- Page 1 KFBCH.B & KFCHR.B KIVA CHAIR AND BARSTOOL Watch Entire Install Video General Installation Guide...
- Page 3 EDITION CODE KFCHR.B :: Chair ...............1 KFBCH.B :: Barstool ............... 7...
- Page 4 CHAIR OVERVIEW KIVA Seating All parts list are for a single chair, additional Scan to Watch Section parts will be needed for additional chairs.
-
Page 5: Parts List
PARTS LIST DESCRIPTION CODE High-back Seat Leg Frame KFBCHR.B Mounting Hardware Screws... -
Page 6: Install Mounting Hardware
1 | DETERMINE FRONT OF FRAME Measure inside of leg widths to determine front of frame. Front will measure 19 inches from outside of legs. Scan to Watch Step Back 20.25" 19" 20" Front Side 2 | INSTALL MOUNTING HARDWARE Bring two-piece mounting hardware closer to center of frame. - Page 7 3 | PLACE FRAME ON SEAT We recommend placing seat on a flat, sturdy surface edge to make mounting process easier. Scan to Watch Step 4 | FIND CORRECT FRAME POSITIONING Scan to Watch Step Front 7" 7.25" Side...
- Page 8 5 | SECURE FRAME TO SEAT WITH SCREWS Scan to Watch Step...
- Page 10 BARSTOOL OVERVIEW KIVA Seating All parts list are for a single stool, additional Scan to parts will be needed for additional stools. Watch Section...
- Page 11 PARTS LIST DESCRIPTION CODE Seat (high back or low back) Leg Frame KFBCH.B Mounting Hardware Screws...
- Page 12 1 | DETERMINE FRONT OF FRAME Leg frame front and sides will have a footrest bar Scan to Watch Step Back Side Front 2 | INSTALL MOUNTING HARDWARE Bring two-piece mounting hardware closer to center of frame. Press mounting hardware together until pieces snap in place. Scan to Watch Step...
- Page 13 3 | PLACE FRAME ON SEAT We recommend placing seat on a flat, sturdy surface edge to make mounting process easier. Scan to Watch Step 4 | FIND CORRECT POSITION BY MEASURING Scan to Watch Step Front Front 6.25” 6" 6.5"...
- Page 14 5 | SECURE FRAME TO SEAT WITH SCREWS Scan to Watch Step...
