3-7 PC Health Status
By choosing the PC Health Status option from the CMOS Setup Utility menu (Figure
3-1), the screen below is displayed. This sample screen contains the manufacturer's
default values for the mainboard.
CMOS Setup Utility- Copyright (C) 1984-2001 Award Software
CPU Fan Speed
SYS Fan Speed
12V
5V
2.5V
Vcore
Internal Vcc
:Move Enter:Select
F5:Previous Values
This field shows you the current system temperature/external voltages input and
the current CPU FAN and System FAN operating speed.
38
PC Health Status
4500 RPM
4500 RPM
12.16V
5.05V
2.48V
1.75V
2.45v
+/-/PU/PD:Value
F6:Fail-Safe Defaults
Figure 3-8 PC Health Status Screen
Menu Level
F10:Save
ESC:Exit
F7:Optimized Defaults
Item Help
F1:General Help
