Page 4
WORKSTATION OVERVIEW BLADE Stand-Alone All parts listed are for a single workstation; additional parts will be needed for additional workstations.
Page 5
PARTS LIST CODE DESCRIPTION GB3072 Surface Extra Long Beam Lock Plate Cap Screw Locking Screw and Lever BLADE 30” End Leg BL30 Wood Screws 42” Support Bar* BASB72 Wood Screws *Part will be added to surfaces 72” and longer...
Page 6
1 | JOIN END LEGS WITH BEAM Insert beam tabs into leg brackets. Guide beam tabs into bracket holes, ensuring that there is not a gap between the beam and legs. Using a rubber mallet, hammer the beam to lock in place. 2 | BOLT DOWN BEAM-TO-LEG LOCK PLATE Note: The beam lock plates will not fit if there is a gap between the beam and the leg.
Page 7
3 | MEASURE AND ADJUST BEAM WIDTH Measure from end leg to end leg until you find the approximate width of the work surface. Insert the screw through the overlapping beam slots and into the locking screw and lever. Slightly tighten the screw. DO NOT fully tighten.
Page 8
5 | SECURE BEAM Tighten beam locks. OPTIONAL | INSTALL SUPPORT BAR If working with a surface 72” or longer, use 10 wood screws to install support bar under the surface.
Page 10
A1: SURFACE-MOUNT CABLE MANAGEMENT TRAY OVERVIEW BLADE Stand-Alone If workstations have power, refer to BL-8 BLADE power guide.
Page 11
PARTS LIST CODE DESCRIPTION Surface-Mount Cable Management Tray BHCT Wood Screws...
Page 13
2 | ATTACH CABLE TRAY TO SURFACE Attach cable tray using wood screws.
Page 14
A2: MODESTY PANEL OVERVIEW BLADE Stand-Alone All parts listed are for a single modesty panel; additional parts will be needed for additional modesty panels.
Page 15
PARTS LIST CODE DESCRIPTION Laminate Modesty Panel* GLMP## Machine Screws L-Brackets BMPBFB Wood Screws *For Steel Modesty Panel: components may vary, but process is similar.
Page 16
1 | SECURE BRACKETS TO MODESTY PANEL Connect the BMPBFB bracket to the modesty panel using screws. Secure tightly.
Page 17
2 | ATTACH MODESTY PANEL TO SURFACE Attach modesty panel to surface using wood screws provided with brackets. Panel will be center aligned and flushed with back of surface.
Page 18
A3: LAMINATE INSET END PANELS OVERVIEW BLADE Stand-Alone All parts listed are for a single panel; additional parts will be needed for additional panels.
Page 19
PARTS LIST CODE DESCRIPTION GBEP## Laminate Inset End Panel End Panel T-Bracket LEPBL1 Self-Tapping Screws Wood Screws...
Page 20
1 | SECURE BRACKET TO END LEGS Attach 4 brackets to each BLADE end leg using the self-tapping screws. 1. Inset–The back of the bracket will align flush with edge of leg. 2. Flush–Back of bracket will be 9/16” from edge back edge of leg. Inset Bottom View Align Flush ”...
Page 21
2 | ATTACH END PANEL Slide end panels into place and adjust until flush with bracket. Use 2 wood screws to secure panel to each bracket.
Page 22
A4: STEEL INSET END PANELS OVERVIEW BLADE Stand-Alone All parts listed are for a steel inset end panel; additional parts will be needed for additional steel inset end panels.
Page 23
PARTS LIST CODE DESCRIPTION Steel Inset End Panel BEP## Self-Tapping Screws...
Page 24
1 | SECURE PANELS TO END LEGS Slide the end panel into place and adjust until either flush with outside of leg or slightly recessed. Align Flush Slightly Recessed...
Page 25
2 | ATTACH END PANEL Use 4-6 self-tapping screws to secure panel to each leg.
