Control
Control port
Control Connector
General
HDMI Standard
HDCP Version
Transmission Mode
Transmission Distance
Operation Temperature
Storage Temperature
Relative Humidity
AC Adapter Input Power
Input Power
Power Consumption
Dimension (W*H*D)
Net Weight
Note: SPDIF audio output does not support DTS-HD Master Audio and Dolby TrueHD
format.

2.2 HDBaseT Receiver

Video
Input
Input Connector
Input Resolution
Output
Output Connector
Output Resolution
Audio
Output
Output Connector
Audio Format
Frequency Response
Max Output Level
1x4 HDBaseT Splitter Kit
(1) EDID, (1) FIRMWARE, (1) ID PRESET, (1) IR ALL IN/LOOP IN,
(1) IR OUT, (4) IR IN, (1) IR LOOP OUT, (1) RS232 IN, (1) RS232 OUT,
(1) 4-pin DIP switch, (1) Micro-USB, (1) DIP switch, (7) 3.5mm mini
jacks, (2) 3-pin terminal blocks
2.0
2.2
HDBaseT
1080p ≤ 229 feet (70 meters), 4K ≤ 131 feet (40 meters)
-10 ~ +55℃
-25~ +70℃
10% ~ 90%
100V~240V AC, 50/60Hz
24V DC 5A
47W (Max)
250mm x 44mm x 148mm
1.16kg
(1) HDBT
(1) RJ45
Up to 4K@60Hz 4:2:0
(1) HDMI
(1) Type-A female HDMI
Up to 4K@60Hz 4:4:4 8bit HDR10
(1) Audio Breakout
(1) Toslink connector
Supports PCM, Dolby Digital, Dolby True-HD, DTS and DTS-HD
20Hz - 20KHz, ±3dB
2.0Vrms ± 0.5dB. 2V = 16dB headroom above -10dBV (316mV)
