IEI Technology PulM-1G4T-I211 Quick Installation Manual

Networking module

Advertisement

Quick Links

PulM Series
PulM-1G4T-I211
w w w. i e i wor l d. co m
Package Contents
PulM-1G4T-I211
Torx Screws x 2
Hardware Installation
Slot A
CPU
DMI GEN3 x4
One PCIe x8 or
Two PCIe x4
Slot A
PCIe Con guration
x8
x4
x4
A
Torx Wrench x 1
Slot B
PCH
Four PCIe x2 or
Two PCIe x4
Slot B
PCIe Con guration
x2
x2
x2
x2
x4
x4
A19 A32 PCIe Con g.
0
B
0
1
Networking Module Quick Installation Guide
PulM-1G4T-I211 Block Diagram
PCIe CONF. MODE
A32
Four x2
A19
PCIe 2.0
A32
LAN LED Status
LAN Port
Link
Speed
LED
LED
Install the PulM-1G4T-I211 networking module into the slot of the
PUZZLE series. The Slot A supports 8 lanes from CPU (1 PCIe x8 or
2 PCIe x4); the Slot B supports 8 lanes from PCH (2 PCIe x4 or 4 PCIe
x2). When the PulM-1G4T-I211 is installed into the Slot A, only two
LAN ports (port 1 & port 3) are active.
Slot
0
4x2
B
1
2x4
A & B
0
1x8
A
A19
0
0
Intel ®
Ethernet 1G
I211
Ethernet 1G
Intel ®
I211
Ethernet 1G
Intel ®
I211
Ethernet 1G
Intel ®
I211
LED
State
Description
Link (Left)
Yellow
Active
Orange
1 Gbps date rate
Speed (Right)
Green
100 Mbps data rate
RJ-45
RJ-45
RJ-45
RJ-45
