CHAINTECH CT-6BSA Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following two
conditions:
This device may not cause harmful interference
This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy. If this equipment is not installed and used in accordance with the
manufacturer's instructions, it may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required to
assure compliance with FCC regulations. Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the user's authority to operate this
equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for audio noise emissions from digital
apparatusses set out in the Radio Interference Regulations of the Canadian Department of
Communications.
Manufacturer's Disclaimer Statement
The information in this document is subject to change without notice and does not represent a
commitment on the part of the vendor. No warranty or representation, either expressed or implied,
is made with respect to the quality, accuracy or fitness for any particular purpose of this document.
The manufacturer reserves the right to make changes to the content of this document and/or the
products associated with it at any time without obligation to notify any person or organization of
such changes. In no event will the manufacturer be liable for direct, indirect, special, incidental
or consequential damages arising out of the use or inability to use this product or documentation,
even if advised of the possibility of such damages. This document contains materials protected
by copyright. All rights are reserved. No part of this manual may be reproduced or transmitted
in any form, by any means or for any purpose without expressed written consent of it's authors.
Product names appearing in this document are mentioned for identification purposes only. All
trademarks, product names or brand names appearing in this document are registered property
of their respective owners.
Printed in Taiwan
September 1998
POST-CONSUMER
RECYCLED PAPER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT-6BSA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CHAINTECH CT-6BSA

Summary of Contents for CHAINTECH CT-6BSA

  • Page 1 Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 2: Table Of Contents

    T T T T T ab le of Contents le of Contents ab le of Contents le of Contents le of Contents Chapter 1 Introduction ................. 1 Product Specifications ............1 Package Contents ..............4 Mainboard Layout ..............5 Connector and Jumper Reference Chart ........ 5 Chapter 2 Hardware Setup ..............
  • Page 3 Feature Explanations SeePU Technology ................8 Software Power-off Control ..............11 Power-On By Modem ............... 11/36 Over-ride Power Button ................. 12 Blinking LED in Suspend Mode ............12 Wake Up On LAN ................14/36 Poly-fuse Over Current Protection ............15 Creative's SB-LINK Sound Connector ..........
  • Page 4 Memo Memo Memo Memo Memo...

  • Page 5: Chapter 1 Introduction

    Introduction Chapter 1 Introduction 1-1 Product Specifications Processor ® - Supports Intel Pentium II processors up to 450 MHz and Celeron processors up to 333MHz with MMX technology - Slot 1 CPU socket with convenient retention mechanism - High efficiency Switching Power Module (1.8v ~ 3.5v, 0.1v increments) - Supports 66/100 MHz system clock speeds - Innovative SeePU technology (software CPU installation without jumper settings)
  • Page 6 Chapter 1 Two Ultra DMA-33 PCI IDE Ports - Supports up to PIO Mode 4, Multi-word Mode 2 and Ultra DMA-33 timings - Bus Mastering software drivers for all well known multi-task operating systems On-board Ultra I/O - ITE 8671 I/O chip - One Parallel (SPP/ECP/EPP) and two Serial (16550A compliant) ports - One floppy disk drive connector supports up to 2.88MB, Japanese 3-Mode, and 1Mbps transfer rates...
  • Page 7 Introduction Standby, and Suspend modes - ACPI features ready Switching Power Supply Requirement (at least 200 Watts) Max. Regulation Min. Current Output Voltage Requirement Requirement (Amps) +12V +/- 5% +/- 5% +3.3V +/- 5% +/- 10% -12V +/- 10% +5VSB +/- 5% 0.75 Table 1-1...

  • Page 8: Package Contents

    Chapter 1 1-2 Package Contents 1-2 Package Contents 1-2 Package Contents 1-2 Package Contents 1-2 Package Contents This product comes with the following components: One mainboard One Slot 1 universal retention mechanism One 40-pin IDE connector ribbon cable (Figure 1-1) One 34-pin floppy disk drive ribbon cable (Figure 1-2a) or (Figure 1-2b) One Plastic Stub for standard ATX chassis installation (Figure 1-3) One User's Manual...

  • Page 9: Mainboard Layout

    Introduction 1-3 Mainboard Layout 1-3 Mainboard Layout 1-3 Mainboard Layout 1-3 Mainboard Layout 1-3 Mainboard Layout B a c k P a n e l I/O C o n n e cto r P C B U S B 2 C O M 2 C O M 1 K /B...
  • Page 10 Chapter 1 Memo Memo Memo Memo Memo...

