ACACIA SERIES
Natural Wood Tables
General Installation Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the Willow Park ACACIA Series and is the answer not in the manual?

Questions and answers

Related Manuals for CLEAR DESIGN Willow Park ACACIA Series

Summary of Contents for CLEAR DESIGN Willow Park ACACIA Series

  • Page 1 ACACIA SERIES Natural Wood Tables General Installation Guide...

  • Page 2: Leg Installation

    LEG INSTALLATION Place tabletop with bottom facing up on a soft surface to avoid scratching the table. Acacia tables come with pre-drilled holes for installation. Align legs with pre-drilled holes and secure with provided screws. STANDING–HEIGHT ANGLED SLEIGH LEGS WITH SUPPORT BRACES First, align leg and brace pilot holes to surface pre-drilled holes to identify the location of self-tapping screws on bottom of leg.
  • Page 3 SEATED–HEIGHT ANGLED SLEIGH LEGS Wood Screws c) ANGLED POST LEGS Wood Screws...
  • Page 4 2-PIECE SURFACE INSTALLATION Place tabletops with bottoms facing up on a soft surface to avoid scratching the table. Lay the joining hardware into the slotted areas and attach flat brackets 1.5 inches from surface edges. Align leg and brace pilot holes to surface pre-drilled holes to identify the location of self-tapping screws on bottom of leg.
  • Page 6 1-866-304-7197 | inspire@mycleardesign.com | mycleardesign.com © 2023 Clear Design | Version 23.1.0...
