3-7 PC Health Status

By choosing the PC Health Status option from the CMOS Setup Utility menu (Figure
3-1), the screen below is displayed. This sample screen contains the manufacturer's
default values for the mainboard.
CMOS Setup Utility- Copyright (C) 1984-2001 Award Software
Shutdown Temperature
CPU VCore
+1.5V
+3.3V
+5.0V
+12V
+2.5V
5VSB
Voltage Battery
CPU Temperature
CPU FAN Speed
SYS FAN Speed
:Move Enter:Select
F5:Previous Values
A. Shutdown Temperature
The system will shutdown when the temperature setting is reached, to prevent
the system from overheating (supports Windows 98 or above with ACPI function
only).
PC Health Status
Disabled
1.63V
1.53V
3.32V
5.05V
12.16V
2.48V
5.02V
2.91V
o
46 C
4590 RPM
4500 RPM
+/-/PU/PD:Value
F6:Fail-Safe Defaults
Figure 3-8 PC Health Status Screen