  • Page 11: Chapter 2 Hardware Setup

    Hardware Setup Chapter 2 Chapter 2 Chapter 2 Chapter 2 Chapter 2 Har d d d d d ware Setup ware Setup ware Setup ware Setup ware Setup If your mainboard has already been installed in your computer you may still need to refer to this chapter if you plan to upgrade your system's hardware.

  • Page 12: Installing An S.e.c. Processor In Slot 1

    Chapter 2 2-2 Installing an S.E.C. Processor in Slot 1 1. Insert the Pentium II processor into the retention mechanism. Press evenly and gently until the snaps on the upper side of the processor have been inserted into the holes at the top of the retention mechanism. 2.
  • Page 13 Hardware Setup 3. Change the CPU Type according to the speed of your Pentium II processor. See Figure 2-3 for frequency specifications. CPU Speed CPU Type Frequency External Clock Internal Clock Ratio Pentium II processor Figure 2-3 Figure 2-3 Figure 2-3 Figure 2-3 Figure 2-3 4.
  • Page 14 Chapter 2 Overclocking Operating a CPU at a higher frequency than it's specification allows is called overclocking. If the CPU frequency is set at a higher frequency than it's specification allows, it may or may not run at that freqency, depending on the quality of your CPU and the extent to which the frequency has been overset.

  • Page 15: Connector And Jumper Settings

    Hardware Setup 2-4 Connector and Jumper Settings Connectors are used to link the system board with other parts of the system, including the power supply, the keyboard, and the various controllers on the front panel of the system case. The power supply connector is the last connection to be made while installing a mainboard.
  • Page 16 Chapter 2 Front Panel Connector Set (CN8) A through G A. Over-ride Power Button Connector The power button on the ATX chassis can be used as a normal power switch as well as a device to activate Advanced Power Management Suspend mode. This mode is used for saving electricity when the computer is not in use for long periods of time.
  • Page 17 Hardware Setup C. Green Switch/Green LED Connector Some ATX cases provide a Green switch which is used to put the system in Suspend mode. In Suspend mode, the power supply to the system is reduced to a trickle, the CPU clock is stopped, and the CPU core is in it's minimum power state.
  • Page 18 Chapter 2 Infrared Connector (CN3) If you enable the COM2 Mode in BIOS's Integrated Peripherals menu the COM2 port will support IR functions. (See section 3-7) CPU/System Cooling Fan Connectors FAN1/FAN2) These added connectors allow the fan to draw their power from the mainboard instead of the disk drive connector.
  • Page 19 Hardware Setup Clear CMOS Data Jumper (JP8) Normal (default) Clear CMOS data To clear the contents of the CMOS, please follow the steps below. 1.Disconnect the system power supply from the power source. 2.Set the jumper cap at location 2~3 for 5 seconds, then set it back to the default position.
  • Page 20 Chapter 2 CD-ROM Audio-in (JP1) Use the audio cable enclosed with your CD-ROM disk drive to connect the CD-ROM to your mainboard. This will enable your CD-ROM's audio function. G N D G N D 2 2 2 2 2 I I I I I S Connector S Connector...
  • Page 21 Hardware Setup USB(Universal Serial Bus) Ports If you want to use a USB keyboard, you must enable the USB keyboard support function in BIOS's Integrated Peripherals menu (See Section 3-7). USB is an open industry standard, providing a simple and inexpensive way to connect up to 125 devices to a single computer port.

  • Page 22: Main Memory Configuration

    Chapter 2 2-5 Main Memory Configuration The DRAM memory system consists of three banks and the memory size ranges from 16~384 MBytes. If you only use one bank it does not matter which one you use and if you use two or more banks, it does not matter which bank you install first. Bank0 DIM M 1 Bank1...
  • Page 23 Hardware Setup SPD (Serial Presence Detect) This is an EPROM that contains speed and design information about the memory module. The mainboard queries the module and makes adjustments to system operation based on what it finds. ECC DRAM Capability This mainboard can be configured to support ECC (Error Check and Correct) function when utilizing parity DIMM modules.
  • Page 24 Chapter 2 M e m o M e m o M e m o M e m o M e m o...

  • Page 25: Chapter 3 Award Bios Setup Program

    Award BIOS Setup Program Chapter 3 Chapter 3 Chapter 3 Chapter 3 Chapter 3 3 3 3 3 3 Award BIOS Setup Program Award's BIOS ROM has a built-in setup program that allows users to modify the basic system configuration. This information is stored in CMOS RAM so that it can retain the setup information, even when the power is turned off.

