6. RS232 Control

The splitter and compatible receivers features RS232 ports to transmit RS232 signals
from computer to control far-end third-party devices by using 3-pin to DB9 cable and a
RS232 control software, such as docklight. After installing the RS232 control software,
please set the parameters of COM number, bound rate, data bit, stop bit and the parity
bit correctly. Compatible receivers must be able to communicate at 2400, 4800, 9600,
19200, 38400, 57600, or 115200 baud. The splitter requires the following
communication protocol parameters:
Baud rate: 9600 (default)
Data bit: 8
Stop bit: 1
Parity bit: none
RS232 Commands
The end mark of below commands is "<CR><LF>".
Command
#param1_GET_FIRM
WARE_VERSION
#param1_FACTORY_
RESET
#param1_SET_RS232
_BAUD param2
#param1_GET_RS232
_BAUD
#param1_GET_STATE
1x4 HDBaseT Splitter Kit
Function
Get the firmware version.
param1=0~15. The splitter ID 0~9, A~F.
param1=ALL. All splitters.
Restore to factory Default setting.
param1=0~15. The splitter ID 0~9, A~F.
param1=ALL. All splitters.
Set the baud rate of splitter.
param1=0~15. The splitter ID 0~9, A~F.
param1=ALL. All splitters.param1=ALL.
param2=0~4. Baud rate.
0=9600
1=19200
2=38400
3=57600
4=115200
Get the baud rate of splitter.
param1=0~15. The splitter ID 0~9, A~F.
param1=ALL. All splitters.
Get system status.
14
Command Example and
Feedback
#5_GET_FIRMWARE_VER
SION
@5_V1.0.0
#5_FACTORY_RESET
@5_FACTORY_RESET
#5_SET_RS232_BAUD 0
@5_RS232_BAUD 9600
#5_GET_RS232_BAUD
@5_RS232_BAUD 9600
#5_GET_STATE
