introduction Thanks for choosing the MP-UCUH-KVM USB-C to HDMI converter. This converter is designed to convert 4K@60Hz 4:4:4(max) USB-C video input to 4K@60Hz 4:4:4(max) HDMI video output. For the USB-C, it also supports USB 3.1 Gen2 data transfer and 60W fast-charging. -
Page 6: Packing List
HDMI 2.0 CONVERTER 1.2 Packing List 1x MP-UCUH-KVM ⚫ 2x Mounting Ears with 4 Screws ⚫ 4x Plastic Cushions ⚫ 1x Power Adapter (DC 24V/5A) ⚫ 1x User Manual ⚫ 1.3 Customer Service We provide limited warranty for the product within three years counting from date of purchase (The purchase invoice shall prevail). -
Page 7: Specification
HDMI 2.0 CONVERTER 2. Specification Video Input Input (1) USB Input Connector (1) USB-C Input Resolution Up to 4K@60Hz 4:4:4 USB Standard USB3.1 Gen2 Video Output Output (1) HDMI Output Connector (1) Female type-A HDMI HDMI Output Resolution Up to 4K@60Hz 4:4:4 HDMI Standard HDCP Version 2.3（backwards compatible）... -
Page 8: Panel Description
HDMI 2.0 CONVERTER 3. Panel Description 3.1 Front Panel ① Power LED: The LED illuminates green when power is applied. ② CHARGING: The LED illuminates green when USB-C is charging externally. 3.2 Rear Panel ① ETHERNET: 1x RJ45 port, connect to Ethernet. ②... -
Page 9: System Connection
HDMI 2.0 CONVERTER 4. System Connection The following diagram illustrates typical input and output connections that can be utilized with the Converter:... -
Page 10: Panel Drawing
HDMI 2.0 CONVERTER 5. Panel Drawing...