  • Page 26: Standard Cmos Setup

    User's Manual 3-1 Standard CMOS Setup The Standard CMOS Setup allows users to configure system components such as hard disk drive, floppy disk drive and video display as well as date, time and boot- up error signaling. This configuration menu should be changed when installing a mainboard for the first time, changing hardware in your system such as the HDD, FDD, video display, or when the CMOS data has been lost or contaminated.
  • Page 27 Award BIOS Setup Program Type (Auto/User/None): Use the fields under the Type column to determine the method you will use to configure the IDE devices. If you choose Auto, BIOS will automatically detect and make optimal settings for most IDE hard drives. The mainboard manufacturer recommends that you choose Auto for all drives.
  • Page 28 User's Manual Large - for IDE drives that do not support LBA and have more than 1024 cylinders. Try this setting if your hard disk does not operate properly with the LBA setting. Large mode is not supported by all operating systems, i.e., only certain versions of DOS support large mode.

  • Page 29: Bios Features Setup

    Award BIOS Setup Program 3-2 BIOS Features Setup By choosing the BIOS Features Setup option from the CMOS Setup Utility menu (Figure 3-1), the screen below is displayed. This sample screen contains the manufacturer's default values for the mainboard. ROM PCI / ISA BIOS (2A69KC39) BIOS FEATURES SETUP AWARD SOFTWARE, INC.
  • Page 30 User's Manual 2 external cache. Both settings are left enabled to significantly increase the performance of your computer. CPU L2 Cache ECC Checking Enable this function to perform ECC (Error Check and Correct) on the CPU's L2 SRAM. ECC detects and corrects single-bit errors while it only detects double bit errors.
  • Page 31 Award BIOS Setup Program Typematic Rate (Chars/Sec) The typematic rate sets the rate at which characters on the screen repeat when a key is pressed and held down. Typematic Delay (Msec) The typematic delay sets how long after you press a key that a character begins repeating.
  • Page 32 User's Manual Shadowing improves the firmware's performance because the firmware can be read by the CPU through the 16- or 32-bit DRAM bus as opposed to the 8-bit XT bus. However, shadowing also results in reducing the amount of high memory (640 KB to 1 MB) for loading device drivers.

  • Page 33: Seepu & Chipset Setup

    Award BIOS Setup Program 3-3 SeePU & Chipset Setup By choosing the SeePU & Chipset Setup option from the CMOS SETUP UTILITY menu(Figure 3-1), the screen below is displayed. This sample screen contains the manufacturer's default values for the mainboard. ROM PCI / ISA BIOS (2A69KC39) SeePU &...
  • Page 34 User's Manual B. DRAM Data Integrity Mode BIOS automatically detects the presence of ECC DIMMs (72-bit modules). However, to take advantage of ECC you must set this function at "ECC." If any non-parity DIMMs are installed, the memory operates in non-parity mode only and this function must be set at "Non-ECC."...
  • Page 35 Award BIOS Setup Program H. Power Failure Recovery Computers using an ATX power supply do not turn back on after the power source to the computer unexpectedly fails (i.e. electricity outage). Enabling this setting will allow the system to always turn back on after a power failure. This is especially important for computers that must be on 24 hours per day.

  • Page 36: Power Management Setup

    User's Manual 3-4 Power Management Setup This section provides information on the Green PC power management funtcions. By choosing the Power Management Setup option from the CMOS Setup Utility menu (Figure 3-1), the screen below is displayed. This sample screen contains the manufacturer's default values for the mainboard.
  • Page 37 Award BIOS Setup Program B. Power Management Power management allows the computer to save electricity when it is not in use by entering increasingly deep power saving modes as shown by the diagram below. Figure 3-6 Power Saving Mode Flow Chart The computer runs in Normal operation mode until the Doze timer expires, at which point the computer enters Doze mode.
  • Page 38 User's Manual D. Video Off Method This function serves as both a screen saver and power saver for monitors. See the next function, Video Off After, for setting the video timer. Blank - BIOS will only blank the monitor's screen. The electricity saved in this mode is negligible and this function is only used as a screen saver to prevent screen damage while the screen is on but not in use.
  • Page 39 Award BIOS Setup Program Power saving modes achieved in lower power saving states will either be maintained or enter higher power saving modes when switching to higher power saving states. For example, the CPU clock will not switch back to normal in Standby mode.
  • Page 40 User's Manual M. CPUFAN Off In Suspend When enabled, this function turns off the CPU fan when the computer is in suspend mode. N. Power On By Modem When enabled, a modem that receives a call will wake up the system from soft off and green mode.

