IEI Technology PulM Series Quick Installation Manual

PulM Series
PulM-1G8T-BCM5720
w w w. i e i wor l d. co m

Package Contents

PulM-1G8T-BCM5720
Torx Screws x 2

Hardware Installation

Slot A
CPU
DMI GEN3 x4
One PCIe x8 or
Two PCIe x4
Slot A
PCIe Con guration
x8
x4 x4
A
Torx Wrench x 1
Slot B
PCH
Four PCIe x2 or
Two PCIe x4
Slot B
PCIe Con guration
x2 x2 x2 x2
x4 x4
A19 A32 PCIe Con g.
0
B
0
1
Networking Module Quick Installation Guide
PulM-1G8T-BCM5720 Block Diagram
PCIe CONF. MODE A32
Four x2
A19
PCIe 2.0
A32

LAN LED Status

LAN Port
Link Speed
LED LED
Install the PulM-1G8T-BCM5720 networking module into the slot
of the PUZZLE series. The Slot A supports 8 lanes from CPU (1 PCIe
x8 or 2 PCIe x4); the Slot B supports 8 lanes from PCH (2 PCIe x4 or
4 PCIe x2). When the PulM-1G8T-BCM5720 is installed into the Slot
A, only four LAN ports (port 1, port 2, port 5 & port6) are active.
Slot
0 4x2 B
1 2x4 A & B
0 1x8 A
A19
0 0
BCM5720 Ethernet 1G
Ethernet 1G
BCM5720
Ethernet 1G
BCM5720
Ethernet 1G
BCM5720
LED State Description
Link (Left) Yellow Active
Orange 1 Gbps date rate
Speed (Right)
Green 100 Mbps data rate
RJ-45 RJ-45
RJ-45 RJ-45
RJ-45 RJ-45
RJ-45 RJ-45
