Declaration of Conformity
According to 47 CFR, Parts 2 and 15 of the FCC Rules
is a Class B digital device that complies with 47 CFR Parts 2 and 15 of the FCC
Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operation.
This declaration is given to the manufacturer:
CHAINTECH-EXCEL COMPUTER INC.
4427 Enterprise St. Fremont, CA 94538, U.S.A.
The following designated product:
EQUIPMENT : MAINBOARD
MODEL NO. : 6WIV0
http://www.chaintech-excel.com
Chaintech President: Simon Ho
Signature:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6WIV0 and is the answer not in the manual?

Questions and answers

Related Manuals for CHAINTECH 6WIV0

Summary of Contents for CHAINTECH 6WIV0

  • Page 1 According to 47 CFR, Parts 2 and 15 of the FCC Rules The following designated product: EQUIPMENT : MAINBOARD MODEL NO. : 6WIV0 is a Class B digital device that complies with 47 CFR Parts 2 and 15 of the FCC Rules. Operation is subject to the following two conditions: 1.
  • Page 2 Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Introduction ................ 1 Product Specifications ............1 Package Contents ..............4 Mainboard Layout ..............5 Connector and Jumper Reference Chart ......5 Chapter 2 Hardware Setup ..............7 Introduction to Jumpers ............7 Installing a CPU in a Socket 370 ......... 8 SettingYour CPU's Parameters...........8 Connector and Jumper Settings .........

  • Page 4: Chapter 1 Introduction

    Introduction Chapter 1 Introduction 1-1 Product Specifications ! ! ! ! ! Processor ! ! ! ! ! Chipset ! ! ! ! ! DRAM Memory Embedded 3D AGP VGA ! ! ! ! ! " " " " " Embedded Audio Subsystem ! ! ! ! ! "...
  • Page 5 Chapter 1 Boot-Block Flash ROM ! ! ! ! ! " " " " " ChipAway Virus ! ! ! ! ! Onboard LPC I/O Controller ! ! ! ! ! Embedded System Monitoring Hardware (Optional) Double Stack Back-Panel I/O Connectors with PC99 Colored Codes ! ! ! ! ! ! ! ! ! ! Board Dimensions...
  • Page 6 Introduction ! ! ! ! ! Advanced Management Features 5AA27 Max. Regulation Min.Current Output Voltage Requirement Requirement(Amps) +12V +/- 5% +/- 5% +3.3V +/- 5% +/- 10% -12V +/- 10% +5VSB +/- 5% 0.75 Table 1-1...

  • Page 7: Package Contents

    Chapter 1 1-2 Package Contents Color coded connection for UDMA/66 cable Value Pack 2000 UDMA66 IDE cable Figure 1-1 Standard Floppy Figure 1-2 cable Insert the stub if the mounting screw is not supported by the ATX Figure 1-3 case...

  • Page 8: Mainboard Layout

    Introduction 1-3 Mainboard Layout 1-4 Connector and Jumper Reference Chart Jumper & Function Page Connector No. Infrared connector CD-ROM audio in connector Keyboard lock & Power indicator LED connector System reset switch connector Speaker connector Green switch & Green LED connector IDE activity LED connector Over-ride power button CN10...
  • Page 9 Chapter 1 $ Memo...

  • Page 10: Chapter 2 Hardware Setup

    Hardware Setup Chapter 2 Hardware Setup Be sure to disconnect the power cable from the power source before performing any work on your mainboard, i. e. installing a CPU, memory module, changing a jumper setting, etc. Not doing so may result in electrical shock! 2-1 Introduction to Jumpers Putting jumper caps on anything that is not a jumper may result in damaging your mainboard.

  • Page 11: Installing A Cpu In A Socket 370

    Chapter 2 2-2 Installing a CPU in a Socket 370 2-3 Setting Your CPU's Parameters( SeePU Technology) SeePU CMOS Setup Utility - Copyright (C) 1984-2000 Award Software SeePU Setup    Auto Detect DIMM/PCI CLK Enabled Items Help CPU Clock/Spread Spectrum Default CPU Type 233MHz(66*3.5)
  • Page 12 Hardware Setup CPU Speed CPU Type External Clock Frequency Ratio Internal Clock Intel Celeron Socket370 processor FC-PGA Socket370 processor Figure 2-3 SeePU CMOS Setup Utility - Copyright (C) 1984-2000 Award Software SeePU Setup    Auto Detect DIMM/PCI CLK Enabled Items Help CPU Clock/Spread Spectrum...
  • Page 13 Chapter 2 Overclocking System Lock-up Recovery...