  • Page 41: Pnp/Pci Configuration

    Award BIOS Setup Program 3-5 PnP/PCI Configuration This section provides IRQ and DMA setting information. By choosing the PnP/PCI Configuration option from the CMOS Setup Utility menu (Figure 3-1), the screen below is displayed. This sample screen contains the manufacturer's default values for the mainboard.
  • Page 42 User's Manual C. Reset Configuration Data When enabled the system BIOS will clear/reset the ESCD during POST. After clearing the ESCD, the BIOS will then change this item's value to Disabled. Otherwise, the ESCD data will become useless. D. IRQ#/DMA# assign to When resources are controlled manually, you can assign each system interrupt &...

  • Page 43: Load Setup Defaults

    Award BIOS Setup Program 3-6 Load Setup Defaults Load Setup Defaults loads the default system values directly from the CMOS Setup Utility menu (Figure3-1). If the stored record created by the setup program becomes corrupted and therefore unusable, these defaults will be loaded automatically when you turn on the computer.

  • Page 44: Integrated Peripherals

    User's Manual 3-7 Integrated Peripherals This section provides information on setting peripheral devices. By choosing the Integrated Peripherals option from the CMOS Setup Utility menu (Figure 3-1), the screen below is displayed. This sample screen contains the manufacturer's default values for the mainboard. ROM PCI / ISA BIOS (2A69KC39) INTEGRATED PERIPHERALS AWARD SOFTWARE, INC.
  • Page 45 Award BIOS Setup Program B. USB Keyboard Support If your current operating system doesn't support USB drivers (i.e., DOS) this function must be enabled for USB keyboard operation in these operating systems. When using a USB keyboard this function is automatically Enabled during bootup regardless of its setting in BIOS.

  • Page 46: Supervisor Password & User Password Setting

    User's Manual 3-8 Supervisor Password & User Password Setting There are four different variables that control password settings. The first two are located under the Security Option function in BIOS Features Setup Menu (Figure 3-3). When the Security Option function is set to Setup, a password is required to enter BIOS and change BIOS settings.
  • Page 47 Award BIOS Setup Program B. Set Both Supervisor Password and User Password Figure 3-11 Set Both Supervisor and User Password...

  • Page 48: Ide Hdd Auto Detection

    User's Manual 3-9 IDE HDD Auto Detection This utility can automatically detect IDE hard disk type and parameters. The detection process take about 5 seconds for each physical drive. After the utility detects the disk drive, type Y and press [Enter] to automatically load the parameters in the Hard Disk section of the Standard CMOS Setup menu.

  • Page 49: Chapter 4 Brief Software Driver Guide

    Brief Software Driver Guide Chapter 4 Chapter 4 Chapter 4 Chapter 4 Chapter 4 Brief Software Driver Guide The Mainboard Software Guide is found on the CD-ROM that is enclosed with your mainboard and is a PDF file which must be viewed with Adobe's freeware called ®...
  • Page 50 Chapter 4 Memo Memo Memo Memo Memo...

  • Page 51: Chapter 5 Audiosub-System

    Chapter 5 Audio Subsystem 5-1 Features ESS Maestro-2 audio chip with advanced wavetable synthesizer . Full Duplex operation for simultineous recording and playback. Up to 20-bit ADC/DAC audio resolution. 500-MIPS-equivalent processor performance to accelerate multi-stream PC audio. Intergrated Spatializer 3D effects Processor. Complies with Microsoft's ACPI 1.0 and PPMI 1.0 (D0~D3) S/Zoomed video support.
  • Page 52 Memo Memo Memo Memo Memo...
  • Page 53 Introduction Appendix I Appendix I Appendix I Appendix I Appendix I On Board I/O Addresses & IRQ Maps System Resource I/O Address 1. Timer IRQ0 040, 043 2. Keyboard IRQ1 060, 064 3. Programmable INT IRQ2 0020, 0021, 00A0, 00A1 4.
  • Page 54 User's Manual Memo Memo Memo Memo Memo...
  • Page 55 Appendix II Appendix II Appendix II Appendix II Appendix II CN3: Infrared connector B ack Panel I/O C onnector PC B U S B 2 C O M 2 C O M 1 K /B U S B 1 G am e Printer M o use Line-in...
  • Page 56 User's Manual Memo Memo Memo Memo Memo...

This manual is also suitable for:

Ct-6asvCt-6btsCt-6asaCt-6bdu6bdu0

Table of Contents
