Auxiliary CD-ROM Audio-in (CN3)
Audio Mono -in/out (CN4)
PS/2 Mouse and Keyboard Ports (PT1)
Use the mono audio cable enclosed with your
audio device to your mainboard. This will enable
mono audio in/out function.
Mono-in
Mono-out
GND
1
Pin
1
2
No Connect
3
4
+5V (fused)
5
6
No Connect
Hardware Setup
Definition
Data
Ground
Clock
15