  • Page 14: Connector And Jumper Settings

    Hardware Setup 2-4 Connector and Jumper Settings The power supply connector is the last connection to be made while installing a mainboard. Before connecting the power supply, please make sure it is not connected to the power source. ATX Power Supply Connector 750mA Software Power-Off Control Power-On By Modem...

  • Page 15: Over-Ride Power Button

    Chapter 2 Front Panel Connector Set (CN9) A through E A. Over-ride Power Button Connector B. Keyboard Lock & Power Indicator LED Over-ride Power Button Connector Operation Definition +5V DC Power Good LED No Connect Ground Keylock Keyboard Lock Ground Suspend to RAM (STR)

  • Page 16: Blinking Led In Suspend Mode

    Hardware Setup Blinking LED in Suspend Mode C. System Reset Switch Connector Definition System D. Speaker Connector Definition Speaker Signal +5V DC E. IDE Activity LED Connector Infrared Connector 5VSB Ir-Rx Ir-Tx 5VSB...

  • Page 17: Poly-Fuse Over Current Protection

    Chapter 2 CPU/System Cooling Fan Connectors FAN1/FAN2/FAN3) FAN1 FAN3 FAN2 PS/2 Mouse and Keyboard Ports Definition Data No Connection Ground + 5V (fused) Clock No Connection Poly-fuse Over Current Protection...

  • Page 18: Wystem Lockup Recovery

    Hardware Setup Host Bus Frequency Jumper (JP2) On Board Audio CODEC Jumper(JP3) CPU Freq. ratio Jumper(JP6) System Lockup Recovery Jumper (JP4) System Lockup Recovery Jumper (JP4) System Lockup Recovery Jumper (JP4) System Lockup Recovery Jumper (JP4) System Lockup Recovery Jumper (JP4)

  • Page 19: Jp8 Chassis Intrusion Detection

    Chapter 2 Audio Line out and Speaker out Jumper(JP9/JP10) JP9 JP10 JP9 JP10 Speaker out Line out CMOS Setting (JP5) Chassis Intrusion Detection (JP8) CD-ROM Audio-in Connector(CN1)

  • Page 20: Cn10 Wol(Wake-On-Lan) Connector

    Hardware Setup WOL (Wake-on-LAN) Connector (CN10) 750mA USB(Universal Serial Bus) Ports...

  • Page 21: Main Memory Configuration

    Chapter 2 2-5 Main Memory Configuration 16~256 MBytes DRAM Specifications SPD (Serial Presence Detect)

  • Page 22: Chapter 3 Award Bios Setup Program

    Award BIOS Setup Program Chapter 3 3 3 3 3 3 Award BIOS Setup Program Award's BIOS ROM has a built-in setup program that allows users to modify the basic system configuration. This information is stored in CMOS RAM so that it can retain the setup information, even when the power is turned off.
  • Page 23 Chapter 3 ! Memo...

  • Page 24: Chapter 4 Brief Software Driver Guide

    Brief Software Driver Guide Chapter 4 Brief Software Driver Guide The Mainboard Software Guide is found on the CD-ROM that is enclosed with your mainboard and is a PDF file which must be viewed with Adobe's freeware called Acrobat Reader. The Acrobat Reader software is also included on the same CD- ®...
  • Page 25 Chapter 4 ! Memo...

  • Page 26: Appendix I On Board I/O Addresses & Irq Maps

    Appendix I On Board I/O Addresses & IRQ Maps System Resource I/O Address 1. Timer IRQ0 040, 043 2. Keyboard IRQ1 060, 064 3. Programmable INT IRQ2 0020, 0021, 00A0, 00A1 4. COM2(B) IRQ3 2F8, 2FF 5. COM1(A) IRQ4 3F8, 3FF 6.
  • Page 27 User's Manual " Memo...

  • Page 28: Appendix Ii Embedded Flash Utility

    Appendix II Embedded Flash Utility This mainboard is equipped with an Erasable Flash ROM and an Embedded Flash Utility which allows the user to update the BIOS to a newer version. Embedded Flash Utility eases BIOS upgrade and eliminate the compatibility issue between different Flash ROM type and version of Flash utility.
  • Page 29 User's Manual Memo...
