Summary of Contents for Clarke METALWORKER CAG121
- Page 1 © 0504 Operating & Maintenance Instructions 4½” Angle Grinder Model CAG121 Part Number 6470088...
- Page 2 Parts and Service For Spare Parts and Servicing, please contact your local dealer, or Clarke International on one of the following Numbers: Parts and Service Tel: 020 89887400 Parts and Service Fax: 020 85583622 or email as follows: Parts: Parts@clarkeinternational.com Service: Service@clarkeinternational.com...
-
Page 3: Table Of Contents
Spare Parts List ....................10 Recommended Grinding Wheels / Cutting Discs ......... 10 Thank you for purchasing this Clarke Angle Grinder. Before using please read these instructions. This is for your own safety and that of others around you, and to help you achieve long and trouble free service from the Grinder. -
Page 4: For Your Own Safety
For Your Own Safety WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result. Keep children away when using Power Tools. -
Page 5: Safety Precautions : For Angle Grinders
Additional Safety Precautions : For Angle Grinders Eye Protection manufactured to the current European Safety Standard should be worn when operating grinding equipment. Ear Protection manufactured to the current European Safety Standard should be worn when operating grinding equipment. A Dust Mask manufactured to the current European Safety Standard should be worn when operating grinding equipment. -
Page 6: Electrical Connections
Electrical Connections Double Insulated Electrical Appliance This appliance is of Double Insulation Construction. Because of its construction there is no earth required and therefore there is no Earth connection. Connect the mains lead to a standard 230V (50Hz) electrical supply through an approved 13 Amp BS1363 plug, or a suitably fused isolator switch. -
Page 7: Overview Of Your Angle Grinder
Figure (1) Overview Safety ON/OFF Switch Handle Spindle Lock Button Abrasive Disk Adjustable Guard Body Before Using the Grinder Fit the Handle : Screw the handle into the left or right hand position in the grinder head as required. Mount the Grinding Wheel / Cutting Disc : See page 7 for details ( i ) Adjust the Guard : The guard... -
Page 8: Mounting The Grinding Wheel / Cutting Disc
Mounting the Grinding Wheel / Cutting Disc ( i ) Unscrew and remove the outer flange : Figure (2) Mounting Discs If it is tight, lock the spindle by pressing the Spindle Lock button and use the tool supplied to turn the flange to break the seal. -
Page 9: Maintenance
Maintenance IMPORTANT! Ensure that the grinder is disconnected from the power supply before carrying out any maintenance. Before Each Use Always inspect the tool before use, and ensure it is in top condition. Ensure all air vents are clear, use compressed air to clean the tool where possible. (Always wear protective goggles when cleaning with compressed air). -
Page 10: Troubleshooting
Tool will not operate 1. No supply 1. Check supply and rectify where necessary. 2. Switch is faulty 2. Consult your Clarke dealer 3. Brushes badly worn 3. Check and replace if necessary 4. Fuse blown 4. Check and replace if necessary... -
Page 11: Spare Parts Diagram
HT12103 Casing HT12104 Outer Flange HT12105 Inner Flange HT12106 Flange Tool HT16107 Grinding Wheel / Cutting Disc ( See Clarke Accessories below ) Recommended Grinding Wheels / Cutting Discs Clarke Accessories Description Part No. Thickness Metal Grinding 6470705 115mm (DPC)
